Interior Trim: Overview Mazda CX-9 I рестайлинг

Scheme 1

Scheme 2

Scheme 3

Scheme 4

1. Disconnect the negative battery cable.
2. Remove the following parts: Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-663022-S35013114172014101600000) .) Front console box mat (See «FRONT CONSOLE BOX MAT REMOVAL/INSTALLATION»(ref-663022-S21869071382014101600000) .) Indicator panel (See «INDICATOR PANEL REMOVAL/INSTALLATION»(ref-663022-S05956493772014101600000) .) Front console box (See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-663022-S12692561512014101600000) .) Dashboard undercover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-663022-S31534965712014101600000) .) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-663022-S26910641872014101600000) .) Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-663022-S28127850752014101600000) .) Console cover (See «CONSOLE COVER REMOVAL/INSTALLATION»(ref-663022-S08411145752014101600000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-663022-S34706346452014101600000) .) Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-663022-S02482966052014101600000) .) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-663022-S17350159942014101600000) .) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-663022-S35953709692014101600000) .) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-663023-S07470612692014101600000) .) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-663022-S16954671222014101600000) .) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-663022-S36532790502014101600000) .) Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-663024-S32454083042014101600000) .) (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-663024-S42363955022014101600000) .) Steering wheel (See STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION .) Combination switch (See «COMBINATION SWITCH REMOVAL/INSTALLATION»(ref-663026-S01948892012014101600000) .) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-663022-S15432009222014101600000) .) Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-663022-S00847800162014101600000) .) Instrument cluster (See INSTRUMENT CLUSTER REMOVAL/INSTALLATION .) Audio unit (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-663028-S39309799952014101600000) .) Steering shaft (See STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION .) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-663022-S20449993582014101600000) .) Side panel (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-663022-S03719288262014101600000) .)
3. Disconnect the front door wiring harness connector (Driver side). (See FRONT DOOR MODULE PANEL REMOVAL/INSTALLATION .)
4. Disconnect the dashboard harness connectors.
5. Remove the brake switch from the brake pedal with the brake switch connector connected. (See «BRAKE PEDAL REMOVAL/INSTALLATION»(ref-663013-S34704880312014101600000) .)
6. Remove the selector lever component. (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-663030-S38097019132014101600000) .)
7. Remove the windshield wiper arm and blade. (See WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION .)
8. Remove the cowl grille. (See COWL GRILLE REMOVAL/INSTALLATION .)
9. Remove the windshield wiper motor. (See WINDSHIELD WIPER MOTOR REMOVAL/INSTALLATION .)
10. Remove in the order indicated in the illustration.
11. Install in the reverse order of removal.
