FUSE SERVICE CAUTIONS
| CAUTION | Determine and correct the cause of the burnt fuse before replacing it with the specified type. If the fuse is replaced before doing this, it may burn again. |
Scheme 4
- Disconnect the negative battery cable.
- Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-343786-S34448879892009101500000) ).
- Remove in the order indicated in the illustration.
- Install in the reverse order of removal.
Scheme 5
Scheme 6
- Verify that the continuity between the ignition switch terminals is as indicated in the table. If not as indicated in the table, replace the ignition switch.
Scheme 7
- Disconnect the negative battery cable.
- Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-343786-S34448879892009101500000) ).
- Disconnect the key reminder switch connector.
- Remove the key reminder switch.
- Install in the reverse order of removal.
Scheme 8
Scheme 9
- Disconnect the negative battery cable.
- Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-343786-S34448879892009101500000) ).
- Disconnect the key reminder switch connector.
- Inspect for continuity between the key reminder switch terminals using a tester. If there is any malfunction, replace the key reminder switch.
Relay type
| Terminal type | Part name | |
|---|---|---|
| 4 terminals | Type A | Fuel pump relay Fuel pump speed control relay Starter relay NO. 2 Injector relay Drive-by-wire relay A/C relay Rear window defroster relay TNS relay Front fog light relay Back-up light relay Horn relay |
| Type B | Cooling fan relay NO. 1 Cooling fan relay NO. 2 Starter relay NO. 1 Main relay Blower relay Headlight relay | |
Scheme 10
Scheme 11
- Verify the continuity between the relay terminals. If not as indicated in the table, replace the relay.
Scheme 12
Scheme 13
- Verify the continuity between the relay terminals. If not as indicated in the table, replace the relay.
