HVAC Basic System: Overview Mazda CX-9 I рестайлинг

Automatic HVAC System 6 illustrations ~505 words

Scheme 1

Scheme 1: HVAC BASIC SYSTEM LOCATION INDEX
Scheme 1: HVAC BASIC SYSTEM LOCATION INDEX

Scheme 2

Scheme 2: FRONT A/C UNIT REMOVAL/INSTALLATION
Scheme 2: FRONT A/C UNIT REMOVAL/INSTALLATION

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6
  1. Disconnect the negative battery cable.
  2. Discharge the refrigerant. (See REFRIGERANT CHARGING article.)
  3. Drain the engine coolant. (See «ENGINE COOLANT REPLACEMENT [MZI-3.7]»(ref-663017-S17886152422014101600000) article.)
  4. Remove the following parts: Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-663022-S35013114172014101600000) article.) Front console box mat (See «FRONT CONSOLE BOX MAT REMOVAL/INSTALLATION»(ref-663022-S21869071382014101600000) article.) Indicator panel (See «INDICATOR PANEL REMOVAL/INSTALLATION»(ref-663022-S05956493772014101600000) article.) Front console box (See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-663022-S12692561512014101600000) article.) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-663022-S31534965712014101600000) article.) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-663022-S26910641872014101600000) article.) Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-663022-S28127850752014101600000) article.) Console cover (See «CONSOLE COVER REMOVAL/INSTALLATION»(ref-663022-S08411145752014101600000) article.) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-663022-S34706346452014101600000) article.) Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-663022-S02482966052014101600000) article.) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-663022-S17350159942014101600000) article.) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-663022-S35953709692014101600000) article.) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-663023-S07470612692014101600000) article.) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-663022-S16954671222014101600000) article.) Lower column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-663022-S36532790502014101600000) article.) Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-663024-S32454083042014101600000) article.) (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-663024-S42363955022014101600000) article.) Steering wheel (See STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION article.) Combination switch (See «COMBINATION SWITCH REMOVAL/INSTALLATION»(ref-663026-S01948892012014101600000) article.) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-663022-S15432009222014101600000) article.) Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-663022-S00847800162014101600000) article.) Instrument cluster (See INSTRUMENT CLUSTER REMOVAL/INSTALLATION article.) Audio unit (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-663028-S39309799952014101600000) article.) Steering shaft (See STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION article.) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-663022-S20449993582014101600000) article.) Side panel (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-663022-S03719288262014101600000) article.)
  5. Disconnect the front door wiring harness connector (Driver side). (See FRONT DOOR MODULE PANEL REMOVAL/INSTALLATION article.)
  6. Remove the brake switch from the brake pedal with the brake switch connector connected. (See «BRAKE PEDAL REMOVAL/INSTALLATION»(ref-663013-S34704880312014101600000) article.)
  7. Remove the selector lever component. (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-663030-S38097019132014101600000) article.)
  8. Remove the windshield wiper arm. (See WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION article.)
  9. Remove the cowl grille. (See COWL GRILLE REMOVAL/INSTALLATION article.)
  10. Remove the windshield wiper motor. (See WINDSHIELD WIPER MOTOR REMOVAL/INSTALLATION article.)
  11. Remove the dashboard. (See «DASHBOARD REMOVAL/INSTALLATION»(ref-663022-S36557827272014101600000) article.)
  12. Remove the rear heat duct fasteners and slide the rear heat duct rearward. (See «REAR HEAT DUCT COMPONENT REMOVAL/INSTALLATION»(ref-663011-S08203967002014101600000) .)
  13. Disconnect the drain hose.
  14. Remove the nuts.
  15. Remove the bracket.
  16. Remove the bolts.
  17. Remove the dashboard bracket.
  18. Remove the hose clips.
  19. Remove the front heater hose No. 3 and front heater hose No. 4. (See «HEATER PIPE AND HOSE COMPONENT REMOVAL/INSTALLATION»(ref-663011-S23213271562014101600000) .)
  20. Remove the front cooler pipe No. 1 bracket installation nut.
  21. Remove the nut.
  22. Remove the front cooler pipe No. 1 and front cooler pipe No. 4. (See «REFRIGERANT LINE REMOVAL/INSTALLATION»(ref-663011-S25515470512014101600000) .) CAUTION: If moisture or foreign material enters the refrigeration cycle, cooling ability will be lowered and abnormal noise or other malfunction could occur. Always plug open fittings immediately after removing any refrigeration cycle parts.
  23. Remove the nuts.
  24. Remove the front A/C unit. Do not allow compressor oil to spill.
  25. Install in the reverse order of removal. (See «FRONT A/C UNIT INSTALLATION NOTE»(ref-663011-S32960628922014101600000) .)
  26. Perform the refrigerant system performance test.
