General Information: Removal & Installation Mazda CX-9 I

Oem General Information 7 illustrations ~339 words

INSTALLATION OF RADIO SYSTEM

The control module and control unit have been designed with sufficient attention to radio wave disturbances from the outside. However, observe the following precautions when installing the radio set to the vehicle to prevent adverse effects on the control module and control unit.

Scheme 14

Scheme 14: INSTALLATION OF RADIO SYSTEM
  1. Install the radio set and its antenna as far away as possible from the control module and control unit.
  2. The antenna feeder and power cable generate radio waves, therefore, keep them 100 mm or more from the control module, control unit, and wiring harness. If the antenna feeder and power cable cross over the wiring harness, place them perpendicular to the wiring harness.
  3. Do not install a high output radio set.
  4. Do not use the control module and control unit power source for the radio set. In addition, do not use the cigar lighter and accessory socket power source.
  5. Do not attach the antenna feeder or wiring harness of the radio set to the wiring harness, fuel pipe, or brake tube of the vehicle.
  6. Do not install any radio set-related devices in the area where the air bag module deploys to prevent a secondary accident if the air bag were to deploy.
  7. After installing the radio set, perform a test transmission with the engine idling to verify that it does not affect engine control.

Scheme 15

Scheme 15: Battery Cable
  1. Before disconnecting connectors or removing electrical parts, disconnect the negative battery cable.

Scheme 16

Scheme 16: Wiring Harness

Scheme 17

Scheme 17
  1. To remove the wiring harness from the clip in the engine room, pry up the hook of the clip using a flathead screwdriver. CAUTION: Do not remove the wiring harness protective tape. Otherwise, the wires could rub against the body, which could result in water penetration and electrical shorting.

Scheme 18

Scheme 18: Disconnecting Connectors

Scheme 19

Scheme 19
  1. When disconnecting a connector, grasp the connectors, not the wires.
  2. Connectors can be disconnected by pressing or pulling the lock lever as shown in the figure.

Scheme 20

Scheme 20: Locking Connector
  1. When locking connectors, listen for a click indicating they are securely locked.
