Lighting Systems: Other Mazda CX-7 I facelift

DISCHARGE HEADLIGHT CONTROL MODULE REUSE

1. If the discharge headlight control module is dented or damaged in any way, replace the module with a new one to prevent electrical shock and improper operation.
2. Although the control module may temporarily operate normally even though it has received an impact, it is possible that the interior may have been damaged. When reusing the control module, inspect the following items regarding discharge headlight illumination to verify that there are no malfunctions. Verify that the discharge headlights illuminate normally by testing them several times under cold illumination (headlights off for approx. 10 min or more and then turned on) and hot illumination (headlights on for approx. 15 min or more, turned off for approx. 1 min, and then turned on again) conditions. Inspect the headlight illumination in the period from directly after cold illumination until they are uniformly illuminated (approx. 5 min) and verify that there is no flickering or inconsistent brightness. Turn on the headlights for approx. 30 min with normal condition bulbs and verify that there is no brightness difference between the right and left, and that illumination is consistent.

Scheme 41

1. Disconnect the negative battery cable.
2. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-343787-S10990257842009101500000) ).
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.
5. Adjust the headlight aiming. (See «HEADLIGHT AIMING»(ref-343766-S22449296682009101500000) )

Scheme 42

1. Point the headlight beams to a wall and verify that the headlight beams are as shown in the figure.
2. Make a headlight adjustment screen as shown in the figure using double-weight, white paper.
3. Adjust the tire pressure to the specification.
4. Position the unloaded vehicle on a flat, level surface.
5. Seat one person in the driver's seat.
6. Position the vehicle straight ahead and perpendicular to the white screen.
7. Set the headlights 3 m {9.8 ft} from the white screen.
8. Place an object in front of the headlight not being adjusted to block its light beam.
9. Start the engine so that the battery remains charged.
10. Turn on the low-beam headlight.
11. Set the headlight leveling switch to the 0 position. (Vehicles with headlight leveling switch)
12. Adjust by turning the aiming adjustment screw so that elbow point is in the position shown in the figure.

Halogen type

1. Disconnect the negative battery cable.
2. Remove the fasteners and slightly bend back the mudguard.
3. Disconnect the connector. CAUTION: A halogen bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, excessive heat will build up and the life of the bulb will be shortened. When replacing the bulb, hold the metal flange, not the glass.
4. Remove the cover.
5. Remove the socket, then remove the headlight bulb.
6. Install in the reverse order of removal.

Discharge type

Scheme 43

1. Disconnect the negative battery cable.
2. Remove the fasteners and slightly bend back the mudguard.
3. Remove the cover. CAUTION: The bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, excessive heat will build up and the life of the bulb will be shortened. When replacing the bulb, hold the metal flange, not the glass.
4. Remove the connector, then remove the discharge headlight bulb.
5. Install in the reverse order of removal.

Scheme 44

1. Disconnect the negative battery cable.
2. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-343787-S10990257842009101500000) ).
3. Remove the front combination light. (See «FRONT COMBINATION LIGHT REMOVAL/INSTALLATION»(ref-343766-S07288533412009101500000) .)
4. Disconnect the connector. CAUTION: A halogen bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, excessive heat will build up and the life of the bulb will be shortened. When replacing the bulb, hold the metal flange, not the glass.
5. Remove the socket, then remove the headlight bulb.
6. Install in the reverse order of removal.

Discharge headlight inoperative

Scheme 45

FRONT FOG LIGHT AIMING

1. Point the front fog light beams to a wall and verify that the front fog light beams are as shown in the figure.
2. Make a front fog light adjustment screen as shown in the figure using double-weight, white paper.
3. Remove the bolt and cut the plastic piece off at the position shaded shown in the figure.
4. Adjust the tire pressure to the specification.
5. Position the unloaded vehicle on a flat, level surface.
6. Seat one person in the driver's seat.
7. Line up the headlights with the white screen at a distance of 3 m {9.8 ft} apart.
8. Place an object in front of the fog light not being adjusted to block its light beam.
9. Start the engine so that the battery remains charged.
10. Turn the front fog lights on.
11. Loosen the screw, move the front fog light in the direction of the arrows, and adjust the center of the front fog light to the position shown in the figure.
12. Install the bolt and tighten the screw.

AUTO LIGHT ILLUMINATION LEVEL SETTING

Note. Perform the procedure in a condition that allows verification of the headlight illumination because it is necessary to verify the setting condition according to the number of times headlights turn on.

1. Turn the ignition switch to the ON position with the light switch in the OFF position and pulled back (Flash-to-pass ON).
2. Switch the light switch from the OFF to TNS position five times and return it to the OFF position.
3. Pull the light switch back once. (Flash-to-pass ON)
4. Turn the light switch to the TNS position.
5. Switch the light switch from the TNS to ON position five times and return it to the TNS position.
6. Turn the light switch to the ON position.
7. Switch the light switch from the ON to AUTO position five times and return it to the ON position.
8. Turn the light switch to the TNS position. NOTE: Switches to the sensitivity setting mode when the above operations are performed. The headlights turn on for the number of times according to the current setting conditions. Illumination (Two times): Standard sensitivity Illumination (Three times): Low sensitivity
9. Switch the sensitivity by pulling the light switch back (Flash-to pass ON).
10. Verify the number of times the headlights turn on and that the sensitivity is set properly. Illumination (Two times): Standard sensitivity Illumination (Three times): Low sensitivity

Scheme 46

Scheme 47

1. Disconnect the negative battery cable.
2. Insert a scraper into the gap between the headliner and the map light.
3. Press the tab and remove the map light.
4. Disconnect the connector.
5. Remove the socket, then remove the map light bulb.
6. Install in the reverse order of removal.

Scheme 48

Scheme 49

1. Verify that the continuity between the map light terminals is as indicated in the table. If not as indicated in the table, replace the map light.

Scheme 50

Scheme 51

1. Disconnect the negative battery cable.
2. Insert a tape-wrapped flathead screwdriver into the service hole and pry with the screwdriver in the direction shown by the arrow to remove the lens.
3. Remove the interior light bulb.
4. Install in the reverse order of removal.

Scheme 52

1. Disconnect the negative battery cable.
2. Remove the following parts: A-pillar lower trim (See «A-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-343786-S19089065762009101500000) ). A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-343786-S38477671872009101500000) ). Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-343786-S38441409102009101500000) ). Rear scuff plate inner (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-343786-S26288222212009101500000) ). B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-343786-S02459983842009101500000) ). Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-343796-S38173603652009101500000) ). B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-343786-S38009257982009101500000) ). Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-343794-S05270954202009101500000) ). Sub trunk box (See «SUB TRUNK BOX REMOVAL/INSTALLATION»(ref-343786-S21209099022009101500000) ). Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-343786-S36363096202009101500000) ). Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-343786-S20618636202009101500000) ). C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-343786-S42679206212009101500000) ). D-pillar trim (See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-343786-S21078314782009101500000) ). Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-343766-S04919488902009101500000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-343786-S19828267872009101500000) ). Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-343786-S30720771062009101500000) ). Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-343786-S39783741632009101500000) ).
3. Detach the tab and remove the interior light.
4. Install in the reverse order of removal.

Scheme 53

Scheme 54

1. Verify that the continuity between the interior light terminals is as indicated in the table. If not as indicated in the table, replace the interior light.

Scheme 55

Scheme 56

1. Disconnect the negative battery cable.
2. Insert a tape-wrapped flathead screwdriver into the service hole and pry with the screwdriver in the direction shown by the arrow to remove the lens.
3. Remove the cargo compartment light bulb.
4. Install in the reverse order of removal.

Scheme 57

1. Disconnect the negative battery cable.
2. Remove the following parts: A-pillar lower trim (See «A-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-343786-S19089065762009101500000) ). A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-343786-S38477671872009101500000) ). Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-343786-S38441409102009101500000) ). Rear scuff plate inner (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-343786-S26288222212009101500000) ). B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-343786-S02459983842009101500000) ). Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-343796-S38173603652009101500000) ). B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-343786-S38009257982009101500000) ). Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-343794-S05270954202009101500000) ). Sub trunk box (See «SUB TRUNK BOX REMOVAL/INSTALLATION»(ref-343786-S21209099022009101500000) ). Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-343786-S36363096202009101500000) ). Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-343786-S20618636202009101500000) ). C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-343786-S42679206212009101500000) ). D-pillar trim (See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-343786-S21078314782009101500000) ). Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-343766-S04919488902009101500000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-343786-S19828267872009101500000) ). Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-343786-S30720771062009101500000) ). Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-343786-S39783741632009101500000) ).
3. Detach the tab and remove the interior light.
4. Install in the reverse order of removal.

Scheme 58

Scheme 59

1. Verify that the continuity between the cargo compartment light terminals is as indicated in the table. If not as indicated in the table, replace the cargo compartment light.

Scheme 60

1. Disconnect the negative battery cable.
2. Remove the lower column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-343786-S34448879892009101500000) ).
3. Remove the ignition key illumination bulb.
4. Install in the reverse order of removal.

Scheme 61

1. Disconnect the negative battery cable.
2. Remove the A-pillar trim. (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-343786-S38477671872009101500000) ).
3. Remove the sunvisor. (See «SUNVISOR REMOVAL/INSTALLATION»(ref-343786-S19828267872009101500000) ).
4. Remove the map light. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-343766-S04919488902009101500000) .)
5. Set the headliner out of the way.
6. Remove in the order indicated in the table.
7. Install in the reverse order of removal.

Scheme 62

1. Disconnect the negative battery cable.
2. Disassemble in the order indicated in the table.
3. Install in the reverse order of removal.

Scheme 63

Scheme 64

1. Verify that the continuity between door switch terminal and the body ground is as indicated in the table. If not as indicated in the table, replace the door switch.
