Power Systems: Diagnosis Mazda CX-7 I рестайлинг

Ignition Switch/steering Lock 3 illustrations

STEERING LOCK UNIT INSPECTION [WITH ADVANCED KEYLESS ENTRY AND START SYSTEM]

Measure the voltage or inspect for continuity according to the Terminal Voltage Table (Reference). If the voltage is not as specified in the Terminal Voltage Table (Reference), inspect the parts under "Inspection item(s)" and related wiring harnesses.
If the system does not work properly even though the inspection items or related wiring harnesses do not have any malfunction, replace the steering look unit.

Scheme 2

Scheme 2: Terminal Voltage Table (Reference)

Scheme 2: Terminal Voltage Table (Reference)

Terminal	Signal name	Connected to	Measured condition	Voltage (V)/Continuity	Inspection item(s)
C	Ignition key illumination control	Ignition key illumination	Ignition switch off and driver-side door opened.	1.0 or less	Ignition key illumination bulb Related wiring harnesses
C	Ignition key illumination control	Ignition key illumination	15 s or more after all doors closed.	B+	Ignition key illumination bulb Related wiring harnesses
D	Ignition key illumination power supply	Ignition key illumination	Under any condition	B+	Related wiring harnesses
E	Push switch signal	Keyless control module	Start knob pressed	B+	Keyless control module Related wiring harnesses
E	Push switch signal	Keyless control module	Start knob released	1.0 or less	Keyless control module Related wiring harnesses
F	Power supply	Fuse	Under any condition	B+	Fuse Related wiring harnesses
G	Key reminder switch signal	Keyless control module	Key inserted	B+	Keyless control module Related wiring harnesses
G	Key reminder switch signal	Keyless control module	Key removed	1.0 or less	Keyless control module Related wiring harnesses
I	Power supply	Fuse	Under any condition	B+	Fuse Related wiring harnesses
K	Serial communication	Keyless control module	Under any condition: Inspect for continuity to keyless control module.	Continuity detected	Related wiring harnesses
L	GND	Body ground	Under any condition: Inspect for continuity to GND.	Continuity detected	Related wiring harnesses

TERMINAL VOLTAGE CHART

Scheme 3

Scheme 3: RELAY LOCATION [L5]

Scheme 3: RELAY LOCATION [L5]

Scheme 4

Scheme 4: RELAY LOCATION [L3 WITH TC]

Scheme 4: RELAY LOCATION [L3 WITH TC]
