Power Systems: Other Mazda CX-7 I рестайлинг

Ignition Switch/steering Lock 13 illustrations ~275 words

FUSE SERVICE CAUTIONS

CAUTIONDetermine and correct the cause of the burnt fuse before replacing it with the specified type. If the C fuse is replaced before doing this, it may burn again.

Scheme 5

Scheme 5: IGNITION SWITCH REMOVAL/INSTALLATION
Scheme 5: IGNITION SWITCH REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-375422-S22241475042010102800000) .)
  3. Remove in the order indicated in the table.
  4. Install in the reverse order of removal.

Scheme 6

Scheme 6: IGNITION SWITCH INSPECTION
Scheme 6: IGNITION SWITCH INSPECTION

Scheme 7

Scheme 7
Scheme 7
  1. Verify that the continuity between the ignition switch terminals is as indicated in the table. If not as indicated in the table, replace the ignition switch.

Scheme 8

Scheme 8: KEY REMINDER SWITCH INSPECTION [WITHOUT ADVANCED KEYLESS ENTRY AND START SYSTEM]
Scheme 8: KEY REMINDER SWITCH INSPECTION [WITHOUT ADVANCED KEYLESS ENTRY AND START SYSTEM]

Scheme 9

Scheme 9
Scheme 9
  1. Disconnect the negative battery cable.
  2. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-375422-S22241475042010102800000) .)
  3. Disconnect the key reminder switch connector.
  4. Inspect for continuity between the key reminder switch terminals using a tester. If there is any malfunction, replace the key reminder switch.

Scheme 10

Scheme 10: KEY REMINDER SWITCH REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND START SYSTEM]
Scheme 10: KEY REMINDER SWITCH REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND START SYSTEM]
  1. Disconnect the negative battery cable.
  2. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-375422-S22241475042010102800000) .)
  3. Disconnect the key reminder switch connector.
  4. Remove the key reminder switch.
  5. Install in the reverse order of removal.

Relay type

Terminal typePart name
4 terminalsType AFuel pump relay A/C relay TNS relay Front fog light relay AT main relay Horn relay Main relay (except Canada) Rear window defroster relay (Canada only)
Type BCooling fan relay No. Cooling fan relay No. Headlight relay
Type CStarter relay Blower relay Main relay (Canada only) Rear window defroster relay (except Canada)

RELAY TYPE CHART

Scheme 11

Scheme 11: Type A
Scheme 11: Type A

Scheme 12

Scheme 12
Scheme 12
  1. Verify the continuity between the relay terminals. If not as indicated in the table, replace the relay.

Scheme 13

Scheme 13: Type B
Scheme 13: Type B

Scheme 14

Scheme 14
Scheme 14
  1. Verify the continuity between the relay terminals. If not as indicated in the table, replace the relay.

Scheme 15

Scheme 15: Type C
Scheme 15: Type C

Scheme 16

Scheme 16
Scheme 16
  1. Verify the continuity between the relay terminals. If not as indicated in the table, replace the relay.
Terminal typePart name
4 terminalsType AFuel pump relay Fuel pump speed control relay Fuel injector relay Starter relay No. A/C relay TNS relay Front fog light relay Back-up light relay Horn relay Main relay (except Canada) Rear window defroster relay (Canada only)
Type BCooling fan relay No. Cooling fan relay No. Headlight relay
Type CStarter relay No. Blower relay Main relay (Canada only) Rear window defroster relay (except Canada)

RELAY TYPE CHART

Type A

  1. Verify the continuity between the relay terminals. If not as indicated in the table, replace the relay.

Type B

  1. Verify the continuity between the relay terminals. If not as indicated in the table, replace the relay.

Scheme 17

Scheme 17: Type C
Scheme 17: Type C
  1. Verify the continuity between the relay terminals. If not as indicated in the table, replace the relay.
