Engine -- Lubrication: Removal & Installation Mazda CX-7 I facelift

Lubrication System 16 illustrations ~1450 words

ENGINE OIL REPLACEMENT [L3 WITH TC]

WARNINGHot engines and engine oil can cause severe burns. Turn off the engine and wait until it and the engine oil have cooled. A vehicle that is lifted but not securely supported on safety stands is dangerous. It can slip or fall, causing death or serious injury. Never work around or under a lifted vehicle if it is not securely supported on safety stands. Continuous exposure to USED engine oil has caused skin cancer in laboratory mice. Protect your skin by washing with soap and water immediately after working with engine oil.
CAUTIONIf engine oil is spilled on the exhaust system, wipe it oft completely. If you fail to wipe the spilled engine oil, it will produce fumes because of the heat.

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7
  1. Position the vehicle on level ground.
  2. Remove the oil filler cap.
  3. Remove the service hole cover (installed to under cover) used to drain the engine oil.
  4. Remove the oil pan drain plug.
  5. Drain the engine oil into a container.
  6. Install the oil pan drain plug with a new washer. Oil pan drain plug tightening torque 30-41 N.m {3.1-4.1 kgf.m, 23-30 ft.lbf} NOTE: The amount of residual oil in the engine can vary according to factors such as the replacement method and oil temperature. Verify the oil level after engine oil replacement.
  7. Refill with the following type and amount of the engine oil. Engine oil capacity (approx. quantity) Oil replacement: 5.3 L {5.6 US qt, 4.7 Imp qt} Oil and oil filter replacement: 5.7 L {6.0 US qt, 5.0 Imp qt} Total (dry engine): 6.4 L {6.8 US qt, 5.6 Imp qt} Engine Oil Specification Item U.S.A. and CANADA Except U.S.A. and CANADA Engine oil grade Engine oil viscosity 5W-30
  8. Install the oil filler cap.
  9. Start the engine and confirm that there is no oil leakage. If there is oil leakage, repair or replace the applicable part.
  10. Inspect the oil level. (See «ENGINE OIL LEVEL INSPECTION [L3 WITH TC]»(ref-343776-S09874168562009101500000) .)
  11. Install the service hole cover.

OIL FILTER REPLACEMENT [L3WITH TC]

WARNINGHot engines and engine oil can cause severe burns. Turn off the engine and wait until it and the engine oil have cooled. A vehicle that is lifted but not securely supported on safety stands is dangerous. It can slip or fall, causing death or serious injury. Never work around or under a lifted vehicle if it is not securely supported on safety stands. Continuous exposure to USED engine oil has caused skin cancer in laboratory mice. Protect your skin by washing with soap and water immediately after working with engine oil.
CAUTIONIf engine oil is spilled on the exhaust system, wipe it off completely. If you fail to wipe the spilled engine oil, it will produce fumes because of the heat. To avoid damage to the oil filter, use only specified oil filter.

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9
  1. Remove the under cover.
  2. Loosen the oil filter drain plug. (Do not remove.)
  3. Loosen the filter cover for 1 turn using a commercially available, cup-type oil filter wrench (74 mm {2.9 in} diameter, 14 sided).
  4. Remove the oil filter drain plug, and drain the engine oil. NOTE: Oil could be easily drained when the air is in the filter.
  5. Loosen the oil filter cover for another 1 turn.
  6. Remove the oil filter cover and the oil filter.
  7. Use a clean rag to wipe off the mounting surface on the oil filter adapter and the oil filter cover.
  8. Apply clean engine oil to a new O-ring of the oil filter cover.
  9. Apply clean engine oil to a new O-ring of the oil filter drain plug.
  10. Install the oil filter, oil filter drain plug, and oil filter cover.
  11. Tighten the oil filter cover and the oil filter drain plug. Tightening torque Oil filter cover: 30-35 N.m {3.1-3.5 kgf.m, 22.2-25.8 ft.lbf} Oil filter drain plug: 9-11 N.m {91.8-112.2 kgf.cm, 79.6-97.2 in.lbf}
  12. Start the engine and confirm that there is no oil leakage. If there is oil leakage, repair or replace the applicable part.
  13. Inspect the oil level. (See «ENGINE OIL LEVEL INSPECTION [L3 WITH TC]»(ref-343776-S09874168562009101500000) ).
  14. Install the undercover.

OIL COOLER REMOVAL/INSTALLATION [L3 WITH TC]

WARNINGHot engines and engine oil can cause severe burns. Turn off the engine and wait until it and the engine oil have cooled. A vehicle that is lifted but not securely supported on safety stands is dangerous. It can slip or fall, causing death or serious injury. Never work around or under a lifted vehicle if it is not securely supported on safety stands. Continuous exposure to USED engine oil has caused skin cancer in laboratory mice. Protect your skin by washing with soap and water immediately after working with engine oil.

Scheme 10

Scheme 10
Scheme 10
  1. Disconnect the negative battery cable.
  2. Remove the under cover.
  3. Drain the engine coolant. (See «ENGINE COOLANT REPLACEMENT [L3 WITH TC]»(ref-343779-S08745490832009101500000) ).
  4. Remove in the order indicated in the table.
  5. Use a clean rag to wipe off the mounting surface on the oil filter adapter and the oil cooler.
  6. Install in the reverse order of the removal.
  7. Refill the engine coolant. (See «ENGINE COOLANT REPLACEMENT [L3 WITH TC]»(ref-343779-S08745490832009101500000) ).
  8. Start the engine and confirm that there is no oil leakage. If there is oil leakage, repair or replace the applicable part.
  9. Inspect the oil level. (See «ENGINE OIL LEVEL INSPECTION [L3 WITH TC]»(ref-343776-S09874168562009101500000) .)

OIL PAN REMOVAL/INSTALLATION [L3 WITH TC]

WARNINGHot engines and engine oil can cause severe burns. Turn off the engine and wait until it and the engine oil have cooled. A vehicle that is lifted but not securely supported on safety stands is dangerous. It can slip or fall, causing death or serious injury. Never work around or under a lifted vehicle if It is not securely supported on safety stands. Continuous exposure to USED engine oil has caused skin cancer in laboratory mice. Protect your skin by washing with soap and water immediately after working with engine oil.

Scheme 11

Scheme 11
Scheme 11
  1. Complete the "BEFORE REPAIR PROCEDURE". (See «BEFORE REPAIR PROCEDURE [L3 WITH TC]»(ref-343778-S29211529882009101500000) ).
  2. Remove the battery and battery tray. (See «BATTERY REMOVAL/INSTALLATION [L3 WITH TC]»(ref-343783-S22929626792009101500000) ).
  3. Remove the under cover.
  4. Remove the splash shield (RH).
  5. Drain the engine oil. (See «ENGINE OIL REPLACEMENTS [L3 WITH TC]»(ref-343776-S03692382352009101500000) .)
  6. Drain the engine coolant. (See «ENGINE COOLANT REPLACEMENT [L3 WITH TC]»(ref-343779-S08745490832009101500000) ).
  7. Remove the charge air cooler, air cleaner and fresh air duct component, and air hose. (See «INTAKE AIR SYSTEM REMOVAL/INSTALLATION [L3 WITH TC]»(ref-343780-S31334616152009101500000) ).
  8. Disconnect the quick release connector on the high pressure fuel pump. (See «QUICK RELEASE CONNECTOR REMOVAL/INSTALLATION [L3 WITH TC]»(ref-343778-S20155531342009101500000) ).
  9. Remove the high pressure fuel pump. (See «HIGH PRESSURE FUEL PUMP REMOVAL/INSTALLATION [L3 WITH TC]»(ref-343778-S14465464402009101500000) ).
  10. Remove the ignition coils. (See «IGNITION COIL REMOVAL/INSTALLATION [L3 WITH TC]»(ref-343815-S34231586842009101500000) ).
  11. Loosen the water pump pulley bolts before removing the drive belt.
  12. Remove the drive belt. (See «DRIVE BELT REMOVAL/INSTALLATION [L3 WITH TC]»(ref-343774-S21935724792009101500000) ).
  13. Remove the P/S oil pump with hose and pipe still connected. Position the P/S oil pump out of the way. (See «POWER STEERING OIL PUMP REMOVAL/INSTALLATION»(ref-343793-S40861938122009101500000) ).
  14. Remove the crankshaft position (CKP) sensor. (See «CRANKSHAFT POSITION (CKP) SENSOR REMOVAL/INSTALLATION [L3 WITH TC]»(ref-343775-S29988514872009101500000) ).
  15. Remove the engine front cover. (See «TIMING CHAIN REMOVAL/INSTALLATION [L3 WITH TC]»(ref-343774-S19941505902009101500000) ).
  16. Remove in the order indicated in the table.
  17. Install in the reverse order of removal.
  18. Refill with the specified type and amount of the engine oil. (See «ENGINE OIL REPLACEMENTS [L3 WITH TC]»(ref-343776-S03692382352009101500000) .)
  19. Refill the engine coolant. (See «ENGINE COOLANT REPLACEMENT [L3 WITH TC]»(ref-343779-S08745490832009101500000) ).
  20. Start the engine and confirm that there is no oil leakage. If there is oil leakage, repair or replace the applicable part.
  21. Inspect the oil level. (See «ENGINE OIL LEVEL INSPECTION [L3 WITH TC]»(ref-343776-S09874168562009101500000) ).
  22. Inspect for engine coolant leakage. (See «ENGINE COOLANT LEAKAGE INSPECTION [L3 WITH TC]»(ref-343779-S07286188112009101500000) ).
  23. Inspect for the ignition timing and idle speed. (See «ENGINE TUNE-UP [L3 WITH TC]»(ref-343774-S33779898232009101500000) ).

Scheme 12

Scheme 12: Oil Pan Removal Note
Scheme 12: Oil Pan Removal Note
  1. Remove the oil pan using a separator tool.

Oil Pan Installation Note

CAUTIONApply the silicon sealant in a single, unbroken line around the whole perimeter. Using bolts with the old seal adhering could cause cracks in the housing.

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17
  1. Completely clean and remove any oil, dirt, sealant or other foreign material that may be adhering to the housing and oil pan.
  2. When reusing the oil pan installation bolts, clean any old sealant from the bolts.
  3. Use a square ruler to align the oil pan and the cylinder block junction side on the engine front cover side.
  4. Apply silicone sealant to the oil pan along the inside of the bolt holes as shown in the figure. Thickness 2.2-3.2 mm {0.087-0.126 in}
  5. Tighten the bolts in the order shown in the figure. Tightening torque 17-23 N.m {1.8-2.3 kgf.m, 12.6-16.9 ft.lbf}
  6. Tighten the oil pan-transaxle installation bolts. Tightening torque 37-52 N.m {3.8-5.3 kgf.m, 28-38 ft.lbf}

OIL PUMP REMOVAL/INSTALLATION [L3 WITH TC]

WARNINGHot engines and engine oil can cause severe burns. Turn off the engine and wait until it and the engine oil have cooled. A vehicle that is lifted but not securely supported on safety stands is dangerous. It can slip or fall, causing death or serious injury. Never work around or under a lifted vehicle if it is not securely supported on safety stands. Continuous exposure to USED engine oil has caused skin cancer in laboratory mice. Protect your skin by washing with soap and water immediately after working with engine oil.

Scheme 18

Scheme 18
Scheme 18
  1. Complete the "BEFORE REPAIR PROCEDURE". (See «BEFORE REPAIR PROCEDURE [L3 WITH TC]»(ref-343778-S29211529882009101500000) ).
  2. Remove the battery and battery tray. (See «BATTERY REMOVAL/INSTALLATION [L3 WITH TC]»(ref-343783-S22929626792009101500000) ).
  3. Remove the under cover.
  4. Remove the splash shield (RH).
  5. Drain the engine oil. (See «ENGINE OIL REPLACEMENTS [L3 WITH TC]»(ref-343776-S03692382352009101500000) .)
  6. Drain the engine coolant. (See «ENGINE COOLANT REPLACEMENT [L3 WITH TC]»(ref-343779-S08745490832009101500000) ).
  7. Remove the charge air cooler, air cleaner and fresh air duct component, and air hose. (See «INTAKE AIR SYSTEM REMOVAL/INSTALLATION [L3 WITH TC]»(ref-343780-S31334616152009101500000) ).
  8. Disconnect the quick release connector on the high pressure fuel pump. (See «QUICK RELEASE CONNECTOR REMOVAL/INSTALLATION [L3 WITH TC]»(ref-343778-S20155531342009101500000) ).
  9. Remove the high pressure fuel pump. (See «HIGH PRESSURE FUEL PUMP REMOVAL/INSTALLATION [L3 WITH TC]»(ref-343778-S14465464402009101500000) ).
  10. Remove the ignition coils. (See «IGNITION COIL REMOVAL/INSTALLATION [L3 WITH TC]»(ref-343815-S34231586842009101500000) ).
  11. Loosen the water pump pulley bolts before removing the drive belt.
  12. Remove the drive belt. (See «DRIVE BELT REMOVAL/INSTALLATION [L3 WITH TC]»(ref-343774-S21935724792009101500000) ).
  13. Remove the P/S oil pump with hose and pipe still connected. Position the P/S oil pump out of the way. (See «POWER STEERING OIL PUMP REMOVAL/INSTALLATION»(ref-343793-S40861938122009101500000) ).
  14. Remove the crankshaft position (CKP) sensor. (See «CRANKSHAFT POSITION (CKP) SENSOR REMOVAL/INSTALLATION [L3 WITH TC]»(ref-343775-S29988514872009101500000) ).
  15. Remove the engine front cover. (See «TIMING CHAIN REMOVAL/INSTALLATION [L3 WITH TC]»(ref-343774-S19941505902009101500000) ).
  16. Remove the oil pan. (See «OIL PAN REMOVAL/INSTALLATION [L3 WITH TC]»(ref-343776-S40621167912009101500000) .)
  17. Remove in the order indicated in the table.
  18. Install in the reverse order of removal.
  19. Refill with the specified type and amount of the engine oil. (See «ENGINE OIL REPLACEMENTS [L3 WITH TC]»(ref-343776-S03692382352009101500000) .)
  20. Refill the engine coolant. (See «ENGINE COOLANT REPLACEMENT [L3 WITH TC]»(ref-343779-S08745490832009101500000) ).
  21. Start the engine and confirm that there is no oil leakage. If there is oil leakage, repair or replace the applicable part.
  22. Inspect the oil level. (See «ENGINE OIL LEVEL INSPECTION [L3 WITH TC]»(ref-343776-S09874168562009101500000) .)
  23. Inspect for engine coolant leakage. (See «ENGINE COOLANT LEAKAGE INSPECTION [L3 WITH TC]»(ref-343779-S07286188112009101500000) ).
  24. Inspect for the ignition timing and idle speed. (See «ENGINE TUNE-UP [L3 WITH TC]»(ref-343774-S33779898232009101500000) ).
  25. Inspect the oil pressure. (See «OIL PRESSURE INSPECTION [L3 WITH TC]»(ref-343776-S31469422402009101500000) ).

Scheme 19

Scheme 19: Oil Pump Sprocket Removal/Installation Note
Scheme 19: Oil Pump Sprocket Removal/Installation Note
  1. Temporarily install the crankshaft pulley and crankshaft pulley lock bolt to the crankshaft, and lock the oil pump against rotation as shown in figure.
  2. Remove/install the oil pump sprocket, and then remove the crankshaft pulley and crankshaft pulley lock bolt. Tightening torque 20-30 N.m {2.1-3.0 kgf.m, 15-22 ft.lbf}

Scheme 20

Scheme 20: Oil Pump Installation Note
Scheme 20: Oil Pump Installation Note
  1. Tighten the oil pump bolts in two steps in the order shown in the figure. Tightening torque Step 1: 8-12 N.m {82-122 kgf.cm, 71-105 in.lbf} Step 2: 17-23 N.m {1.8-2.3 kgf.m, 12.6-16.9 ft.lbf}
