Wheel Alignment System: Adjustments Mazda CX-7 I facelift

Wheel Alignment 4 illustrations ~528 words

FRONT WHEEL ALIGNMENT

ItemFuel gauge indication
Empty1/41/23/4Full
Maximum steering angle [Tolerance ±3°]Inner36°06'
Outer30°54'
Total toe-in[Tolerance ±2 {+0.08}](mm {in})0 {0.00}
(degree)0°00'±0°09'
Caster angle (2) [Tolerance ±1°]2°47'2°50'2°53'2°55'2°57'
Camber angle (2) [Tolerance ± 1°]0°190°20'
Steering axis inclination (Reference value)11° 42'11°43'11°44'
(1) Engine coolant and engine oil are at specified level. Spare tire, jack and tools are in designated position. (2) Difference between left and right must not exceed 1°30'.
(1)Engine coolant and engine oil are at specified level. Spare tire, jack and tools are in designated position.
(2)Difference between left and right must not exceed 1°30'.

FRONT WHEEL ALIGNMENT (UNLOADED) (1)

Note. Total toe-in measuring position Tire: A indicated in the figure (between the center of the tires) Rim inner: B indicated in the figure (between the inner side of the rims)

Scheme 2

Scheme 2: Steering Angle Adjustment
Scheme 2: Steering Angle Adjustment
  1. Jack up the front of the vehicle and support it on safety stands.
  2. Loosen the locknut of the tie-rod end.
  3. Remove the rack boot clamp.
  4. Rotate the tie rod and adjust the steering angle. NOTE: The travel distance of the right and left tie rods should be the same.
  5. Rotate the tie rod and adjust so that the length L shown in the figure is within the specification. Dimension L (reference value) 9.5-23.5 mm {0.38-0.92 in} Difference between left and right 3 mm {0.12 in} or less
  6. Tighten the locknut of the tie-rod end. Tightening torque 68.6-98.0 N.m {7.00-9.99 kg.fm, 50.6-72.2 ft.lbf}
  7. Correct the rack boot twists.
  8. Install and fix the rack boot clamp.
  9. After adjusting the steering angle, always inspect and adjust the toe angle.

Scheme 3

Scheme 3: Camber and Caster Adjustment
Scheme 3: Camber and Caster Adjustment

Scheme 4

Scheme 4
Scheme 4
  1. Remove the windshield wiper arm. (See «WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION»(ref-343767-S09185334432009101500000) ).
  2. Remove the cowl grille. (See «COWL GRILLE REMOVAL/INSTALLATION»(ref-343791-S10664681202009101500000) ).
  3. Jack up the front of the vehicle and support it on safety stands.
  4. Remove the mounting rubber nuts.
  5. Push the shock absorber and coil spring component downward, and turn the direction indicator to the desired position. ADJUSTMENT VALUE FROM ORIGINAL POSITION Direction indicator position Camber angle Caster angle A 0° +0°22' B +0°22' +0°22' C +0°22' 0°
  6. Install the shock absorber and coil spring, then tighten the mounting rubber nuts to the specified torque. Tightening torque 46.1-62.7 N.m {4.71-6.39 kgf-m, 34.1-46.2 ft.lbf}
  7. Install the cowl grille. (See «COWL GRILLE REMOVAL/INSTALLATION»(ref-343791-S10664681202009101500000) ).
  8. Install the windshield wiper arm. (See «WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION»(ref-343767-S09185334432009101500000) ).

Total Toe-in Adjustment

  1. Jack up the front of the vehicle and support it on safety stands.
  2. Loosen the locknut of the tie-rod end.
  3. Remove the rack boot clamp.
  4. Adjust the total toe-in by rotating each tie rod (left and right) in the opposite directions by the same amount respectively. NOTE: Toe angle changes by approx. 6 mm {0.2 in} per one rotation of the tie rod for one wheel. Each tie rod has a right-hand thread. When increasing the toe-in angle, rotate the right tie rod toward the front of the vehicle and rotate the left tie rod toward the rear of the vehicle by the same amount.
  5. Tighten the locknut of the tie-rod end. Tightening torque 68.6-98.0 N.m {7.00-9.99 kgf-m, 50.6-72.2 ft.lbf}
  6. Verify that the rack boot does not have any twisting and install the rack boot clamp.

REAR WHEEL ALIGNMENT

ItemFuel gauge indication
Empty1/41/23/4Full
Total toe-in[Tolerance ±4 {±0.16}](mm {in})2 {0.08}
(degree)0°10'±20'
Camber angle (2) (Reference value) [Tolerance ±1°]0°51'0°54'0°57'1°00'1°03'
Thrust angle (Reference value) [Tolerance ±0°48']0°
(1) Engine coolant and engine oil are at specified level. Spare tire, jack and tools are in designated position. (2) Difference between left and right must not exceed 1°30'.
(1)Engine coolant and engine oil are at specified level. Spare tire, jack and tools are in designated position.
(2)Difference between left and right must not exceed 1°30'.

REAR WHEEL ALIGNMENT (UNLOADED) (1)

Note. Total toe-in measuring position Tire: A indicated in the figure (between the center of the tires) Rim inner: B indicated in the figure (between the inner side of the rims)

Scheme 5

Scheme 5: Total Toe-in Adjustment
Scheme 5: Total Toe-in Adjustment
  1. Loosen the securing nut of the adjusting cam bolt.
  2. Rotate the adjusting cam bolt in either direction to adjust the toe-in. TOE-IN ADJUSTMENT REFERENCE Left wheel Right wheel Toe-out direction Counterclockwise Clockwise Toe-in direction Clockwise Counterclockwise
  3. Tighten the nut. Tightening torque 80-100 N.m {8.2-10.1 kgf.m, 59.1-73.7 ft.lbf}
