Entertainment System: Removal & Installation Mazda CX-7 I рестайлинг

AUDIO UNIT REMOVAL/INSTALLATION

Scheme 22

Scheme 23

1. Disconnect the negative battery cable.
2. Remove the following parts: Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-375422-S00635045162010102800000) .) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-375422-S25498401972010102800000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

AUDIO AMPLIFIER REMOVAL/INSTALLATION

Note. Some vehicles are equipped with the audio amplifier cover depending on the vehicle production period.

Scheme 24

1. Disconnect the negative battery cable.
2. Remove the sub trunk box. (See «SUB TRUNK BOX REMOVAL/INSTALLATION»(ref-375422-S36700633102010102800000) .)
3. Fold the second-row seat backs forward.
4. Remove in the order indicated in the table.
5. Install in the reverse order of removal.
6. Perform the audio amplifier configuration after replacing the audio amplifier. (See «AUDIO AMPLIFIER CONFIGURATION»(ref-375342-S01769102172010102800000) .) CAUTION: Perform the audio amplifier configuration after replacing the audio amplifier to assure that the audio system operates correctly.

ANTENNA FEEDER NO.2 REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Partially peel back the seaming welt.
3. Remove the following parts: A-pillar lower trim (See «A-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-375422-S07484122802010102800000) .) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S30388225242010102800000) .) Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S33927733892010102800000) .) Rear scuff plate inner (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S26643993712010102800000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-375422-S15162149412010102800000) .) Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-375441-S36111913702010102800000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-375422-S41425861872010102800000) .) Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-375390-S34221810972010102800000) .) Sub trunk box (See «SUB TRUNK BOX REMOVAL/INSTALLATION»(ref-375422-S36700633102010102800000) .) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-375422-S17949797502010102800000) .) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S21530471642010102800000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S26389937922010102800000) .) D-pillar trim (See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S31047308992010102800000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-375320-S33124507192010102800000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-375422-S14848166412010102800000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-375422-S01596377622010102800000) .) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-375422-S31648295792010102800000) .)
4. Remove the antenna feeder NO.2.
5. Install in the reverse order of removal.

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

1. Disconnect the negative battery cable.
2. Remove the following parts: A-pillar lower trim (RH) (See «A-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-375422-S07484122802010102800000) .) A-pillar trim (RH) (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S30388225242010102800000) .) Rear scuff plate inner (RH) (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S26643993712010102800000) .) Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-375390-S34221810972010102800000) .) Sub trunk box (See «SUB TRUNK BOX REMOVAL/INSTALLATION»(ref-375422-S36700633102010102800000) .) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-375422-S17949797502010102800000) .) Trunk side trim (RH) (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S21530471642010102800000) .) D-pillar trim (RH) (See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S31047308992010102800000) .)
3. Disconnect the antenna feeder NO.1.
4. Disconnect the antenna feeder NO.3.
5. Verify that the continuity between antenna feeder NO.2 terminals is as indicated in the table. If not as indicated in the table, replace antenna feeder NO.2.

Scheme 31

1. Disconnect the negative battery cable.
2. Remove the following parts: Rear scuff plate inner (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S26643993712010102800000) .) Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-375390-S34221810972010102800000) .) Sub trunk box (See «SUB TRUNK BOX REMOVAL/INSTALLATION»(ref-375422-S36700633102010102800000) .) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-375422-S17949797502010102800000) .) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S21530471642010102800000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S26389937922010102800000) .) D-pillar trim (See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S31047308992010102800000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-375422-S01596377622010102800000) .)
3. Partially peel back the headliner.
4. Disconnect the connector.
5. Remove the clips A and B.
6. Remove the antenna feeder NO.3.
7. Install in the reverse order of removal.

Scheme 32

Scheme 33

Scheme 34

1. Disconnect the negative battery cable.
2. Remove the following parts: Rear scuff plate inner (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S26643993712010102800000) .) Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-375390-S34221810972010102800000) .) Sub trunk box (See «SUB TRUNK BOX REMOVAL/INSTALLATION»(ref-375422-S36700633102010102800000) .) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-375422-S17949797502010102800000) .) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S21530471642010102800000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S26389937922010102800000) .) D-pillar trim (See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S31047308992010102800000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-375422-S01596377622010102800000) .)
3. Partially peel back the headliner.
4. Disconnect the connector.
5. Verify that the continuity between antenna feeder NO.3 terminals is as indicated in the table. If not as indicated in the table, replace antenna feeder NO.3.

SIRIUS SATELLITE RADIO ANTENNA FEEDER REMOVAL/INSTALLATION

Note. SIRIUS satellite radio antenna feeder is integrated with the rear wiring harness. When installing a new SIRIUS satellite radio antenna feeder, secure it to the vehicle wiring harness along the installation route of the old SIRIUS satellite radio antenna feeder.

Scheme 35

GPS ANTENNA FEEDER REMOVAL/INSTALLATION

Note. GPS antenna feeder is integrated with the dashboard wiring harness.

1. Refer to «DASHBOARD DISASSEMBLY/ASSEMBLY»(ref-375422-S42823331702010102800000) .

Scheme 36

Scheme 37

1. Disconnect the negative battery cable.
2. Remove the following parts: Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-375422-S00635045162010102800000) .) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-375422-S25498401972010102800000) .) Car-navigation unit (See «CAR-NAVIGATION UNIT REMOVAL/INSTALLATION»(ref-375342-S34523276652010102800000) .) Front scuff plate inner (driver's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S33927733892010102800000) .) Front side trim (driver's side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S05380344012010102800000) .) Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-375422-S16179305552010102800000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-375422-S05218780952010102800000) .) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-375401-S08980162612010102800000) .) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-375422-S28238229142010102800000) .) Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-375422-S12837313052010102800000) .) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-375337-S06830601912010102800000) .)
3. Disconnect the GPS antenna connector. (See «GPS ANTENNA REMOVAL/INSTALLATION»(ref-375342-S36156609032010102800000) .)
4. Verify that the continuity is as indicated in the table. If not as indicated in the table, replace the dashboard wiring harness.

Scheme 38

1. Disconnect the negative battery cable.
2. Remove the following parts: Upper garnish (See «DASHBOARD DISASSEMBLY/ASSEMBLY»(ref-375422-S42823331702010102800000) .) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-375422-S00635045162010102800000) .) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-375422-S25498401972010102800000) .) Multi information display (See «MULTI INFORMATION DISPLAY REMOVAL/INSTALLATION»(ref-375337-S00486604342010102800000) .) Front scuff plate inner (driver's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S33927733892010102800000) .) Front side trim (driver's side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S05380344012010102800000) .) Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-375422-S16179305552010102800000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-375422-S05218780952010102800000) .) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-375401-S08980162612010102800000) .) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-375422-S28238229142010102800000) .) Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-375422-S12837313052010102800000) .) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-375337-S06830601912010102800000) .)
3. Disconnect the GPS antenna connector. (See «GPS ANTENNA REMOVAL/INSTALLATION»(ref-375342-S36156609032010102800000) .)
4. Verify that the continuity is as indicated in the table. If not as indicated in the table, replace the dashboard wiring harness.

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

1. Disconnect the negative battery cable and wait for 1 min or more.
2. Remove the driver-side air bag module. (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-375340-S17292282012010102800000) .)
3. Remove the steering wheel. (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-375364-S15088001982010102800000) .)
4. Remove the screw.
5. Remove the wiring harness from the cover hook.
6. Remove the cover tabs and pins from the steering wheel.
7. Remove the cover.
8. Disconnect the connector.
9. Remove the screw.
10. Remove the steering switch pins from the steering wheel.
11. Remove the steering switch.
12. Install in the reverse order of removal.

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

1. Disconnect the negative battery cable and wait for 1 min or more.
2. Remove the driver-side air bag module. (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-375340-S17292282012010102800000) .)
3. Disconnect the steering switch connector.
4. Verify the resistance between the steering switch terminals. If not within the specification, replace the steering switch.
5. Apply battery positive voltage to steering switch terminal O, and connect terminal E to ground.
6. Verify that the LED illuminates. If the LED does not illuminate, replace the steering switch.

Scheme 50

Scheme 51

Scheme 52

Scheme 53

1. Disconnect the negative battery cable and wait for 1 min or more.
2. Remove the driver-side air bag module. (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-375340-S17292282012010102800000) .)
3. Disconnect the steering switch connector.
4. Verify the resistance between the steering switch terminals. If not within the specification, replace the steering switch.
5. Apply battery positive voltage to steering switch terminal O, and connect terminal E to ground.
6. Verify that the LED illuminates. If the LED does not illuminate, replace the steering switch.

Scheme 54

1. Disconnect the negative battery cable.
2. Remove the center speaker cover. (See «CENTER SPEAKER REMOVAL/INSTALLATION»(ref-375342-S12608237582010102800000) .)
3. Remove the microphone in the direction of the arrow (2) shown in the figure while pressing the microphone tabs in the direction of the arrow (1) using a tape-wrapped fastener remover.
4. Install in the reverse order of removal.

Scheme 55

1. Disconnect the negative battery cable.
2. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-375422-S04325768492010102800000) .)
3. Remove the liftgate side trim. (See «LIFTGATE SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S05467767222010102800000) .)
4. Remove the liftgate lower trim. (See «LIFTGATE LOWER TRIM REMOVAL/INSTALLATION»(ref-375422-S12242040212010102800000) .)
5. Remove in the order indicated in the table.
6. Install in the reverse order of removal.

Scheme 56

1. Disconnect the negative battery cable.
2. Remove the following parts: Front scuff plate (RH) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S33927733892010102800000) .) Front side trim (RH) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S05380344012010102800000) .) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-375422-S25337417152010102800000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 57

1. Detach clip A using a flathead screwdriver

Scheme 58

1. Disconnect the negative battery cable.
2. Remove the console panel. (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-375422-S16179305552010102800000) .)
3. Remove the panel. (See «CONSOLE REMOVAL/INSTALLATION»(ref-375422-S05218780952010102800000) .)
4. Remove in the order indicated in the table.
5. Install in the reverse order of removal.

Scheme 59

1. Disconnect the negative battery cable.
2. Remove the console panel. (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-375422-S16179305552010102800000) .)
3. Remove the console. (See «CONSOLE REMOVAL/INSTALLATION»(ref-375422-S05218780952010102800000) .)
4. Remove in the order indicated in the table.
5. Install in the reverse order of removal.

Scheme 60

1. Remove the socket in the direction of the arrow (2) shown in the figure while opening the caps in the direction of the arrow (1) using a tape-wrapped fastener remover.

Scheme 61

1. Remove the cap in the direction of the arrow (2) shown in the figure while pressing the cap tabs in the direction of the arrow (1).

Scheme 62

1. Connect a tester as shown in the figure and verify that there is continuity. If the continuity cannot be verified, replace the accessory socket.

Scheme 63

1. Disconnect the negative battery cable.
2. Remove the console panel. (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-375422-S16179305552010102800000) .)
3. Remove the console. (See «CONSOLE REMOVAL/INSTALLATION»(ref-375422-S05218780952010102800000) .)
4. Remove the auxiliary jack in the direction of the arrow (2) shown in the figure while pressing the auxiliary jack tabs in the direction of the arrow (1).
5. Install in the reverse order of removal.

Scheme 64

Scheme 65

1. Disconnect the negative battery cable.
2. Remove the console panel. (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-375422-S16179305552010102800000) .)
3. Remove the console. (See «CONSOLE REMOVAL/INSTALLATION»(ref-375422-S05218780952010102800000) .)
4. Connect a commercially-available nonresistant plug to the auxiliary jack.
5. Verify that the continuity between the auxiliary jack terminals is as indicated in the table. If not as indicated in the table, replace the auxiliary jack.
