Interior Trim: Overview Mazda CX-9 I

Scheme 1

Scheme 2

Scheme 3

Scheme 4

1. Disconnect the negative battery cable.
2. Remove the following parts: Decoration panel. See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-345331-S31374414672009102000000) . Front console box mat. See «FRONT CONSOLE BOX MAT REMOVAL/INSTALLATION»(ref-345331-S10485313842009102000000) . Indicator panel. See «INDICATOR PANEL REMOVAL/INSTALLATION»(ref-345331-S24413902932009102000000) . Front console box. See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-345331-S18733072432009102000000) . Dashboard under cover. See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-345331-S05761886132009102000000) . Side wall. See «SIDE WALL REMOVAL/INSTALLATION»(ref-345331-S28735626472009102000000) . Console panel. See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-345331-S12921188482009102000000) . Console cover. See «CONSOLE COVER REMOVAL/INSTALLATION»(ref-345331-S33051633072009102000000) . Console. See «CONSOLE REMOVAL/INSTALLATION»(ref-345331-S33017209812009102000000) . Front scuff plate inner. See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-345331-S00212993842009102000000) . Front side trim. See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-345331-S41141327992009102000000) . Glove compartment. See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-345331-S00629389742009102000000) . Hood release lever. See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-345344-S38720975792009102000000) . Lower panel. See «LOWER PANEL REMOVAL/INSTALLATION»(ref-345331-S27563849592009102000000) . Column cover. See «COLUMN COVER REMOVAL/INSTALLATION»(ref-345331-S39771315522009102000000) . Driver-side air bag module. See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-345337-S10259074632009102000000) . Steering wheel. See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-345338-S02652016412009102000000) . Combination switch. See «COMBINATION SWITCH REMOVAL/INSTALLATION»(ref-345339-S03518932132009102000000) . Center panel. See «CENTER PANEL REMOVAL/INSTALLATION»(ref-345331-S22152336712009102000000) . Meter hood. See «METER HOOD REMOVAL/INSTALLATION»(ref-345331-S34116172672009102000000) . Instrument cluster. See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-345363-S11148620752009102000000) . Audio unit. See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-345330-S42396879762009102000000) . Steering shaft. See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-345338-S02652016412009102000000) . A-pillar trim. See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-345331-S17536592742009102000000) . Side panel. See «SIDE PANEL REMOVAL/INSTALLATION»(ref-345331-S06165285212009102000000) .
3. Disconnect the front door wiring harness connector (Driver side). See «FRONT DOOR MODULE REMOVAL/INSTALLATION»(ref-345364-S04095690732009102000000) .
4. Disconnect the dashboard harness connectors.
5. Remove the brake switch from the brake pedal with the brake switch connector connected. See «BRAKE PEDAL REMOVAL/INSTALLATION»(ref-345362-S30768079172009102000000) .
6. Remove the selector lever component. See «SELECTOR LEVER COMPONENT REMOVAL/INSTALLATION»(ref-345341-S00995522882009102000000) .
7. Remove the windshield wiper arm and blade. See «WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION»(ref-345367-S20259665782009102000000) .
8. Remove the cowl grille. See «COWL GRILLE REMOVAL/INSTALLATION»(ref-345340-S17876884912009102000000) .
9. Remove the windshield wiper motor. See «WINDSHIELD WIPER MOTOR REMOVAL/INSTALLATION»(ref-345367-S10993438382009102000000) .
10. Remove in the order indicated in the figure.
11. Install in the reverse order of removal.
