On-Board Diagnostic (Auto Light/wiper Control Module): Overview Mazda CX-9 I

Wiper/washer Systems 2 illustrations ~182 words

Scheme 41

Scheme 41: CLEARING DTC [AUTO LIGHT/WIPER CONTROL MODULE]
Scheme 41: CLEARING DTC [AUTO LIGHT/WIPER CONTROL MODULE]
  1. Connect the M-MDS to the DLC-2.
  2. After the vehicle is identified, select the following items from the initialization screen of the M-MDS. When using the IDS (laptop PC) Select "Self Test". Select "Modules". Select "LCM". When using the PDS (Pocket PC) Select "Module Tests". Select "LCM". Select "Self Test".
  3. Verify the DTC according to the directions on the screen.
  4. Press the clear button on the DTC screen to clear the DTC.
  5. Verify that no DTCs are displayed.

Scheme 42

Scheme 42: DTC INSPECTION [AUTO LIGHT/WIPER CONTROL MODULE]
Scheme 42: DTC INSPECTION [AUTO LIGHT/WIPER CONTROL MODULE]
  1. Connect the M-MDS to the DLC-2.
  2. After the vehicle is identified, select the following items from the initialization screen of the M-MDS. When using the IDS (laptop PC) Select "Self Test". Select "Modules". Select "LCM". When using the PDS (Pocket PC) Select "Module Tests". Select "LCM". Select "Self Test".
  3. Verify the DTC according to the directions on the screen. If any DTCs are displayed, perform troubleshooting according to the corresponding DTC inspection.
  4. After completion of repairs, clear all DTCs stored in the auto light/wiper control module. See «CLEARING DTC [AUTO LIGHT/WIPER CONTROL MODULE]»(ref-345416-S41991523332009102000000) .
