Dynamic Stability Control: Removal & Installation Mazda CX-7 I рестайлинг

DSC HU/CM REMOVAL/INSTALLATION

Scheme 27

Scheme 28

1. Remove the battery and battery tray. (See «BATTERY REMOVAL/INSTALLATION [L3 WITH TC]»(ref-375338-S37461824502010102800000) .) (See «BATTERY REMOVAL/INSTALLATION [L5]»(ref-375359-S31806842452010102800000) .)
2. Remove the battery tray bracket as shown in the figure.
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.
5. After installation, add brake fluid, bleed the air, and inspect for fluid leakage. (See «AIR BLEEDING»(ref-375339-S29185173622010102800000) .)
6. After installation, perform the following procedures: DSC configuration (See «DSC CONFIGURATION»(ref-375420-S26152068232010102800000) .) Combined sensor initialization procedure (See «DSC SENSOR INITIALIZATION PROCEDURE»(ref-375420-S09483054452010102800000) .) Steering angle sensor initialization procedure (See «STEERING ANGLE SENSOR INITIALIZATION PROCEDURE»(ref-375320-S27923995692010102800000) .)

Scheme 29

1. Pull the lock lever up in the direction of the arrow.
2. Pull the connector toward the vehicle rear and remove it.

Scheme 30

1. Place an alignment mark on the brake pipe and DSC HU/CM.
2. Apply protective tape to the connector to prevent brake fluid from entering.
3. Remove the brake pipe.

Scheme 31

1. Install the rubber mount on DSC HU/CM section A to the bracket as shown in the figure.
2. Install DSC HU/CM section B to the bracket.
3. Install the nuts to DSC HU/CM section A and tighten them.

Scheme 32

1. Align the marks made before removal and install the brake pipe to the DSC HU/CM and brake pipe joint referring to the figure.
2. Tighten the brake pipe to the specified torque using the commercially available flare nut wrench.

Scheme 33

1. After connecting the connector, verify that the lock lever is completely pushed in.

COMBINED SENSOR REMOVAL/INSTALLATION

Scheme 34

1. Remove the console panel. (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-375422-S16179305552010102800000) .)
2. Remove the console. (See «CONSOLE REMOVAL/INSTALLATION»(ref-375422-S05218780952010102800000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.
5. After installation, perform the combined sensor initialization procedure. (See «DSC SENSOR INITIALIZATION PROCEDURE»(ref-375420-S09483054452010102800000) .)

Scheme 35

Scheme 36

1. Turn the ignition switch to the LOCK position.
2. Connect the M-MDS to the DLC-2.
3. Select the following PIDs, then inspect the lateral acceleration speed and the yaw rate. LAT_ACCL: (lateral acceleration speed) YAW_RATE: (yaw rate) Lateral acceleration speed inspection Verify the LAT_ACCL change when the combined sensor is tilted to the left and right. If there is any malfunction, replace the combined sensor. Standard When the sensor is tilted to the right (A): LAT_ACCL changes negatively. When the sensor is tilted to the left (B): LAT_ACCL changes positively. Yaw rate inspection Verify the YAW_RATE change when the combined sensor is rotated to the left and right. If there is any malfunction, replace the combined sensor. Standard When the sensor is rotated to the right (A): YAW_RATE changes negatively. When the sensor is rotated to the left (B): YAW_RATE changes positively.

Switch Bezel Component Removal Note

1. Access the switch bezel component from behind of the dashboard, and squeeze the tabs of the switch bezel component.
2. Remove the switch bezel component from the dashboard.

Scheme 37

Scheme 38

1. Remove the TCS OFF switch. (See «TCS OFF SWITCH REMOVAL/INSTALLATION»(ref-375420-S14558167462010102800000) .)
2. Verify that the continuity is as indicated in the table. If not as indicated in the table, replace the TCS OFF switch.
