Basic System (HVAC): Overview Mazda CX-7 I рестайлинг

Scheme 61

Scheme 62

Scheme 63

Scheme 64

1. Disconnect the negative battery cable.
2. Remove the following parts: Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION».) Console (See «CONSOLE REMOVAL/INSTALLATION».) Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION».) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION».) Dashboard under cover Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION».) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION».) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION».) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION».) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION».) Audio unit (See «AUDIO UNIT REMOVAL/INSTALLATION».) Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]».) (See «CLIMATE CONTROL UNIT REMOVAL [MANUAL AIR CONDITIONER]».) (See «CLIMATE CONTROL UNIT INSTALLATION [MANUAL AIR CONDITIONER]».) Knee bolster (See «KNEE BOLSTER REMOVAL/INSTALLATION».) Meter hood (See «METER HOOD REMOVAL/INSTALLATION».) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION».) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION».) Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION».) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION».) Combination switch (See «COMBINATION SWITCH REMOVAL/INSTALLATION».) Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION».) A-pillar lower trim (See «A-PILLAR LOWER TRIM REMOVAL/INSTALLATION».) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION».) Dashboard (See «DASHBOARD REMOVAL/INSTALLATION».)
3. Remove the blower motor. (See «BLOWER MOTOR REMOVAL/INSTALLATION [MANUAL AIR CONDITIONER]».)
4. Remove the power MOS FET (Full-auto air conditioner) or resistor. (Manual air conditioner) (See «POWER METAL OXIDE SEMICONDUCTOR FIELD EFFECT TRANSISTOR (POWER MOS FET) REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]».) (See «RESISTOR REMOVAL/INSTALLATION [MANUAL AIR CONDITIONER]».)
5. Remove the blower unit installation nuts.
6. Remove the screw securing the duct (2) to the A/C unit, by inserting a phillips screwdriver into the hole made after removing the blower motor.
7. Remove the screw securing the duct (2) to the A/C unit.
8. Remove the duct (2).
9. Remove the blower unit.
10. Temporary install the blower unit.
11. Install in the duct (2).
12. Install the two outer screws, securing the duct (2) to the A/C unit.
13. Install the screw on the end of the phillips screwdriver with the packing tape. CAUTION: If the packing tape remains in the duct (2), it may become a source of noise. Wind up the packing tape to prevent pinching when tightening the screw.
14. Install the duct (2) to the A/C unit by inserting a phillips screwdriver, with the screw, into the hole made after removing the blower motor.
15. Pull out the phillips screwdriver together with the packing tape.
16. Install in the reverse order of removal.

Scheme 65

1. Disassemble in the order indicated in the table. CAUTION: Apply only the specified grease to the link. Otherwise abnormal noise or improper operation may result.
2. Assemble in the reverse order of disassembly.

Scheme 66

Scheme 67

1. Disconnect the negative battery cable.
2. Discharge the refrigerant from the system. (See «REFRIGERANT RECOVERY»(/mazda/cx-7/i-2009-2012/remont/automatic-hvac-system/#refrigerant-system-hvac__refrigerant-recovery) .) (See «REFRIGERANT CHARGING»(/mazda/cx-7/i-2009-2012/remont/automatic-hvac-system/#refrigerant-system-hvac__refrigerant-charging) .)
3. Drain the engine coolant. (See «ENGINE COOLANT REPLACEMENT [L3 WITH TC]».) (See «ENGINE COOLANT REPLACEMENT [L5]».)
4. Remove the following parts: Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION».) Console (See «CONSOLE REMOVAL/INSTALLATION».) Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION».) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION».) Dashboard under cover Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION».) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION».) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION».) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION».) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION».) Audio unit (See «AUDIO UNIT REMOVAL/INSTALLATION».) Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]».) (See «CLIMATE CONTROL UNIT REMOVAL [MANUAL AIR CONDITIONER]».) (See «CLIMATE CONTROL UNIT INSTALLATION [MANUAL AIR CONDITIONER]».) Knee bolster (See «KNEE BOLSTER REMOVAL/INSTALLATION».) Meter hood (See «METER HOOD REMOVAL/INSTALLATION».) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION».) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION».) Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION».) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION».) Combination switch (See «COMBINATION SWITCH REMOVAL/INSTALLATION».) Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION».) A-pillar lower trim (See «A-PILLAR LOWER TRIM REMOVAL/INSTALLATION».) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION».) Dashboard (See «DASHBOARD REMOVAL/INSTALLATION».)
5. Remove in the order indicated in the table. Do not allow compressor oil to spill.
6. Install in the reverse order of removal.
7. Perform the refrigerant system performance test. (See «REFRIGERANT SYSTEM PERFORMANCE TEST»(/mazda/cx-7/i-2009-2012/remont/automatic-hvac-system/#refrigerant-system-hvac) .)
