Sunroof: Removal & Installation Mazda CX-7 I рестайлинг

Sun Roof/t-Top/convertible Top 5 illustrations ~1114 words

FRONT DRAIN HOSE INSTALLATION

CAUTIONIf the front drain hose is pinched or bent anywhere, the water in the hose may not discharge and enter the inside of the vehicle. During and after installation of the trims and the headliner, always make sure there is no interference with the front drain hose. Fix any problem if found.
  1. Apply soapy water to the front drain hose inserting area.
  2. Insert one end (the wider end) of the front drain hose into the sunroof frame.
  3. Install the front drain hose to the clips, parallel to the pillar and free of slack.
  4. Insert the front drain hose joint into the hinge pillar inner hole.
  5. Install the following parts: Dashboard (See «DASHBOARD REMOVAL/INSTALLATION»(ref-375422-S10719057362010102800000) .) Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-375364-S15088001982010102800000) .) Combination switch (See «COMBINATION SWITCH REMOVAL/INSTALLATION»(ref-375320-S24848646192010102800000) .) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-375364-S15088001982010102800000) .) Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-375340-S17292282012010102800000) .) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-375337-S06830601912010102800000) .) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-375422-S22241475042010102800000) .) Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-375422-S12837313052010102800000) .) Knee bolster (See «KNEE BOLSTER REMOVAL/INSTALLATION»(ref-375422-S40455233162010102800000) .) Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-375369-S34089285102010102800000) .) (See «CLIMATE CONTROL UNIT REMOVAL [MANUAL AIR CONDITIONER]»(ref-375367-S26882181632010102800000) .) (See «CLIMATE CONTROL UNIT INSTALLATION [MANUAL AIR CONDITIONER]»(ref-375367-S08977046652010102800000) .) Audio unit (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-375342-S35395625342010102800000) .) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-375422-S25498401972010102800000) .) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-375422-S00635045162010102800000) .) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-375422-S28238229142010102800000) .) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-375401-S08980162612010102800000) .) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-375422-S25337417152010102800000) .) Dashboard under cover Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S05380344012010102800000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-375422-S05218780952010102800000) .) Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-375422-S16179305552010102800000) .) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-375422-S31648295792010102800000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-375422-S01596377622010102800000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-375422-S14848166412010102800000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-375320-S33124507192010102800000) .) D-pillar trim (See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S31047308992010102800000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S26389937922010102800000) .) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S21530471642010102800000) .) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-375422-S17949797502010102800000) .) Sub trunk box (See «SUB TRUNK BOX REMOVAL/INSTALLATION»(ref-375422-S36700633102010102800000) .) Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-375390-S34221810972010102800000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-375422-S41425861872010102800000) .) Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-375441-S36111913702010102800000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-375422-S15162149412010102800000) .) Rear scuff plate inner (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S26643993712010102800000) .) Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S33927733892010102800000) .) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S30388225242010102800000) .) A-pillar lower trim (See «A-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-375422-S07484122802010102800000) .)
  6. Install the seaming welt.

Scheme 9

Scheme 9: REAR DRAIN HOSE REMOVAL
Scheme 9: REAR DRAIN HOSE REMOVAL
  1. Disconnect the negative battery cable.
  2. Partially peel back the seaming welt.
  3. Remove the following parts: A-pillar lower trim (See «A-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-375422-S07484122802010102800000) .) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S30388225242010102800000) .) Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S33927733892010102800000) .) Rear scuff plate inner (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S26643993712010102800000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-375422-S15162149412010102800000) .) Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-375441-S36111913702010102800000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-375422-S41425861872010102800000) .) Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-375390-S34221810972010102800000) .) Sub trunk box (See «SUB TRUNK BOX REMOVAL/INSTALLATION»(ref-375422-S36700633102010102800000) .) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-375422-S17949797502010102800000) .) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S21530471642010102800000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S26389937922010102800000) .) D-pillar trim (See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S31047308992010102800000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-375320-S33124507192010102800000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-375422-S14848166412010102800000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-375422-S01596377622010102800000) .) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-375422-S31648295792010102800000) .)
  4. Disconnect the rear drain hose from the sunroof frame.
  5. Remove the rear drain hose from the clips.
  6. Pull the rear drain hose into the room side.
  7. Remove the rear drain hose.

REAR DRAIN HOSE INSTALLATION

CAUTIONIf the rear drain hose is pinched or bent anywhere, the water in the hose may not discharge and enter the inside of the vehicle. During and after installation of the trims and the headliner, always make sure there is no interference with the rear drain hose. Fix any problem if found.
  1. Apply soapy water to the rear drain hose inserting area.
  2. Insert one end (the wider side) of the rear drain hose into the sunroof frame.
  3. Install the rear drain hose to the clips parallel to the pillar and free of slack.
  4. Insert the rear drain hose joint into the rear pillar inner hole.
  5. Install the following parts: Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-375422-S31648295792010102800000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-375422-S01596377622010102800000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-375422-S14848166412010102800000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-375320-S33124507192010102800000) .) D-pillar trim (See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S31047308992010102800000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S26389937922010102800000) .) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S21530471642010102800000) .) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-375422-S17949797502010102800000) .) Sub trunk box (See «SUB TRUNK BOX REMOVAL/INSTALLATION»(ref-375422-S36700633102010102800000) .) Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-375390-S34221810972010102800000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-375422-S41425861872010102800000) .) Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-375441-S36111913702010102800000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-375422-S15162149412010102800000) .) Rear scuff plate inner (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S26643993712010102800000) .) Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S33927733892010102800000) .) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S30388225242010102800000) .) A-pillar lower trim (See «A-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-375422-S07484122802010102800000) .)
  6. Install the seaming welt.

Scheme 10

Scheme 10: SUNROOF MOTOR REMOVAL/INSTALLATION
Scheme 10: SUNROOF MOTOR REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the following parts: A-pillar lower trim (See «A-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-375422-S07484122802010102800000) .) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S30388225242010102800000) .) Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S33927733892010102800000) .) Rear scuff plate inner (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S26643993712010102800000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-375422-S15162149412010102800000) .) Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-375441-S36111913702010102800000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-375422-S41425861872010102800000) .) Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-375390-S34221810972010102800000) .) Sub trunk box (See «SUB TRUNK BOX REMOVAL/INSTALLATION»(ref-375422-S36700633102010102800000) .) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-375422-S17949797502010102800000) .) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S21530471642010102800000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S26389937922010102800000) .) D-pillar trim (See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S31047308992010102800000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-375320-S33124507192010102800000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-375422-S14848166412010102800000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-375422-S01596377622010102800000) .) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-375422-S31648295792010102800000) .)
  3. Disconnect the sunroof motor connector.
  4. Remove the screws, and then remove the sunroof motor.
  5. Install in the reverse order of removal. NOTE: If the glass panel or the sunroof motor is moved with the sunroof motor removed, initial position setting of the sunroof motor will be required. Perform initial position setting referring to the «SUNROOF MOTOR ASSEMBLY NOTE»(ref-375464-S00814590762010102800000) . (See «SUNROOF UNIT DISASSEMBLY/ASSEMBLY»(ref-375464-S09339781112010102800000) .)
  1. Measure the voltage at each terminal (other than terminal G). If not as specified, inspect the parts listed under "Inspection item" and the related wiring harnesses.
  2. Disconnect the negative battery cable.
  3. Verify that continuity at terminal G is as indicated in the Terminal Voltage Table (Reference).
  4. If the parts and wiring harnesses are normal but the system still does not work properly, replace the sunroof relay.

Scheme 11

Scheme 11: Terminal voltage table (Reference)
Scheme 11: Terminal voltage table (Reference)
TerminalSignalConnected toTest conditionVoltage (V)/ContinuityInspection item
ASlide openSunroof switchSunroof is fully opening.B+Sunroof switch
Other1.0 or less
BSlide close/tilt downSunroof switchSunroof is closing/tilting down.B+Sunroof switch
Other1.0 or less
CTilt upSunroof switchSunroof is tilting up.B+Sunroof switch
Other1.0 or less
EIG2R.WIP 10A fuseTurn the ignition switch to the ON position.B+R.WIP 10A fuse
Other1.0 or less
FVehicle speedInstrument clusterPulse signalInstrument cluster
GGNDGNDUnder any condition: Check for continuity to ground.ContinuityGND
HCommunicationBCMBecause this terminal is for communication, good/no good judgment by terminal voltage is not possible.BCM
JPower supplyROOF 20A fuseUnder any conditionB+ROOF 20A fuse

SUNROOF MOTOR CONNECTOR TERMINALS REFERENCE CHART

Note. The sunroof switch is together with the front map light.

  1. Disconnect the negative battery cable.
  2. Remove the map light from the headliner. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-375320-S33124507192010102800000) .)
  3. Install in the reverse order of removal.

Scheme 12

Scheme 12: SUNROOF SWITCH INSPECTION
Scheme 12: SUNROOF SWITCH INSPECTION

Scheme 13

Scheme 13
Scheme 13
  1. Inspect for continuity between the sunroof switch terminals using an ohmmeter. If not as specified, replace the sunroof switch.
