Scheme 411: AUTOMATIC TRANSAXLE LOCATION INDEX [FS5A-EL]

Operation Inspection

Verify that the starter operates only when the ignition switch is turned to the START position with the selector lever in P or N position.
Verify that the back-up lights illuminate when selected to R position with the ignition switch at the ON position.
Verify that the positions of the selector lever and the selector indicator light are aligned. If there is any malfunction, adjust the TR switch. (See «TRANSAXLE RANGE (TR) SWITCH ADJUSTMENT [FS5A-EL]»(ref-375372-S27340109232010102800000) .)

Scheme 412: On-Vehicle Inspection

Disconnect the TR switch connector. Disconnect the negative battery cable. Remove the air cleaner component. (See «INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [L5]»(ref-375352-S14647925242010102800000) .) Disconnect the TR switch connector.
Inspect continuity as indicated in the table. If there is any malfunction, adjust the TR switch. If problem remains, replace the TR switch. (See «TRANSAXLE RANGE (TR) SWITCH REMOVAL/INSTALLATION [FS5A-EL]»(ref-375372-S28265018482010102800000) .)
