Interior Trim: Removal & Installation Mazda CX-9 I рестайлинг

Bolt D Removal Note

Dashboard Removal Note

Scheme 5

1. Raise the dashboard and detach the hooks from the body.
2. Take the dashboard out through the opened front driver-side door.

CLUSTER SWITCH REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove dashboard under cover. (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-663022-S31534965712014101600000)
3. Remove the hood release lever. (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-663023-S07470612692014101600000) .)
4. Pull the cluster switch in the direction of the arrow (2) shown in the figure while pressing the tab in the direction of the arrow (1) shown in the figure. Detach the tab and lower panel, and then remove the cluster switch from the lower panel.
5. Disconnect the connector.
6. Install in reverse order of removal.

Scheme 6

1. Remove the following parts: Information display (See INFORMATION DISPLAY REMOVAL/INSTALLATION .) GPS antenna (See «GPS ANTENNA REMOVAL/INSTALLATION»(ref-663028-S27425395062014101600000) .) Dashboard garnish (See «DASHBOARD GARNISH REMOVAL/INSTALLATION»(ref-663022-S06933668682014101600000) .) Bluetooth unit (See «BLUETOOTH UNIT REMOVAL/INSTALLATION»(ref-663028-S41854392822014101600000) .) Passenger-side air bag module (See «PASSENGER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-663024-S12468609462014101600000) .) (See «PASSENGER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-663024-S24098753322014101600000) .) Front speaker (Vehicles With Bose®) (See «FRONT SPEAKER REMOVAL/INSTALLATION»(ref-663028-S25782369162014101600000) .) Tweeter (Vehicles Without Bose®) (See «TWEETER REMOVAL/INSTALLATION»(ref-663028-S09166143712014101600000) .) Center speaker (See «CENTER SPEAKER REMOVAL/INSTALLATION»(ref-663028-S37899338622014101600000) .) Keyless receiver (See «KEYLESS RECEIVER REMOVAL/INSTALLATION»(ref-663023-S23924536612014101600000) .) Keyless antenna (See «KEYLESS ANTENNA REMOVAL/INSTALLATION [ADVANCED KEYLESS ENTRY AND START SYSTEM]»(ref-663023-S03585838752014101600000) .) keyless control module (See «KEYLESS CONTROL MODULE REMOVAL/INSTALLATION [ADVANCED KEYLESS ENTRY AND START SYSTEM]»(ref-663023-S25652243802014101600000) .) Auto light-off control module (Vehicles without auto light/wiper system) (See «AUTO LIGHT-OFF CONTROL MODULE REMOVAL/INSTALLATION»(ref-663026-S01289442802014101600000) .) Auto light/wiper control module (Vehicles with auto light/wiper system) (See «AUTO LIGHT/WIPER CONTROL MODULE REMOVAL/INSTALLATION»(ref-663026-S42313728362014101600000) .)
2. Disassemble in the order indicated shown in the illustration.
3. Assemble in the reverse order of disassembly.

Scheme 7

1. Remove the screws.
2. Pull down the tilt wheel release lever.
3. Remove the lower column cover in the direction of the arrow shown in the illustration.
4. Install in the reverse order of removal.

Scheme 8

Scheme 9

Scheme 10

Scheme 11

1. Pull the upper column cover upward and detach the upper column cover from the lower column cover.
2. Push the rubber in the direction of the arrow (shown in the illustration) while pinching part A of the rubber. CAUTION: Remove the rubber by pressing it from the backside of the upper column cover. The rubber may deform if it is pulled forcibly or pried with a flathead screwdriver.
3. Push the rubber in the direction of the arrow (shown in the illustration) while partially peeling part B of the rubber.
4. Push part C of the rubber in the direction of the arrow (shown in the illustration) and remove the upper column cover.
5. Install in the reverse order of removal.

Scheme 12

1. Push the rubber in the direction of the arrow (shown in the illustration) in the order of A, B, and C part to install the upper column cover to the rubber.
2. Install the upper column cover to the lower column cover.

Scheme 13

Scheme 14

1. Disconnect the negative battery cable.
2. Remove the following parts: Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-663022-S35013114172014101600000) .) Front console box mat (See «FRONT CONSOLE BOX MAT REMOVAL/INSTALLATION»(ref-663022-S21869071382014101600000) .) Indicator panel (See «INDICATOR PANEL REMOVAL/INSTALLATION»(ref-663022-S05956493772014101600000) .) Front console box (See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-663022-S12692561512014101600000) .)
3. Remove the screws.
4. Detach clips A by pulling them in the direction of the arrow (shown in the illustration). CAUTION: When removing center panel clips A, perform the work carefully so that the panel corners or the clips do not interfere with the center speaker and scratch or damage it.
5. Disconnect the climate control unit connectors and hazard warning switch connector.
6. Remove the center panel.
7. Install in the reverse order of removal. CAUTION: The ventilator grilles will be installed to the shaded areas shown in the illustration. Therefore, if a wiring harness is in the areas, it could get caught and damaged. When installing the center panel, completely press in the wiring harnesses of the hazard warning switch connector in the direction of the arrow (shown in the illustration) so that the wiring harnesses will not be caught.

Scheme 15

1. Disconnect the negative battery cable.
2. Remove the following parts: Dashboard under cover (Driver side) (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-663022-S31534965712014101600000) .) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-663022-S26910641872014101600000) .) Console panel (LH) (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-663022-S28127850752014101600000) .) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-663023-S07470612692014101600000) .)
3. Remove the screw.
4. Detach clips A and hook B by pulling them in the direction of the arrow (shown in the illustration).
5. Remove the hook B.
6. Disconnect the head light leveling switch connector and TCS OFF switch connector.
7. Disconnect the BSM OFF switch connector. (Vehicles with BSM)
8. Disconnect the PLG switch connector. (Vehicles with PLG)
9. Disconnect the cabin temperature sensor connector and air hose.
10. Remove the lower panel.
11. Install in the reverse order of removal.

Scheme 16

1. Remove the glove compartment service hole cover. (See «AIR FILTER REMOVAL/INSTALLATION»(ref-663011-S35564671912014101600000) .)
2. Insert fingers into the glove compartment service hole and detach the tabs A.
3. Remove the side panel in the direction of the arrow (shown in the illustration).
4. Install in the reverse order of removal.

Scheme 17

1. Remove the following parts: Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-663022-S35013114172014101600000) .) Front console box mat (See «FRONT CONSOLE BOX MAT REMOVAL/INSTALLATION»(ref-663022-S21869071382014101600000) .) Indicator panel (See «INDICATOR PANEL REMOVAL/INSTALLATION»(ref-663022-S05956493772014101600000) .) Front console box (See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-663022-S12692561512014101600000) .) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-663022-S15432009222014101600000) .) Upper column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-663022-S36532790502014101600000) .)
2. Detach clips A and pins B by pulling them in the direction of the arrow (shown in the illustration).
3. Remove the meter hood.
4. Install in the reverse order of removal.

GLOVE COMPARTMENT REMOVAL/INSTALLATION

Scheme 18

Scheme 19

Scheme 20

1. Remove the following parts: Dashboard under cover (Passenger side) (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-663022-S31534965712014101600000) .) Glove compartment service hole cover (See «AIR FILTER REMOVAL/INSTALLATION»(ref-663011-S35564671912014101600000) .)
2. Pull the stay damper in the direction shown in the illustration, and detach the connecting part between the glove compartment and the stay damper.
3. Insert fingers into the glove compartment service hole and detach the stoppers while holding the instrument panel.
4. Lower the glove compartment.
5. Detach the hook from the dashboard and remove the glove compartment.
6. Install in the reverse order of removal.

Scheme 21

1. Disconnect the negative battery cable.
2. Remove the following parts: Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-663022-S35013114172014101600000) .) Front console box mat (See «FRONT CONSOLE BOX MAT REMOVAL/INSTALLATION»(ref-663022-S21869071382014101600000) .) Indicator panel (See «INDICATOR PANEL REMOVAL/INSTALLATION»(ref-663022-S05956493772014101600000) .) Front console box (See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-663022-S12692561512014101600000) .) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-663022-S15432009222014101600000) .) Upper column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-663022-S36532790502014101600000) .)
3. Remove the screws.
4. Remove the hook.
5. Remove the ventilator grille in the direction of the arrow (shown in the illustration).
6. Install in the reverse order of removal.

Scheme 22

1. Disconnect the negative battery cable.
2. Remove the following parts: Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-663022-S35013114172014101600000) .) Front console box mat (See «FRONT CONSOLE BOX MAT REMOVAL/INSTALLATION»(ref-663022-S21869071382014101600000) .) Indicator panel (See «INDICATOR PANEL REMOVAL/INSTALLATION»(ref-663022-S05956493772014101600000) .) Front console box (See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-663022-S12692561512014101600000) .) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-663022-S15432009222014101600000) .) Side panel (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-663022-S03719288262014101600000) .) Dashboard garnish (See «DASHBOARD GARNISH REMOVAL/INSTALLATION»(ref-663022-S06933668682014101600000) .)
3. Remove the screws.
4. Remove the hook.
5. Remove the ventilator grille in the direction of the arrow (shown in the illustration).
6. Install in the reverse order of removal.

Scheme 23

1. Disconnect the negative battery cable.
2. Remove the following parts: Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-663022-S35013114172014101600000) .) Front console box mat (See «FRONT CONSOLE BOX MAT REMOVAL/INSTALLATION»(ref-663022-S21869071382014101600000) .) Indicator panel (See «INDICATOR PANEL REMOVAL/INSTALLATION»(ref-663022-S05956493772014101600000) .) Front console box (See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-663022-S12692561512014101600000) .) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-663022-S15432009222014101600000) .)
3. Remove the screws
4. Remove the ventilator grille.
5. Install in the reverse order of removal.

Scheme 24

1. Disconnect the negative battery cable.
2. Remove the console cover. (See «CONSOLE COVER REMOVAL/INSTALLATION»(ref-663022-S08411145752014101600000) .)
3. Remove the rear cooler duct. (See «REAR COOLER DUCT REMOVAL/INSTALLATION»(ref-663011-S41257624632014101600000) .)
4. Detach the pins A while holding the console cover.
5. Remove the ventilator grille in the direction of the arrow (shown in the illustration).
6. Install in the reverse order of removal.

Scheme 25

1. Pull the sail garnish outward, then detach clips A.
2. Remove the inner sail garnish.
3. Install in the reverse order of removal.

Scheme 26

1. Remove the dashboard under cover (Driver side). (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-663022-S31534965712014101600000) .)
2. Detach clips A and hook by pulling them in the direction of the arrow (shown in the illustration).
3. Remove the side wall.
4. Install in the reverse order of removal.

Scheme 27

1. Remove the fasteners.
2. Detach tab A and hook by pulling them in the direction of the arrow (shown in the illustration).
3. Remove the dashboard under cover.
4. Install in the reverse order of removal.

Scheme 28

1. Insert fingers into the service hole and detach clips A and pin B and hooks by pulling it in the direction of the arrow (shown in the illustration).
2. Remove the dashboard under cover.
3. Install in the reverse order of removal.

Scheme 29

1. Disconnect the negative battery cable.
2. Remove the following parts: Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-663022-S35013114172014101600000) .) Front console box mat (See «FRONT CONSOLE BOX MAT REMOVAL/INSTALLATION»(ref-663022-S21869071382014101600000) .) Indicator panel (See «INDICATOR PANEL REMOVAL/INSTALLATION»(ref-663022-S05956493772014101600000) .) Front console box (See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-663022-S12692561512014101600000) .) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-663022-S15432009222014101600000) .) Side panel (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-663022-S03719288262014101600000) .)
3. Remove the screw.
4. Detach clips A by pulling them in the direction of the arrow (shown in the illustration).
5. Remove the dashboard garnish.
6. Install in the reverse order of removal.

Scheme 30

1. Remove the front console box mat. (See «FRONT CONSOLE BOX MAT REMOVAL/INSTALLATION»(ref-663022-S21869071382014101600000) .)
2. Detach clips A and tabs B and C by pulling them in the direction of the arrow (shown in the illustration).
3. Remove the indicator panel.
4. Install in the reverse order of removal.

Scheme 31

Scheme 32

1. Insert a tape-wrapped flathead screwdriver between the indicator panel and front console box mat. CAUTION: The rubber may deform if it is pried with a flathead screwdriver. Therefore, fully insert a tape-wrapped flathead screwdriver as shown in the illustration, and do not pry the rubber.
2. Raise the front console box mat.
3. Remove the front console box mat in the direction of the arrow (shown in the illustration).
4. Remove the front console box mat.
5. Install in the reverse order of removal.

Scheme 33

1. Disconnect the negative battery cable.
2. Remove the following parts: Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-663022-S35013114172014101600000) .) Front console box mat (See «FRONT CONSOLE BOX MAT REMOVAL/INSTALLATION»(ref-663022-S21869071382014101600000) .) Indicator panel (See «INDICATOR PANEL REMOVAL/INSTALLATION»(ref-663022-S05956493772014101600000) .)
3. Remove the screw.
4. Detach clip A and hooks by pulling them in the direction of the arrow (shown in the illustration).
5. Disconnect the connector.
6. Remove the front console box.
7. Install in the reverse order of removal.

Scheme 34

1. Disconnect the negative battery cable.
2. Detach clips A and tabs B by pulling them in the direction of the arrow (shown in the illustration).
3. Disconnect the rear climate control unit connector.
4. Remove the console cover.
5. Install in the reverse order of removal.

Scheme 35

1. Disconnect the negative battery cable.
2. Remove the following parts: Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-663022-S35013114172014101600000) .) Front console box mat (See «FRONT CONSOLE BOX MAT REMOVAL/INSTALLATION»(ref-663022-S21869071382014101600000) .) Indicator panel (See «INDICATOR PANEL REMOVAL/INSTALLATION»(ref-663022-S05956493772014101600000) .) Front console box (See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-663022-S12692561512014101600000) .) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-663022-S31534965712014101600000) .) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-663022-S26910641872014101600000) .) Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-663022-S28127850752014101600000) .) Console cover (See «CONSOLE COVER REMOVAL/INSTALLATION»(ref-663022-S08411145752014101600000) .)
3. Remove the screws.
4. Remove the bolts.
5. Disconnect the accessory socket connector and auxiliary jack connector, and keyless antenna connector.
6. Remove the console in the direction of the arrow (shown in the illustration).
7. Install in the reverse order of removal.

Scheme 36

1. Disassemble in the order indicated shown in the illustration.
2. Assemble in the reverse order of disassembly.

Scheme 37

1. Detach clips A and pin B by pulling them in the direction of the arrow (shown in the illustration).
2. Remove the decoration panel.
3. Install in the reverse order of removal.

Scheme 38

1. Remove the decoration panel (RH). (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-663022-S35013114172014101600000) .)
2. Remove the dashboard under cover (Passenger side). (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-663022-S31534965712014101600000) .)
3. Detach clips A and B, and hooks by pulling them in the direction of the arrow (shown in the illustration).
4. Remove the console panel.
5. Install in the reverse order of removal.

Scheme 39

1. Remove the decoration panel (LH). (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-663022-S35013114172014101600000) .)
2. Remove the dashboard under cover (Driver side). (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-663022-S31534965712014101600000) .)
3. Remove the side wall. (See «SIDE WALL REMOVAL/INSTALLATION»(ref-663022-S26910641872014101600000) .)
4. Remove the fastener.
5. Detach clips A and B, and hooks by pulling them in the direction of the arrow (shown in the illustration).
6. Remove the console panel.
7. Install in the reverse order of removal.

Scheme 40

Scheme 41

Scheme 42

Scheme 43

1. Partially peel back the seaming welt.
2. Pull the A-pillar trim shown in the illustration in the direction of the arrow (shown in the illustration), raise clip B from its grommet together with the A-pillar trim, and remove clips A at the same time.
3. Slide the A-pillar trim in the direction of the arrow shown in the illustration and remove the A-pillar trim from clip B.
4. Rotate and pull clip B in the direction of the arrow shown in the illustration until it is no longer loose, and feels tight.
5. Pull clip B and remove it from the grommet.
6. Insert a tape-wrapped flathead screwdriver between the body and the grommet.
7. Press the tabs and remove the grommet.
8. Install the new grommet to the body.
9. Install the new clip B to the A-pillar trim.
10. Install the A-pillar trim.

Scheme 44

1. Remove the front scuff plate inner. (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-663022-S02482966052014101600000) .)
2. Partially peel back the seaming welt.
3. Remove the nut.
4. Pull the front side trim upward, then detach clip A, pin B.
5. Remove the front side trim.
6. Install in the reverse order of removal.

Scheme 45

1. Remove the front scuff plate inner. (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-663022-S02482966052014101600000) .)
2. Remove the rear scuff plate inner. (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-663022-S18589923242014101600000) .)
3. Remove the front seat belt lower anchor installation bolt (Driver side). (See FRONT SEAT BELT REMOVAL/INSTALLATION .)
4. Partially peel back the seaming welt.
5. Detach tabs A and clips B and D, and pins C, by pulling them in the direction of the arrow (shown in the illustration).
6. Remove the B-pillar lower trim.
7. Install in the reverse order of removal.

Scheme 46

Scheme 47

1. Remove the following parts: Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-663022-S02482966052014101600000) .) Rear scuff plate inner (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-663022-S18589923242014101600000) .) Front seat belt lower anchor installation bolt (Driver side) (See FRONT SEAT BELT REMOVAL/INSTALLATION .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-663022-S08382637232014101600000) .) Front seat belt upper anchor installation bolt (See FRONT SEAT BELT REMOVAL/INSTALLATION .)
2. Partially peel back the seaming welt.
3. Detach clips A and C, and pin B by pulling them in the direction of the arrow (shown in the illustration).
4. Remove the B pillar upper trim in the direction of the arrow (shown in the illustration).
5. Install in the reverse order of removal.

Scheme 48

1. Detach clip A and B, and tab C by pulling them in the direction of the arrow (shown in the illustration).
2. Remove the roof side trim.
3. Install in the reverse order of removal.

Scheme 49

Scheme 50

1. Disconnect the negative battery cable.
2. Remove the following parts: Trunk box (See «TRUNK BOX REMOVAL/INSTALLATION»(ref-663022-S31210991332014101600000) .) Seat side box (See «SEAT SIDE BOX REMOVAL/INSTALLATION»(ref-663022-S00169912002014101600000) .) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-663022-S10346444022014101600000) .) Third-row seat (See THIRD-ROW SEAT REMOVAL/INSTALLATION .) Third-row seat belt lower anchor installation bolt (See THIRD-ROW SEAT BELT REMOVAL/INSTALLATION .) Rear scuff plate inner (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-663022-S18589923242014101600000) .) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-663022-S12440623912014101600000) .) Second-row seat belt upper anchor installation bolt (See SECOND-ROW SEAT BELT REMOVAL/INSTALLATION .) Roof side trim (See «ROOF SIDE TRIM REMOVAL/INSTALLATION»(ref-663022-S09102032652014101600000) .)
3. Partially peel back the seaming welt.
4. Remove the cover in the direction of the arrow (shown in the illustration).
5. Remove the bolt.
6. Detach clip A and tab B, and pin C by pulling them in the direction of the arrow (shown in the illustration).
7. Remove the C-pillar trim.
8. Install in the reverse order of removal.

Scheme 51

Scheme 52

1. Remove the following parts: Trunk box (See «TRUNK BOX REMOVAL/INSTALLATION»(ref-663022-S31210991332014101600000) .) Seat side box (See «SEAT SIDE BOX REMOVAL/INSTALLATION»(ref-663022-S00169912002014101600000) .) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-663022-S10346444022014101600000) .) Third-row seat (See THIRD-ROW SEAT REMOVAL/INSTALLATION .) Third-row seat belt lower anchor installation bolt (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-663022-S18589923242014101600000) .) Rear scuff plate inner (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-663022-S18589923242014101600000) .) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-663022-S12440623912014101600000) .) Roof side trim (See «ROOF SIDE TRIM REMOVAL/INSTALLATION»(ref-663022-S09102032652014101600000) .) Third-row seat belt upper anchor installation bolt (See THIRD-ROW SEAT BELT REMOVAL/INSTALLATION .)
2. Remove the PLG arm band. (Vehicles with PLG)
3. Partially peel back the seaming welt.
4. Remove the fasteners.
5. Detach clips A and pins B by pulling them in the direction of the arrow (shown in the illustration).
6. Remove the D-pillar trim.
7. Install in the reverse order of removal.

Scheme 53

1. Pull the front scuff plate inner upward while detaching tab A, detach clips B, pins C, and tab D, from the body, and then remove the front scuff plate inner.
2. Install in the reverse order of removal.

Scheme 54

1. Pull the front scuff plate outer upward, detach clips A, tabs B, and pin C, from the body, and then remove the front scuff plate outer.
2. Install in the reverse order of removal.

Scheme 55

1. Pull the rear scuff plate inner upward while detaching tab A, detach clips B, pins C, and tab D, from the body, and then remove the rear scuff plate inner.
2. Install in the reverse order of removal.

Scheme 56

1. Pull the rear scuff plate outer upward, detach clips A, tabs B, and pin C, from the body, and then remove the rear scuff plate outer.
2. Install in the reverse order of removal.

Scheme 57

1. Detach clips A and hook B by pulling them in the direction of the arrow (shown in the illustration).
2. Remove the inner garnish.
3. Install in the reverse order of removal.

Scheme 58

1. Disassemble in the order indicated shown in the illustration.
2. Assemble in the reverse order of disassembly.

Scheme 59

1. Remove the trunk box. (See «TRUNK BOX REMOVAL/INSTALLATION»(ref-663022-S31210991332014101600000) .)
2. Remove the seat side box. (See «SEAT SIDE BOX REMOVAL/INSTALLATION»(ref-663022-S00169912002014101600000) .)
3. Detach clips A and pin B by pulling them in the direction of the arrow (shown in the illustration).
4. Remove the trunk end trim.
5. Install in the reverse order of removal.

Scheme 60

1. Disconnect the negative battery cable.
2. Remove the following parts: Trunk box (See «TRUNK BOX REMOVAL/INSTALLATION»(ref-663022-S31210991332014101600000) .) Seat side box (See «SEAT SIDE BOX REMOVAL/INSTALLATION»(ref-663022-S00169912002014101600000) .) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-663022-S10346444022014101600000) .) Third-row seat (See THIRD-ROW SEAT REMOVAL/INSTALLATION .) Rear scuff plate inner (LH) (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-663022-S18589923242014101600000) .) Third-row seat belt lower anchor installation bolt (LH) (See THIRD-ROW SEAT BELT REMOVAL/INSTALLATION .)
3. Pull the cup holder upward and detach clips A, pins B, and tabs C. (Vehicles without RES)
4. Pull the auxiliary terminal unit panel upward and detach clips A, pins B, and tabs C. (Vehicles with RES)
5. Disconnect the power supply socket connector and external input connector. (Vehicles with RES)
6. Remove the cup holder. (Vehicles without RES)
7. Remove the external input panel. (Vehicles with RES)
8. Remove the bolts, and remove the cargo net hook.
9. Remove the cover.
10. Remove the screw.
11. Remove the bolts.
12. Pull the trunk side trim outward and detach clips D, tabs E, and pin F.
13. Remove the trunk side trim.
14. Install in the reverse order of removal.

Scheme 61

1. Disconnect the negative battery cable.
2. Remove the following parts: Trunk box (See «TRUNK BOX REMOVAL/INSTALLATION»(ref-663022-S31210991332014101600000) .) Seat side box (See «SEAT SIDE BOX REMOVAL/INSTALLATION»(ref-663022-S00169912002014101600000) .) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-663022-S10346444022014101600000) .) Third-row seat (See THIRD-ROW SEAT REMOVAL/INSTALLATION .) Rear scuff plate inner (RH) (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-663022-S18589923242014101600000) .) Third-row seat belt lower anchor installation bolt (RH) (See THIRD-ROW SEAT BELT REMOVAL/INSTALLATION .)
3. Pull the cup holder upward and detach clips A, pins B, and tabs C.
4. Remove the cup holder.
5. Remove the bolts, and remove the cargo net hook.
6. Remove the cover.
7. Remove the screw.
8. Remove the bolts.
9. Pull the trunk side trim outward and detach clips D, tabs E, and pin F.
10. Disconnect the accessory socket connector.
11. Remove the trunk side trim.
12. Install in the reverse order of removal.

Scheme 62

Scheme 63

Scheme 64

1. Disconnect the negative battery cable.
2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-663022-S19522180432014101600000) .)
3. Open the cover using a small flathead screwdriver and remove the screw.
4. Remove the armrest garnish in the direction of the arrow (shown in the illustration).
5. Remove the bolt.
6. Detach clips A from the front door using a fastener remover.
7. Pull the front door trim upward and detach tabs B from the front door.
8. Remove tab A, and move the front door trim in the direction of the arrow (shown in the illustration).
9. Turn the inner handle cover in the direction of the arrow (shown in the illustration) and remove it from the front door trim.
10. Disconnect the power window main switch connector and the power outer mirror switch connector and door lock switch connector. (Driver side)
11. Disconnect the power window subswitch connector. (Passenger side)
12. Disconnect the courtesy light connector.
13. Remove the front door trim.
14. Install in the reverse order of removal.

Scheme 65

1. Disassemble in the order indicated shown in the illustration.
2. Assemble in the reverse order of disassembly.

Scheme 66

Scheme 67

Scheme 68

1. Disconnect the negative battery cable.
2. Remove the inner sail garnish. (See «INNER SAIL GARNISH REMOVAL/INSTALLATION»(ref-663022-S25876355302014101600000) .)
3. Open the cover A using a small flathead screwdriver and remove the screw.
4. Pull up the cover B and remove the screw.
5. Detach clips A from the front door using a fastener remover.
6. Pull the front door trim upward and detach tabs B from the front door.
7. Remove tab A, and move the rear door trim in the direction of the arrow (shown in the illustration).
8. Turn the inner handle cover in the direction of the arrow (shown in the illustration) and remove it from the rear door trim.
9. Disconnect the power window subswitch connector.
10. Remove the rear door trim.
11. Install in the reverse order of removal.

Scheme 69

1. Open the trunk board.
2. Remove the fasteners.
3. Remove the trunk box in the direction of the arrow (shown in the illustration).
4. Install in the reverse order of removal.

Scheme 70

1. Remove the trunk box. (See «TRUNK BOX REMOVAL/INSTALLATION»(ref-663022-S31210991332014101600000) .)
2. Detach clips A and tab B by pulling them in the direction of the arrow (shown in the illustration).
3. Remove the seat side box.
4. Install in the reverse order of removal.

Scheme 71

1. Remove the trunk box. (See «TRUNK BOX REMOVAL/INSTALLATION»(ref-663022-S31210991332014101600000) .)
2. Detach pins by pulling them in the direction of the arrow (shown in the illustration).
3. Remove the seat side box.
4. Install in the reverse order of removal.

Scheme 72

1. Detach tabs A, clips B, and pin C by pulling them in the direction of the arrow (shown in the illustration).
2. Remove the liftgate upper trim.
3. Install in the reverse order of removal.

Scheme 73

1. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-663022-S35774143582014101600000) .)
2. Remove the PLG arm band. (Vehicles with PLG)
3. Remove the fastener.
4. Detach clips A and tab B by pulling them in the direction of the arrow (shown in the illustration).
5. Remove the liftgate side trim.
6. Install in the reverse order of removal.

Scheme 74

Scheme 75

1. Disconnect the negative battery cable.
2. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-663022-S35774143582014101600000) .)
3. Remove the liftgate side trim. (See «LIFTGATE SIDE TRIM REMOVAL/INSTALLATION»(ref-663022-S37890998892014101600000) .)
4. Insert a tape-wrapped flathead screwdriver into the position shown in the illustration, and pull the screwdriver in the direction of the arrow (shown in the illustration) to detach clips A.
5. Detach tabs B and remove the liftgate recess.
6. Disconnect the PLG sub switch connector. (Vehicles with PLG)
7. Remove the fasteners.
8. Detach clips A, tabs B, and pins C by pulling them in the direction of the arrow (shown in the illustration).
9. Disconnect the cargo compartment light connector.
10. Remove the liftgate lower trim.
11. Install in the reverse order of removal.

Scheme 76

Scheme 77

1. Insert a flathead screwdriver into the service hole and remove the assist handle covers.
2. Insert a tape-wrapped flathead screwdriver into the position shown in the illustration, press the flathead screwdriver in the direction of the arrow (shown in the illustration) and press the clip away from the assist handle bracket. CAUTION: When inserting a flathead screwdriver, be careful not to damage the assist handle tabs shown in the illustration.
3. Remove the assist handle by shaking it up and down.

Scheme 78

1. Push the assist handle in the direction of the arrow (shown in the illustration) with the assist handle cover assembled to install the assist handle.

Scheme 79

Scheme 80

1. Disconnect the negative battery cable.
2. Remove the cover.
3. Remove the screw.
4. Rotate the sunvisor in the direction of the arrow (shown in the illustration).
5. Unhook and remove the sunvisor.
6. Disconnect the vanity mirror illumination connector.
7. Press the center adaptor tabs as shown in the illustration using two tape-wrapped flathead screwdrivers, and remove the center adaptor.
8. Install in the reverse order of removal.

Scheme 81

Scheme 82

1. Disconnect the negative battery cable.
2. Partially peel back the seaming welt.
3. Remove the following parts: A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-663022-S20449993582014101600000) .) Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-663022-S02482966052014101600000) .) Rear scuff plate inner (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-663022-S18589923242014101600000) .) Front seat belt lower anchor installation bolt (Driver side) (See FRONT SEAT BELT REMOVAL/INSTALLATION .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-663022-S08382637232014101600000) .) Front seat belt upper anchor installation bolt (See FRONT SEAT BELT REMOVAL/INSTALLATION .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-663022-S32370238852014101600000) .) Trunk box (See «TRUNK BOX REMOVAL/INSTALLATION»(ref-663022-S31210991332014101600000) .) Seat side box (See «SEAT SIDE BOX REMOVAL/INSTALLATION»(ref-663022-S00169912002014101600000) .) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-663022-S10346444022014101600000) .) Third-row seat (See THIRD-ROW SEAT REMOVAL/INSTALLATION .) Third-row seat belt lower anchor installation bolt (See THIRD-ROW SEAT BELT REMOVAL/INSTALLATION .) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-663022-S12440623912014101600000) ) Roof side trim (See «ROOF SIDE TRIM REMOVAL/INSTALLATION»(ref-663022-S09102032652014101600000) .) Second-row seat belt upper anchor installation bolt (See SECOND-ROW SEAT BELT REMOVAL/INSTALLATION .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-663022-S19555760622014101600000) .) Third-row seat belt upper anchor installation bolt (See THIRD-ROW SEAT BELT REMOVAL/INSTALLATION .) D-pillar trim (See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-663022-S08006295722014101600000) .) Front map light (See «FRONT MAP LIGHT REMOVAL/INSTALLATION»(ref-663026-S24007146192014101600000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-663022-S41278714162014101600000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-663022-S08813033222014101600000) .) RES unit cover (Vehicles with RES) (See «RES UNIT REMOVAL/INSTALLATION»(ref-663028-S23690488152014101600000) .)
4. Disconnect the roof harness connector.
5. Disconnect the rear washer hose.
6. Remove the sunroof seaming welt. (Vehicles with sunroof)
7. Remove the fasteners.
8. Take the headliner out from the opened liftgate.
9. Install in the reverse order of removal.

Scheme 83

1. Disconnect the negative battery cable.
2. Remove the following parts: Front seat (See FRONT SEAT REMOVAL/INSTALLATION .) Second-row seat (See SECOND-ROW SEAT REMOVAL/INSTALLATION .) Edge cover (See LONG SLIDER REMOVAL/INSTALLATION .) long slider cover (See LONG SLIDER REMOVAL/INSTALLATION .) Trunk box (See «TRUNK BOX REMOVAL/INSTALLATION»(ref-663022-S31210991332014101600000) .) Seat side box (See «SEAT SIDE BOX REMOVAL/INSTALLATION»(ref-663022-S00169912002014101600000) .) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-663022-S10346444022014101600000) .) Third-row seat (See THIRD-ROW SEAT REMOVAL/INSTALLATION .) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-663022-S31534965712014101600000) .) Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-663022-S02482966052014101600000) .) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-663022-S17350159942014101600000) .) Dust cover (See STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION .) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-663022-S26910641872014101600000) .) Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-663022-S28127850752014101600000) .) Console cover (See «CONSOLE COVER REMOVAL/INSTALLATION»(ref-663022-S08411145752014101600000) .) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-663022-S35013114172014101600000) .) Front console box mat (See «FRONT CONSOLE BOX MAT REMOVAL/INSTALLATION»(ref-663022-S21869071382014101600000) .) Indicator panel (See «INDICATOR PANEL REMOVAL/INSTALLATION»(ref-663022-S05956493772014101600000) .) Front console box (See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-663022-S12692561512014101600000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-663022-S34706346452014101600000) .) Rear scuff plate inner (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-663022-S18589923242014101600000) .) Front seat belt lower anchor installation bolt (Driver side) (See FRONT SEAT BELT REMOVAL/INSTALLATION .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-663022-S08382637232014101600000) .) Third-row seat belt lower anchor installation bolt (See THIRD-ROW SEAT BELT REMOVAL/INSTALLATION .) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-663022-S12440623912014101600000) .) Fuel-filler lid release cover (See «FUEL-FILLER LID OPENER REMOVAL/INSTALLATION»(ref-663023-S24561331352014101600000) .)
3. Remove the fasteners A and B.
4. Remove the nut.
5. Take the floor covering out from the opened liftgate.
6. Install in the reverse order of removal.
