PCM Connector Connection Note

Identifying Proper And Improper PCM Connector Insertion Position. Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

1. Set the PCM connector to the position shown in the figure. (Scheme 62): Identifying PCM Connector Position
2. Align the PCM connector straight against the connection surface. (Scheme 63): Aligning PCM Connector Straight Against Connection Surface
3. Insert the PCM connector straight and press it in until the lever moves up naturally. (Front harness-side connector) (Scheme 64): Pressing PCM Connector
4. Press the PCM connector lever until a click sound is heard. (Scheme 65): Pressing PCM Connector Lever

Without Using the M-MDS

Note. Because the PCM uses a waterproof connector, the inspection for the voltage/wave pattern cannot be performed. The following values are for reference.

PCM Terminal Voltage Chart (Without Using M-MDS). Scheme 66

Electric variable valve timing motor (rotation direction) signal

PCM terminals

1. 1J(+)-body ground(-)

Oscilloscope setting

1. 2 V/DIV (Y), 5 ms/DIV (X), DC range

Vehicle condition

1. Idle (after warm up)

Electric Variable Valve Timing Motor (Rotation Direction) Signal Blinking Pattern. Scheme 67

PCM terminals

1. 1O(+)-body ground(-)

Oscilloscope setting

1. 2 V/DIV (Y), 5 ms/DIV (X), DC range

Vehicle condition

Scheme 68

1. Idle (after warm up) (Scheme 68): Electric Variable Valve Timing Motor (Rotation Pulse) Signal Blinking Pattern

Exhaust CMP signal

PCM terminals

1. 1T(+)-body ground(-)

Oscilloscope setting

1. 2 V/DIV (Y), 20 ms/DIV (X), DC range

Vehicle condition

Scheme 69

1. Idle (after warm up) (Scheme 69): Exhaust CMP Signal Blinking Pattern

Intake CMP signal

PCM terminals

1. 1Y(+)-body ground(-)

Oscilloscope setting

1. 2 V/DIV (Y), 20 ms/DIV (X), DC range

Vehicle condition

1. Idle (after warm up) see scheme 22: Intake CMP Signal Blinking Pattern

CKP signal

PCM terminals

1. 1AD(+)-body ground(-)

Oscilloscope setting

1. 2 V/DIV (Y), 1 ms/DIV (X), DC range

Vehicle condition

Scheme 70

1. Idle (after warm up) (Scheme 70): CKP Signal Blinking Pattern

Generator output voltage

PCM terminals

1. 1AF(+)-body ground(-)

Oscilloscope setting

1. 5 V/DIV (Y), 2 ms/DIV (X), DC range

Vehicle condition

Scheme 71

1. Idle after warm up (Scheme 71): Generator Output Voltage Blinking Pattern

Purge control

PCM terminals

1. 1AI(+)-body ground(-)

Oscilloscope setting

1. 10 V/DIV (Y), 50 ms/DIV (X), DC range

Vehicle condition

Scheme 72

1. Idle after warm up (Scheme 72): Purge Control Signal Blinking Pattern

IGT1, IGT2, IGT3, IGT4 control

PCM terminals

1. IGT1 (ignition coil No.1): 1AY(+)-body ground(-)
2. IGT2 (ignition coil No.2): 1AT(+)-body ground(-)
3. IGT3 (ignition coil No.3): 1AO(+)-body ground(-)
4. IGT4 (ignition coil No.4): 1AJ(+)-body ground(-)

Oscilloscope setting

1. 2 V/DIV (Y), 20 ms/DIV (X), DC range

Vehicle condition

Scheme 73

1. Idle after warm up (Scheme 73): IGT1, IGT2, IGT3, IGT4 Control Signal Blinking Pattern

Hydraulic variable valve timing control signal

PCM terminals

1. 1AN(+)-body ground(-)

Oscilloscope setting

1. 5 V/DIV (Y), 1 ms/DIV (X), DC range

Vehicle condition

Scheme 74

1. Idle after warm up (Scheme 74): Hydraulic Variable Valve Timing Control Signal Blinking Pattern

Engine oil control signal

PCM terminals

1. 1AS(+)-body ground(-)

Oscilloscope setting

1. 5 V/DIV (Y), 1 ms/DIV (X), DC range

Vehicle condition

Scheme 75

1. Idle after warm up (Scheme 75): Engine Oil Control Signal Blinking Pattern

Electric variable valve timing control signal

PCM terminals

1. 1AZ(+)-body ground(-)

Oscilloscope setting

1. 2 V/DIV (Y), 2 ms/DIV (X), DC range

Vehicle condition

Scheme 76

1. Idle after warm up (Scheme 76): Electric Variable Valve Timing Control Signal Blinking Pattern

Generator field coil control signal

PCM terminals

1. 1BE(+)-body ground(-)

Oscilloscope setting

1. 1 V/DIV (Y), 2 ms/DIV (X), DC range

Vehicle condition

Scheme 77

1. Idle after warm up (Scheme 77): Generator Field Coil Control Signal Blinking Pattern

A/F sensor heater control signal

PCM terminals

1. 1BY(+)-body ground(-)

Oscilloscope setting

1. 5 V/DIV (Y), 50 ms/DIV (X), DC range

Vehicle condition

Scheme 78

1. Idle after warm up (Scheme 78): A/F Sensor Heater Control Signal Blinking Pattern

Drive-by-wire control (+) signal

PCM terminals

1. 1CG(+)-body ground(-)

Oscilloscope setting

1. 5 V/DIV (Y), 1 ms/DIV (X), DC range

Vehicle condition

Scheme 79

1. Idle after warm up (Scheme 79): Drive-By-Wire Control (+) Signal Blinking Pattern

Fuel injection control (-) signal

PCM terminals

1. Fuel Injection No.1: 1DO(+)-body ground(-)
2. Fuel Injection No.2: 1DW(+)-body ground(-)
3. Fuel Injection No.3: 1EA(+)-body ground(-)
4. Fuel Injection No.4: 1DS(+)-body ground(-)

Oscilloscope setting

1. 10 V/DIV (Y), 5 ms/DIV (X), DC range

Vehicle condition

Scheme 80

1. Idle after warm up (Scheme 80): Fuel Injection Control (-) Signal Blinking Pattern

Fuel injection control (+) signal

PCM terminals

1. Fuel Injection No.1: 1DP(+)-body ground(-)
2. Fuel Injection No.2: 1DX(+)-body ground(-)
3. Fuel Injection No.3: 1EB(+)-body ground(-)
4. Fuel Injection No.4: 1DT(+)-body ground(-)

Oscilloscope setting

1. 10 V/DIV (Y), 5 ms/DIV (X), DC range

Vehicle condition

Scheme 81

1. Idle after warm up (Scheme 81): Fuel Injection Control (+) Signal Blinking Pattern

High pressure fuel pump control (+) signal

PCM terminals

1. 1 EE(+)-body ground(-)

Oscilloscope setting

1. 10 V/DIV (Y), 5 ms/DIV (X), DC range

Vehicle condition

Scheme 82

1. Idle after warm up (Scheme 82): High Pressure Fuel Pump Control (+) Signal Blinking Pattern

High pressure fuel pump control (-) signal

PCM terminals

1. 1EF(+)-body ground(-)

Oscilloscope setting

1. 10 V/DIV (Y), 5 ms/DIV (X), DC range

Vehicle condition

Scheme 83

1. Idle after warm up (Scheme 83): High Pressure Fuel Pump Control (-) Signal Blinking Pattern

HO2S heater control signal

PCM terminals

1. 2C(+)-body ground(-)

Oscilloscope setting

1. 5 V/DIV (Y), 50 ms/DIV (X), DC range

Vehicle condition

Scheme 84

1. Idle (immediately after starting the engine) (Scheme 84): HO2S Heater Control Signal Blinking Pattern

Fuel pump control signal

PCM terminals

1. 2AE(+)-body ground(-)

Oscilloscope setting

1. 5 V/DIV (Y), 2 ms/DIV (X), DC range

Vehicle condition

Scheme 85

1. Idle after warm up (Scheme 85): Fuel Pump Control Signal Blinking Pattern

Using The M-MDS

Note. PIDs for the following parts are not available on this model. Go to the appropriate part inspection page. Intake CMP sensor and Exhaust CMP sensor (See CAMSHAFT POSITION (CMP) SENSOR INSPECTION [SKYACTIV-G 2.0] ). Main relay (See RELAY INSPECTION ).

1. Connect the M-MDS to the DLC-2.
2. Switch the ignition ON.
3. Measure the PID value. If PID value is not within the specification, follow the instructions in Action column. NOTE: The PID/DATA MONITOR function monitors the calculated value of the input/output signals in the PCM. Therefore, an output device malfunction is not directly indicated as a malfunction of the monitored value for the output device. If a monitored value of an output device is out of specification, inspect the monitored value of the input device related to the output control. The simulation items that are used in the ENGINE CONTROL SYSTEM OPERATION INSPECTION are as follows. ACCS, ALTF, ARPMDES, EVAPCP, EVAPCV, FAN1, FAN3, FP, INJ_1, INJ_2, INJ_3, INJ_4, OIL_P_SOL, Test, VT EX_DES

PCM CONFIGURATION (USING READ/WRITE FUNCTION) [SKYACTIV-G 2.0]

Note. When performing configuration, it is necessary to read the vehicle specification information from the PCM before replacing it. Connect the M-MDS to the vehicle and perform vehicle identification before removing the PCM. The vehicle specification information is temporarily stored in the M-MDS.

1. Connect the M-MDS to the DLC-2.
2. After the vehicle is identified, select the following items from the initialization screen of the M-MDS. Select "Module Programming".
3. Then, select items from the screen menu in the following order. Select "Programmable Module Installation". Select "PCM".
4. Perform the configuration according to the directions on the screen. CAUTION: When the configuration is performed, CAN communication between the PCM and control module connected to the CAN line is cut temporarily, and communication error DTCs may be detected. After performing the configuration, verify the DTCs for the control module connected to the CAN line and clear it if any DTC is detected.
5. Verify the DTCs for all of the control modules connected to the CAN line. If any DTC is stored, clear it. If the DTC is cleared, finish the procedure because the configuration has been completed normally. If the DTC remains, perform troubleshooting according to the DTC.

PCM CONFIGURATION (USING AS-BUILT DATA) [SKYACTIV-G 2.0]

Note. If the configuration is performed using As-Built data, the set value of the personalization function is reset to the initial value (condition when shipped from factory). Verify the set value with the customer and perform the personalization function setting after performing the configuration using As-Built data.

1. Connect the M-MDS to the DLC-2.
2. After the vehicle is identified, select the following items from the initialization screen of the M-MDS. Select "Module Programming".
3. Then, select items from the screen menu in the following order. Select "As-Built". Select "PCM".
4. Perform the configuration according to the directions on the screen. CAUTION: When the configuration is performed, CAN communication between the PCM and control module connected to the CAN line is cut temporarily, and communication error DTCs may be detected. After performing the configuration, verify the DTCs for the control module connected to the CAN line and clear it if any DTC is detected.
5. Verify the DTCs for all of the control modules connected to the CAN line. If any DTC is stored, clear it. If the DTC is cleared, finish the procedure because the configuration has been completed normally. If the DTC remains, perform troubleshooting according to the DTC.

Scheme 86

1. Verify that the CPP switch is installed properly. (See «CLUTCH PEDAL POSITION SWITCH REMOVAL/INSTALLATION [C66M-R]»(ref-615414-S37439655452014051000000) ).
2. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
3. Disconnect the CPP switch connector.
4. Verify that the continuity between CPP switch terminals A and B when the clutch pedal is depressed and when it is released is according to the following table: If not as verified, replace the CPP switch. (See «CLUTCH PEDAL POSITION SWITCH REMOVAL/INSTALLATION [C66M-R]»(ref-615414-S37439655452014051000000) ). (Scheme 86): Identifying CPP Switch With Rod And Connector

ECT Sensor No.2

1. Remove the ECT sensor No.2. (See «ENGINE COOLANT TEMPERATURE (ECT) SENSOR REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-615396-S17600882762014051000000) ).
2. Place the ECT sensor No.2 in water with a thermometer, and heat the water gradually. see scheme 51: Measuring ECT Sensor No.1 Temperature Using Thermometer
3. Measure the resistance between ECT sensor No.2 terminals A and B. If not as specified, replace the ECT sensor No.2. (See «ENGINE COOLANT TEMPERATURE (ECT) SENSOR REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-615396-S17600882762014051000000) ).

RESISTANCE SPECIFICATION
