Entertainment System: Component Locations Mazda CX-9 I рестайлинг

Entertainment Systems 12 illustrations ~1037 words

ANTENNA FEEDER LOCATION

Note. SIRIUS satellite radio antenna feeder is integrated with the rear wiring harness. GPS antenna feeder is integrated with the dashboard wiring harness, (with car-navigation system)

Scheme 59

Scheme 59: ANTENNA FEEDER NO. 1 REMOVAL/INSTALLATION
Scheme 59: ANTENNA FEEDER NO. 1 REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the following parts: Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-663022-S35013114172014101600000) .) Front console box mat (See «FRONT CONSOLE BOX MAT REMOVAL/INSTALLATION»(ref-663022-S21869071382014101600000) .) Indicator panel (See «INDICATOR PANEL REMOVAL/INSTALLATION»(ref-663022-S05956493772014101600000) .) Front console box (See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-663022-S12692561512014101600000) .) Dashboard undercover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-663022-S31534965712014101600000) .) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-663022-S26910641872014101600000) .) Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-663022-S28127850752014101600000) .) Console cover (See «CONSOLE COVER REMOVAL/INSTALLATION»(ref-663022-S08411145752014101600000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-663022-S34706346452014101600000) .) Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-663022-S02482966052014101600000) .) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-663022-S17350159942014101600000) .) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-663022-S35953709692014101600000) .) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-663023-S07470612692014101600000) .) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-663022-S16954671222014101600000) .) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-663022-S36532790502014101600000) .) Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-663024-S32454083042014101600000) .) (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-663024-S42363955022014101600000) .) Steering wheel (See STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION .) Combination switch (See «COMBINATION SWITCH REMOVAL/INSTALLATION»(ref-663026-S01948892012014101600000) .) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-663022-S15432009222014101600000) .) Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-663022-S00847800162014101600000) .) Instrument cluster (See INSTRUMENT CLUSTER REMOVAL/INSTALLATION .) Audio unit (with audio system) (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-663028-S39309799952014101600000) .) Car-navigation unit (with car-navigation system) (See «CAR-NAVIGATION UNIT REMOVAL/INSTALLATION»(ref-663028-S37587984622014101600000) .) Steering shaft (See STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION .) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-663022-S20449993582014101600000) .) Side panel (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-663022-S03719288262014101600000) .)
  3. Disconnect the front door wiring harness connector (Driver side). (See FRONT DOOR MODULE PANEL REMOVAL/INSTALLATION .)
  4. Disconnect the dashboard harness connectors.
  5. Remove the brake switch from the brake pedal with the brake switch connector connected. (See «BRAKE PEDAL REMOVAL/INSTALLATION»(ref-663013-S34704880312014101600000) .)
  6. Remove the selector lever component. (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-663030-S38097019132014101600000) .)
  7. Remove the windshield wiper arm and blade. (See WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION .)
  8. Remove the cowl grille. (See COWL GRILLE REMOVAL/INSTALLATION .)
  9. Remove the windshield wiper motor. (See WINDSHIELD WIPER MOTOR REMOVAL/INSTALLATION .)
  10. Remove in the dashboard. (See «DASHBOARD REMOVAL/INSTALLATION»(ref-663022-S36557827272014101600000) .)
  11. Remove in the clip A, B, and C.
  12. Remove in the antenna feeder No. 1.
  13. Install in the reverse order of removal.

Scheme 60

Scheme 60: With Audio System
Scheme 60: With Audio System
  1. Disconnect the negative battery cable.
  2. Remove the following parts: Front console box mat (See «FRONT CONSOLE BOX MAT REMOVAL/INSTALLATION»(ref-663022-S21869071382014101600000) .) Indicator panel (See «INDICATOR PANEL REMOVAL/INSTALLATION»(ref-663022-S05956493772014101600000) .) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-663022-S35013114172014101600000) .) Front console box (See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-663022-S12692561512014101600000) .) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-663022-S15432009222014101600000) .) Audio unit (with audio system) (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-663028-S39309799952014101600000) .) Front scuff plate inner (RH) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-663022-S02482966052014101600000) .) Front side trim (RH) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-663022-S17350159942014101600000) .)
  3. Disconnect the antenna feeder No. 2. (See «ANTENNA FEEDER NO. 2 REMOVAL/INSTALLATION»(ref-663028-S35262982922014101600000) .)
  4. Verify that the continuity between antenna feeder No. 1 terminals is as indicated in the illustration below. If not as indicated in the illustration below, replace antenna feeder No. 1.

Scheme 61

Scheme 61: With Car-Navigation System
Scheme 61: With Car-Navigation System
  1. Disconnect the negative battery cable.
  2. Remove the following parts: Front console box mat (See «FRONT CONSOLE BOX MAT REMOVAL/INSTALLATION»(ref-663022-S21869071382014101600000) .) Indicator panel (See «INDICATOR PANEL REMOVAL/INSTALLATION»(ref-663022-S05956493772014101600000) .) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-663022-S35013114172014101600000) .) Front console box (See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-663022-S12692561512014101600000) .) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-663022-S15432009222014101600000) .) Audio unit (with audio system) (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-663028-S39309799952014101600000) .) Front scuff plate inner (RH) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-663022-S02482966052014101600000) .) Front side trim (RH) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-663022-S17350159942014101600000) .)
  3. Disconnect the antenna feeder No. 2. (See «ANTENNA FEEDER NO. 2 REMOVAL/INSTALLATION»(ref-663028-S35262982922014101600000) .)
  4. Verify that the continuity between antenna feeder No. 1 terminals is as indicated in the illustration below. If not as indicated in the illustration below, replace antenna feeder No. 1.

Scheme 62

Scheme 62: ANTENNA FEEDER NO. 2 REMOVAL/INSTALLATION
Scheme 62: ANTENNA FEEDER NO. 2 REMOVAL/INSTALLATION

Scheme 63

Scheme 63
Scheme 63

Scheme 64

Scheme 64
Scheme 64

Scheme 65

Scheme 65
Scheme 65

Scheme 66

Scheme 66
Scheme 66
  1. Disconnect the negative battery cable.
  2. Partially peel back the seaming welt.
  3. Remove the following parts: A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-663022-S20449993582014101600000) .) Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-663022-S02482966052014101600000) .) Front side trim (RH) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-663022-S17350159942014101600000) .) Rear scuff plate inner (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-663022-S18589923242014101600000) .) Front seat belt lower anchor installation bolt (Driver side) (See FRONT SEAT BELT REMOVAL/INSTALLATION .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-663022-S08382637232014101600000) .) Front seat belt upper anchor installation bolt (See FRONT SEAT BELT REMOVAL/INSTALLATION .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-663022-S32370238852014101600000) .) Trunk box (See «TRUNK BOX REMOVAL/INSTALLATION»(ref-663022-S31210991332014101600000) .) Seat side box (See «SEAT SIDE BOX REMOVAL/INSTALLATION»(ref-663022-S00169912002014101600000) .) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-663022-S10346444022014101600000) .) Third-row seat (See THIRD-ROW SEAT REMOVAL/INSTALLATION .) Third-row seat belt lower anchor installation bolt (See THIRD-ROW SEAT BELT REMOVAL/INSTALLATION .) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-663022-S12440623912014101600000) .) Roof side trim (See «ROOF SIDE TRIM REMOVAL/INSTALLATION»(ref-663022-S09102032652014101600000) .) Second-row seat belt upper anchor installation bolt (See SECOND-ROW SEAT BELT REMOVAL/INSTALLATION .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-663022-S19555760622014101600000) .) Third-row seat belt upper anchor installation bolt (See THIRD-ROW SEAT BELT REMOVAL/INSTALLATION .) D-pillar trim (See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-663022-S08006295722014101600000) .) Front map light (See «FRONT MAP LIGHT REMOVAL/INSTALLATION»(ref-663026-S24007146192014101600000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-663022-S41278714162014101600000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-663022-S08813033222014101600000) .) RES unit cover (Vehicles with RES) (See «RES UNIT REMOVAL/INSTALLATION»(ref-663028-S23690488152014101600000) .) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-663022-S13550715042014101600000) .)
  4. Disconnect the antenna feeder No. 1.
  5. Remove the clips A and B.
  6. Remove the clips C, D and E. Without sunroof With sunroof
  7. Remove the clips F.
  8. Remove the bolt.
  9. Disconnect the connector.
  10. Remove in the antenna feeder No. 2.
  11. Install in the reverse order of removal.

Scheme 67

Scheme 67: ANTENNA FEEDER NO. 2 INSPECTION
Scheme 67: ANTENNA FEEDER NO. 2 INSPECTION

Scheme 68

Scheme 68
Scheme 68

Scheme 69

Scheme 69
Scheme 69

Scheme 70

Scheme 70
Scheme 70
  1. Disconnect the negative battery cable.
  2. Remove the following parts: Front scuff plate inner (RH) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-663022-S02482966052014101600000) .) Front side trim (RH) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-663022-S17350159942014101600000) .) Liftgate upper trim (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-663022-S35774143582014101600000) .)
  3. Disconnect the antenna feeder No. 1. (See «ANTENNA FEEDER NO. 1 REMOVAL/INSTALLATION»(ref-663028-S01185161192014101600000) .)
  4. Disconnect the antenna feeder No. 2 connector. (See «ANTENNA FEEDER NO. 2 REMOVAL/INSTALLATION»(ref-663028-S35262982922014101600000) .)
  5. Verify that the continuity between antenna feeder No. 2 terminals is as indicated in the illustrations below. If not as indicated in the illustrations below, replace antenna feeder No. 2.
