ANTENNA FEEDER LOCATION
| CAUTION | If the antenna feeder is installed with tension on the cable and wiring harness it could result in of the connection areas and poor contact. When installing and connecting the antenna feeder, always make sure there is slack on the cable and wiring harness. |
Note. The antenna feeder is integrated with the vehicle wiring harness. When installing a new antenna feeder, secure it to the vehicle wiring harness along the installation route of the old antenna feeder.
Scheme 28
Scheme 29
Scheme 30
- Verify that the continuity is as indicated in the illustration. If not as indicated in the illustration, replace the front antenna feeder.
Scheme 31
Scheme 32
- Verify that the continuity is as indicated in the illustration. If not as indicated in the illustration, replace the rear antenna feeder.
Scheme 33
Scheme 34
- Verify that the continuity is as indicated in the table. If not as indicated in the table, replace the SIRIUS satellite radio antenna feeder.
Scheme 35
- Verify that the continuity is as indicated in the illustration. If not as indicated in the table, replace the GPS antenna feeder No.1.
