Body control modules — Dash-electrical supply unit circuit Mazda CX-50 I
All systems — 33 systems
- Air conditioning
- Anti-lock brakes
- Anti-theft 2
- Body control modules 3
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers
- Electronic power steering
- Engine performance 2.5l skyactiv
- Engine performance 2.5l turbo skyactiv
- Exterior lights 3
- Ground distribution
- Headlights 2
- Horn
- Instrument cluster 2
- Interior lights 2
- Memory systems 2
- Navigation 7
- Power distribution
- Power door locks
- Power mirrors 2
- Power seats 6
- Power top/sunroof
- Power windows
- Radio 2
- Shift interlock 2
- Starting/charging 2
- Supplemental restraints
- Transmission 2
- Trunk, tailgate, fuel door 2
- Warning systems
- Wiper/washer 2
Components on these wiring diagrams 18
Click a component to highlight it on every diagram it appears on.
