Entertainment System: Component Locations Mazda CX-7 I рестайлинг

ANTENNA FEEDER LOCATION

Note. The GPS antenna feeder is integrated with the dashboard wiring harness. The SIRIUS satellite radio antenna feeder is integrated with the rear wiring harness.

Scheme 67

Scheme 68

1. Disconnect the negative battery cable.
2. Remove the following parts: Detraction panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-375422-S00635045162010102800000) .) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-375422-S25498401972010102800000) .) Audio unit (with audio system) (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-375342-S35395625342010102800000) .) Car-navigation unit (without integrated multi information display) (See «CAR-NAVIGATION UNIT REMOVAL/INSTALLATION»(ref-375342-S34523276652010102800000) .) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-375422-S25337417152010102800000) .) A-pillar lower trim (RH) (See «A-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-375422-S07484122802010102800000) .) A-pillar trim (RH) (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S30388225242010102800000) .)
3. Disconnect the antenna feeder NO.2. (See «ANTENNA FEEDER NO.2 REMOVAL/INSTALLATION»(ref-375342-S32114013602010102800000) .)
4. Remove the clips A and B.
5. Remove the antenna feeder No.1.
6. Install in the reverse order of removal.

Scheme 69

1. Disconnect the negative battery cable.
2. Remove the following parts: Detraction panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-375422-S00635045162010102800000) .) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-375422-S25498401972010102800000) .) Audio unit (with audio system) (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-375342-S35395625342010102800000) .) Car-navigation unit (without integrated multi information display) (See «CAR-NAVIGATION UNIT REMOVAL/INSTALLATION»(ref-375342-S34523276652010102800000) .) A-pillar lower trim (RH) (See «A-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-375422-S07484122802010102800000) .) A-pillar trim (RH) (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S30388225242010102800000) .)
3. Disconnect the antenna feeder NO.2.
4. Verify that the continuity between antenna feeder NO.1 terminals is as indicated in the table.

Scheme 70

Scheme 71

Scheme 72

1. If not as indicated in the table, replace antenna feeder NO.1.
