Interior Trim: Removal & Installation Mazda CX-5 I

FRONT CONSOLE REMOVAL/INSTALLATION

Protective Tape Application Area On Front Console. Scheme 71

Scheme 72

Scheme 73

Scheme 74

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the following parts: Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-615455-S15150991172014051000000) ). Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-615440-S42122392892014051000000) ). Front console box (See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-615455-S42371732362014051000000) ). Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-615455-S00421900212014051000000) ). Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-615455-S24596820212014051000000) ). Rear console (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-615455-S26190969372014051000000) ). Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-615455-S29263037032014051000000) ).
3. Take the shaded area shown in the figure, and remove the front console in the direction of the arrow in the order of (1), (2), (3), (4) while detaching clips A, clips B, hooks C, guides D. (Scheme 72): Removing Front Console
4. Disconnect the front accessory socket connector.
5. Pull the front console in the direction of the arrow in the order of (5), (6) and remove the front console while detaching the selector lever (ATX) or shift lever (MTX). ATX (Scheme 73): Removing Front Console (ATX) MTX (Scheme 74): Removing Front Console (MTX)
6. Install in the reverse order of removal.

Scheme 75

Scheme 76

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the car-navigation unit, (with car-navigation system) (See «CAR-NAVIGATION UNIT REMOVAL/INSTALLATION»(ref-615447-S38762066702014051000000) ).
3. Insert your hand from the lower side of the lower panel (without car-navigation system) or the area where the car-navigation unit was installed (with car-navigation system), press the switch panel in the direction of the arrow (1) shown in the figure and remove it while detaching hook A and B and hook C. (Scheme 75): Removing Car-Navigation Unit
4. Disconnect the cluster switch connector.
5. Remove the cluster switch in the direction of the arrow (3) while detaching hooks D in the direction of the arrow (2). (Scheme 76): Removing Cluster Switch
6. Install in the reverse order of removal.

Scheme 77

1. Remove fasteners. (Scheme 77): Identifying Trunk Covering With Fasteners
2. Remove the trunk covering.
3. Install in the reverse order of removal.

Scheme 78

Scheme 79

1. Insert a tape-wrapped flathead screwdriver in the position indicated by the arrow in the figure and detach hooks A. (Scheme 78): Removing Liftgate Recess Using Tape-Wrapped Flathead Screwdriver
2. Remove the liftgate recess in the direction of the arrow shown in the figure avoiding hooks B. (Scheme 79): Removing Liftgate Recess
3. Install in the reverse order of removal.

Scheme 80

Scheme 81

Scheme 82

1. Pull down the steering wheel.
2. Press the shaded area shown in the figure using your thumb, and lift the upper column cover in the direction of arrow (1). (Scheme 80): Pulling Upper Column Cover
3. Pull the upper column cover in the direction of the arrow (2) and remove it while detaching pins A, tabs B and guides C.
4. Remove hooks D from the meter hood. CAUTION: If the cover of the meter hood is deformed, it may not return to its original condition. When removing the cover of the meter hood, detach hooks D one by one from the upper column cover. (Scheme 81): Identifying Meter Hood And Hook
5. Pull up the steering wheel.
6. Remove screws E. (Scheme 82): Pulling Up Steering Wheel
7. Remove the lower column cover in the direction of the arrow (4), (5) set the adjusting lever aside while keeping it open in the direction of the arrow (3) shown in the figure.
8. Install in the reverse order of removal.

Scheme 83

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-615455-S15150991172014051000000) ).
3. Take the shaded area shown in the figure, and pull the center panel in the direction of the arrow in the order of (1), (2), (3), (4) and remove it while detaching clips A, pins B and hooks C. (Scheme 83): Removing Center Panel
4. Install in the reverse order of removal.

Scheme 84

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the following parts: Driver-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-615455-S15598834492014051000000) ). Driver-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-615455-S14137250292014051000000) ). Switch panel (See «SWITCH PANEL REMOVAL/INSTALLATION»(ref-615455-S35661694702014051000000) ). Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-615455-S15150991172014051000000) ). Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-615440-S42122392892014051000000) ). Front console box (See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-615455-S42371732362014051000000) ). Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-615455-S00421900212014051000000) ). Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-615455-S24596820212014051000000) ). Rear console (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-615455-S26190969372014051000000) ). Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-615455-S29263037032014051000000) ). Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-615455-S37957878882014051000000) ). Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-615426-S03763202762014051000000) ).
3. Remove the screw A. (Scheme 84): Removing Lower Panel (Driver-Side)
4. Take the shaded area shown in the figure, and pull the driver-side lower panel in the direction of the arrow in the order of (1), (2), (3),(4) and remove it while detaching clips B, hooks C and pins D.
5. Disconnect the car-navigation unit connector, (with car-navigation system)
6. Install in the reverse order of removal.

Scheme 85

Scheme 86

1. Disconnect the negative battery cable.
2. Remove the following parts: Passenger-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-615455-S15598834492014051000000) ). Passenger-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-615455-S14137250292014051000000) ). Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-615455-S15366383852014051000000) ). Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-615455-S15150991172014051000000) ). Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-615455-S39827127492014051000000) ).
3. Remove bolts A.
4. Remove screws B. (Scheme 85): Removing Lower Panel (Passenger-Side)
5. Take the shaded area shown in the figure, and pull the passenger-side lower panel in the direction of the arrow in the order of (1), (2), (3) and remove it while detaching hooks C, clips D and pins E. (Scheme 86): Pulling Passenger-Side Lower Panel

Scheme 87

Scheme 88

Scheme 89

1. Install hooks C, clips D, and pins E while pressing the shaded area shown in the figure for the passenger-side lower panel in the direction of the arrow in the order of (1), (2), and (3). (Scheme 87): Installing Passenger-Side Lower Panel
2. Install screws B.
3. Install bolts A, and then install the passenger-side lower panel. (Scheme 88): Passenger-Side Lower Panel Bolts And Screws With Torque Specifications
4. Install the following parts: Dashboard undercover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-615455-S39827127492014051000000) ). Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-615455-S15150991172014051000000) ). Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-615455-S15366383852014051000000) ). Passenger-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-615455-S14137250292014051000000) ). Passenger-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-615455-S15598834492014051000000) ).
5. Connect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
6. After installing the passenger-side lower panel and glove compartment, measure the clearance, and verify that the measurement value is within the specification shown in the figure. If the measurement value is not within the specification after measuring the clearance between the passenger-side lower panel and glove compartment, adjust the passenger-side lower panel to the proper position. (See «PASSENGER-SIDE LOWER PANEL ADJUSTMENT»(ref-615455-S03486917152014051000000) ). (Scheme 89): Identifying Clearance Between Passenger-Side Lower Panel And Glove Compartment

Scheme 90

Scheme 91

Scheme 92

1. Remove the grove compartment. (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-615455-S15366383852014051000000) )
2. Loosen bolts A. If the passenger-side lower panel moves in the lateral direction when bolts A are loosened, go to the step 3 and 4. If the passenger-side lower panel does not move in the lateral direction when bolts A are loosened, go to the step 5. (Scheme 90): Identifying Passenger-Side Lower Panel With Bolts
3. Remove bolts A.
4. Install bolts A in the order of (1), (2) shown in the figure. (Scheme 91): Identifying Passenger-Side Lower Panel With Bolts And Torque Specifications
5. Install bolts A in the order of (1) and (2) while pressing the shaded area shown in the figure for the passenger-side lower panel. (Scheme 92): Identifying Passenger-Side Lower Panel With Bolts And Torque Specifications
6. Install the glove compartment, measure the clearance between the glove compartment and passenger-side lower panel again, and verify that it is within the specification. If it is not within the specification after measuring the clearance, repeat the adjustment procedure from Step 1.

Scheme 93

Scheme 94

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the upper column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-615455-S35240345352014051000000) ).
3. Using a phillips screwdriver, remove fasteners. NOTE: When pulling up the shaft of fasteners using a phillips screwdriver, the shaft will not be pulled up if it is rotated by pressing the driver. To pull up the shaft of fastener, use the phillips screwdriver to lightly contact fasteners. (Scheme 93): Identifying Meter Hood And Fasteners
4. Take the shaded area shown in the figure, and remove the meter hood in the direction of the arrow in the order of (1), (2) while detaching the clips A, pins B. (Scheme 94): Removing Meter Hood
5. Disconnect the start switch connector
6. Install in the reverse order of removal.

Scheme 95

Scheme 96

Scheme 97

1. Push the glove compartment in the direction of the arrow (1) and remove hooks A. (Scheme 95): Pushing Glove Compartment
2. Pull the stay damper in the direction of the arrow (2) shown in the figure and remove the hook B. CAUTION: If the glove compartment is closed without being joined to the stay damper, the stay damper may be damaged. Verify that the stay damper is joined to the glove compartment before closing the glove compartment. (Scheme 96): Removing Stay Damper
3. Pull down the glove compartment in the direction of the arrow (3). (Scheme 97): Removing Glove Compartment
4. Pull the glove compartment in the direction of the arrow (4) and remove it while detaching hooks C.
5. Install in the reverse order of removal.

Scheme 98

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the switch panel. (See «SWITCH PANEL REMOVAL/INSTALLATION»(ref-615455-S35661694702014051000000) ).
3. Insert your hand from the area where the switch panel was installed, remove the side ventilator grille in the direction of the arrow shown in the figure while detaching hooks A. (Scheme 98): Removing Side Ventilator Grille (Driver-Side)
4. Install in the reverse order of removal.

Scheme 99

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Open the glove compartment.
3. Remove the glove compartment. (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-615455-S15366383852014051000000) ).
4. Insert your hand from the area where the glove compartment was installed, remove the side ventilator grille in the direction of the arrow shown in the figure while detaching hooks B. (Scheme 99): Removing Side Ventilator Grille (Passenger-Side)
5. Install in the reverse order of removal.

Scheme 100

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the decoration panel. (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-615455-S15150991172014051000000) ).
3. Push the edge of center ventilator grille in the direction of arrow (1) and detach hooks C. (Scheme 100): Removing Decoration Panel
4. Remove the center ventilator grille in the direction of arrow (2) shown in the figure.
5. Install in the reverse order of removal.

Scheme 101

Scheme 102

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the following parts: Driver-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-615455-S15598834492014051000000) ). Driver-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-615455-S14137250292014051000000) ). Switch panel (See «SWITCH PANEL REMOVAL/INSTALLATION»(ref-615455-S35661694702014051000000) ). Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-615455-S15150991172014051000000) ). Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-615440-S42122392892014051000000) ). Front console box (See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-615455-S42371732362014051000000) ). Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-615455-S00421900212014051000000) ). Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-615455-S24596820212014051000000) ). Rear console (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-615455-S26190969372014051000000) ). Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-615455-S29263037032014051000000) ). Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-615455-S37957878882014051000000) ). Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-615426-S03763202762014051000000) ). Driver-side lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-615455-S27517637452014051000000) ).
3. Remove bolts. (Scheme 101): Identifying Knee Bolster With Bolts And Torque Specifications
4. Pull the knee bolster in the direction of the arrow in the order of (1), (2) while detaching tabs. (Scheme 102): Pulling Knee Bolster
5. Install in the reverse order of removal.

Scheme 103

1. Pull the side wall in the direction of the arrow in the order of (1), (2) and remove it while detaching hooks A and clip B. (Scheme 103): Pulling Side Wall
2. Pull the side wall in the direction of the arrow (3) and remove it while detaching the guide C. CAUTION: If the hooks A and clip B is removed forcefully, guide C may be damaged. Carefully remove hooks A and clip B so as not to damage guide C.
3. Install in the reverse order of removal.

Scheme 104

1. Detach hooks A in the direction of arrow (1) shown in the figure. (Scheme 104): Removing Dashboard Under Cover
2. Pull the dashboard under cover in the direction of arrow (2) while detaching pins B.
3. Remove the dashboard under cover in the direction of the arrow (3) shown in the figure while detaching the guide C. CAUTION: If hooks A and pins B is removed forcefully, guide C may be damaged. Carefully remove hooks A and pins B so as not to damage guide C.
4. Install in the reverse order of removal.

Scheme 105

Scheme 106

Scheme 107

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the following parts: Front console box (See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-615455-S42371732362014051000000) ). Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-615440-S42122392892014051000000) ). Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-615455-S00421900212014051000000) ).
3. Open the console lid.
4. Remove the button, then open the fastener.
5. Take the shaded area shown in the figure, and remove the upper panel in the direction of the arrow in the order of (1), (2) while detaching clips A, pin B, hooks C. (Scheme 105): Identifying Button And Fasteners (Scheme 106): Removing Upper Panel
6. Remove clips D.
7. Install in the reverse order of removal. (Scheme 107): Identifying Upper Panel With Clip

Scheme 108

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Selector lever to neutral position.
3. Remove the front console box. (See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-615455-S42371732362014051000000) ).
4. Take the shaded area shown in the figure, and remove the shift panel in the direction of the arrow in the order of (1), (2) while detaching clips A, hook B. (Scheme 108): Removing Shift Panel (ATX)
5. Disconnect the connector.
6. Install in the reverse order of removal.

Scheme 109

1. Remove the front console box. (See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-615455-S42371732362014051000000) ).
2. Remove the shift lever knob. (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-615440-S42122392892014051000000) ).
3. Take the shaded area shown in the figure, and remove the shift panel in the direction of the arrow in the order of (1), (2) while detaching clips A, pin B, hook C. (Scheme 109): Removing Shift Panel (MTX)
4. Install in the reverse order of removal.

FRONT CONSOLE BOX REMOVAL/INSTALLATION

Note. Affix protective tape to the position shown in the figure.

Identifying Front Console Box With Protective Tape And Shift Panel. Scheme 110

Scheme 111

Scheme 112

1. Insert a tape-wrapped flathead screwdriver in the position indicated by the arrow in the figure and detach clips A. (Scheme 111): Removing Front Console Box
2. Pull the front console box in the direction of the arrow (2) and remove it while detaching the guides B. (Scheme 112): Pulling Front Console Box NOTE: When the occur to gap between the front console box and shift panel, remove the shift panel then assemble to the front console box. after install the front console box and shift panel as single unit.
3. Install in the reverse order of removal.

Scheme 113

Scheme 114

Scheme 115

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the following parts: Front console box (See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-615455-S42371732362014051000000) ). Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-615440-S42122392892014051000000) ). Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-615455-S00421900212014051000000) ). Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-615455-S24596820212014051000000) ).
3. Remove screws A. (Scheme 113): Identifying Rear Console With Screw And Cap
4. Remove caps B, then remove screws C.
5. Pull the rear console in the direction of the arrow (1) while detaching clips D. (Scheme 114): Pulling Rear Console
6. Disconnect the center accessory socket connector and auxiliary jack/USB port connector.
7. Remove the rear console in the direction of the arrow in the order of (2), (3), (4), (5) shown in the figure. (Scheme 115): Removing Rear Console
8. Install in the reverse order of removal.

Scheme 116

1. Disassemble in the order indicated in the table. (Scheme 116): Disassembled Rear Console
2. Assemble in the reverse order of disassembly.

DECORATION PANEL REMOVAL/INSTALLATION

Identifying Protective Tape Applying Area On Decoration Panel. Scheme 117

Scheme 118

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Open the glove compartment.
3. Insert a tape-wrapped flathead screwdriver in the position indicated by the arrow (1) in the figure and detach clip A. (Scheme 118): Removing Decoration Panel
4. Take the shaded area shown in the figure, and remove the decoration panel in the direction of the arrow in the order of (2), (3), (4) while detaching clips B, clips C.
5. Disconnect the hazard switch connector.
6. Install in the reverse order of removal.

Scheme 119

Scheme 120

Scheme 121

Scheme 122

1. Partially peel back the seaming welt.
2. Take the shaded area shown in the figure, and pull the A-pillar trim in the direction of the arrow (1) while detaching clip A, clips B. (Scheme 119): Removing A-Pillar Trim
3. Cut the lead wire connecting clips B and grommet using a nipper. (Scheme 120): Identifying A-Pillar Trim, Grommet, Lead Wire Nipper
4. Pull the A-pillar trim in the direction of the arrow in the order of (2) and remove the A-pillar trim while detaching guides C. (Scheme 121): Removing A-Pillar Trim
5. Move the hook in the direction of arrows (3) and (4) shown in the figure using a tape-wrapped flathead screwdriver and detach it from the front pillar inner panel. (Scheme 122): Moving Hook Using Tape-Wrapped Flathead Screwdriver
6. Remove the grommet in the direction of the arrow (5) shown in the figure.
7. When installing the A-pillar, install new clips B and grommet to the A-pillar trim in advance.
8. Install in the reverse order of removal.

Scheme 123

1. Remove the front scuff plate. (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-615455-S15598834492014051000000) ).
2. Remove the rear scuff plate. (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-615455-S30956965972014051000000) ).
3. Partially peel back the seaming welt.
4. Take the shaded area shown in the figure, and pull the B-pillar lower trim in the direction of the arrow in the order of (1), (2) while detaching hooks A, pins B. (Scheme 123): Pulling B-Pillar Lower Trim
5. Take the shaded area shown in the figure, and pull the B-pillar lower trim in the direction of the arrow (3) while detaching the clips C, pin D, pin E.
6. Install in the reverse order of removal.

Scheme 124

1. Remove the following parts: Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-615455-S15598834492014051000000) ). Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-615455-S30956965972014051000000) ). B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-615455-S28493908822014051000000) ). Adjuster anchor cover (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-615482-S42598094432014051000000) ). Upper anchor installation bolts on the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-615482-S42598094432014051000000) ).
2. Partially peel back the seaming welt.
3. Take the shaded area shown in the figure, and pull the B-pillar upper trim in the direction of the arrow (1) while detaching clips A, pin B, pin C. (Scheme 124): Pulling B-Pillar Upper Trim
4. Remove the B-pillar upper trim in the direction of the arrow (2) shown in the figure while detaching the guide D. CAUTION: If clips A, pin B and pin C is removed forcefully, guide D may be damaged. Carefully remove clips A, pin B and pin C so as not to damage guide D.
5. Install in the reverse order of removal.

Scheme 125

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the following parts: Trunk board (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-615455-S29131302172014051000000) ). Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-615455-S40973116952014051000000) ). Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-615455-S30956965972014051000000) ). Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-615455-S22359050062014051000000) ). D-pillar trim (See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-615455-S20578915672014051000000) ).
3. Partially peel back the seaming welt.
4. Remove the fastener A. (Scheme 125): Removing C-Pillar Trim
5. Take the shaded area shown in the figure, and pull the C-pillar trim in the direction of the arrow (1) while detaching the pin B.
6. Remove the C-pillar trim in the direction of the arrow (2) shown in the figure while detaching guide C, tabs D. CAUTION: If the C-pillar trim is pulled in the direction of the arrow (1) forcefully, guide C may be damaged. Carefully pull the C-pillar trim so as not to damage guide C.
7. Install in the reverse order of removal.

Scheme 126

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the following parts: Trunk board (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-615455-S29131302172014051000000) ). Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-615455-S40973116952014051000000) ). Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-615455-S30956965972014051000000) ). Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-615455-S22359050062014051000000) ).
3. Take the shaded area shown in the figure, and remove the D-pillar trim in the direction of the arrow in the order of (1), (2), (3) while detaching clips A, pins B. (Scheme 126): Removing D-Pillar Trim
4. Pull the D-pillar trim in the direction of the arrow (4) and remove the D-pillar trim while detaching the guide C.
5. Install in the reverse order of removal.

Scheme 127

1. Take the shaded area shown in the figure, detach tab A while pulling the front scuff plate in the direction of the arrow (1) shown in the figure, then detach the hook B, clip C, and pin D while pulling in the direction of the arrow (2).
2. Take the shaded area shown in the figure, detach tab E while pulling the front scuff plate in the direction of the arrow (3) shown in the figure, then detach the hook F, clip G and pin H while pulling in the direction of the arrow (4). (Scheme 127): Pulling Front Scuff Plate
3. Install in the reverse order of removal.

Scheme 128

1. Take the shaded area shown in the figure, detach tab A while pulling the rear scuff plate in the direction of the arrow (1) shown in the figure, then detach hook B, clips C, pins D while pulling in the direction of the arrow (2).
2. Take the shaded area shown in the figure, detach tab E while pulling the rear scuff plate in the direction of the arrow (3) shown in the figure, then detach the hook F while pulling in the direction of the arrow (4). (Scheme 128): Pulling Rear Scuff Plate
3. Install in the reverse order of removal.

Scheme 129

1. Remove the front scuff plate. (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-615455-S15598834492014051000000) ).
2. Partially peel back the seaming welt.
3. Remove the cap nut. (Scheme 129): Removing Front Side Trim
4. Pull the front side trim in the direction of the arrow shown in the figure and remove it while detaching the clip.
5. Install in the reverse order of removal.

Scheme 130

1. Take the shaded area shown in the figure, and pull the inner garnish in the direction of the arrow (1) while detaching clips A. (Scheme 130): Removing Inner Garnish
2. Take the shaded area shown in the figure, and remove the inner garnish in the direction of the arrow (2) while detaching pins B.
3. Install in the reverse order of removal.

Scheme 131

1. Disassemble in the order shown in the figure. (Scheme 131): Disassembled View Of Rear Door Trim
2. Assemble in the reverse order of disassembly.

Scheme 132

1. Pull the edge of power window subswitch cover in the direction of arrow (1) and detach the tab. (Scheme 132): Removing Power Window Subswitch
2. Remove the power window subswitch in the direction of arrow (2) shown in the figure.

Scheme 133

Scheme 134

Scheme 135

Scheme 136

Scheme 137

1. Remove the trunk board. (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-615455-S29131302172014051000000) ).
2. Partially peel back the liftgate weather strip.
3. Remove fasteners. (Scheme 133): Identifying Trunk End Trim With Fasteners
4. Carry the trunk end trim from the position of the arrow shown in the figure, and pull up the trunk end trim in the direction of arrow (1) shown in the figure while disengage tab A and B. (Scheme 134): Pulling Trunk End Trim
5. Pull up the trunk end trim in the direction of arrow (2) shown in the figure, and then remove clip C and pin D. (Scheme 135): Pulling Trunk End Trim
6. Carry the trunk end trim from the position of the arrow shown in the figure, and pull up the trunk end trim in the direction of arrow (3) shown in the figure while disengage tab E and F. (Scheme 136): Carrying Trunk End Trim
7. Pull up the trunk end trim in the direction of arrow (4) shown in the figure, and then remove clip G and pin H. (Scheme 137): Pulling Trunk End Trim
8. Install in the reverse order of removal.

Scheme 138

Scheme 139

Scheme 140

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the following parts: Trunk board (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-615455-S29131302172014051000000) ). Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-615455-S40973116952014051000000) ). Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-615455-S30956965972014051000000) ).
3. Remove bolts A, then remove the cargo net hook. (Scheme 138): Identifying Trunk Side Trim, Bolts, Fasteners, Screws And Hook With Torque Specifications
4. Remove the fastener B.
5. Remove the screw C.
6. Remove the cap, then remove the screw D. (4:2:4 split type)
7. Hold D-pillar trim with your hands and pull the trunk side trim in the direction of the arrow (1), (2), (3), (4) and remove clips E, hooks F and pin G. (Scheme 139): Removing Trunk Side Trim
8. Set the remote handle lever. (4:2:4 split type)
9. Disconnect the connector, (cargo room light connector, rear accessory socket connector)
10. Install in the reverse order of removal. (Scheme 140): Identifying Remote Handle Lever

Scheme 141

Scheme 142

Scheme 143

Scheme 144

Scheme 145

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-615455-S13279173212014051000000) ).
3. Insert a tape-wrapped flathead screwdriver in the position indicated by the arrow (1) in the figure and remove the inner handle cover while detach tabs A, pin B. (Scheme 141): Removing Remote Handle Lever
4. Remove the screw C. (Scheme 142): Identifying Screw
5. Remove the cover D, then remove the screw E. (Scheme 143): Identifying Cover And Screw
6. Take the shaded area shown in the figure, and pull the front door trim in the direction of the arrow in the order of (1), (2), (3), (4) while detaching clips F, hooks G and pin H. CAUTION: If the front door trim is removed in the same way as past vehicles by pulling it upward, it could damage clips F, hooks G and pin H. When removing the front door trim, always pull it in the direction of the arrow shown in the figure. (Scheme 144): Pulling Front Door Trim
7. Remove the tab I in the direction of the arrow (5) shown in the figure. (Scheme 145): Identifying Front Inner Handle Cover With Tab
8. Remove the front inner handle in the direction of the arrow (6) shown in the figure while detaching the tab J.
9. Disconnect the power window main switch connector (driver-side) or power window subswitch connector (passenger-side).
10. Install in the reverse order of removal.

Scheme 146

1. Disassemble in the order shown in the figure. (Scheme 146): Disassembled View Of Front Door Trim (Driver-Side)
2. Assemble in the reverse order of disassembly.

Scheme 147

1. Disassemble in the order shown in the figure. (Scheme 147): Disassembled View Of Front Door Trim (Passenger-Side)
2. Assemble in the reverse order of disassembly.

Scheme 148

Scheme 149

1. Pull the edge of power window main switch or subswitch cover in the direction of arrow (1) and detach tabs. Driver-side (Scheme 148): Pulling Power Window Main Switch (Driver-Side) Passenger-side (Scheme 149): Pulling Power Window Main Switch (Passenger-Side)
2. Remove the power window main switch, power window subswitch or lock switch in the direction of arrow (2) shown in the figure.

Scheme 150

Scheme 151

Scheme 152

Scheme 153

Scheme 154

1. Insert a tape-wrapped flathead screwdriver in the position indicated by the arrow (1) in the figure and remove the inner handle cover while detach tabs A, pin B. (Scheme 150): Removing Inner Handle Cover
2. Remove the screw C. (Scheme 151): Identifying Inner Handle Cover And Screws
3. Remove the cover D, then remove the screw E.
4. Take the shaded area shown in the figure, and pull the rear door trim in the direction of the arrow in the order of (1), (2), (3), (4) while detaching clips F, hooks G and pin H. CAUTION: If the rear door trim is removed in the same way as past vehicles by pulling it upward, it could damage clips F, hooks G and pins H. When removing the rear door trim, always pull it in the direction of the arrow shown in the figure. (Scheme 152): Identifying Rear Door Trim Cover And Screws (Scheme 153): Removing Rear Door Trim
5. Remove the tab I in the direction of the arrow (5) shown in the figure. (Scheme 154): Removing Inner Handle Cover
6. Remove the rear inner handle in the direction of the arrow (6) shown in the figure while detaching the tab J.
7. Disconnect the power window subswitch connector.
8. Install in the reverse order of removal.

Scheme 155

1. Set the trunk covering aside.
2. Remove the trunk board No.1 in the direction of the arrow (1) shown in the figure. (Scheme 155): Removing Trunk Board
3. Remove the trunk board No.2 in the direction of the arrow (2) shown in the figure.
4. Install in the reverse order of removal.

Scheme 156

1. Take the shaded area shown in the figure, detach tab A while pulling the liftgate upper trim in the direction of the arrow (1) shown in the figure, then detach clips B, clip C and pin D while pulling in the direction of the arrow (2). (Scheme 156): Removing Liftgate Upper Trim
2. Take the shaded area shown in the figure, detach tab E while pulling the liftgate upper trim in the direction of the arrow (3) shown in the figure, then detach the clip F, clip G while pulling in the direction of the arrow (4).
3. Install in the reverse order of removal.

Scheme 157

1. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-615455-S41758863582014051000000) ).
2. Remove the fastener A.
3. Take the shaded area shown in the figure, and pull the liftgate side trim in the direction of the arrow (1) while detaching clips B. (Scheme 157): Pulling Liftgate Side Trim
4. Take the shaded area shown in the figure, detach tabs C while pulling the liftgate side trim in the direction of the arrow (2) shown in the figure, then detach the hook D, pin E while pulling in the direction of the arrow (3).
5. Install in the reverse order of removal.

Scheme 158

Scheme 159

1. Remove the following parts: Liftgate upper trim (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-615455-S41758863582014051000000) ). Liftgate side trim (See «LIFTGATE SIDE TRIM REMOVAL/INSTALLATION»(ref-615455-S24037188362014051000000) ). Liftgate recess (See «LIFTGATE RECESS REMOVAL/INSTALLATION»(ref-615455-S32409649192014051000000) ).
2. Remove fasteners A. (Scheme 158): Identifying Liftgate Lower Trim Fasteners
3. Take the shaded area shown in the figure, and pull the liftgate lower trim in the direction of the arrow in the order of (1), (2), (3), (4) and remove it while detaching clips B, clips C and pins D. (Scheme 159): Pulling Liftgate Lower Trim
4. Install in the reverse order of removal.

Scheme 160

Scheme 161

1. Insert a tape-wrapped flathead screwdriver into the service hole and remove the assist handle covers. (Scheme 160): Removing Assist Handle Covers
2. Remove the assist handle in the direction of the arrow (1) and (2), while detach clips. (Scheme 161): Removing Assist Handle

Note. Remove the assist handle by shaking it up and down.

Scheme 162

Scheme 163

1. Push the assist handle in the direction of the arrow shown in the figure. (Scheme 162): Pushing Assist Handle
2. Push the assist handle cover assembled to install the assist handle. (Scheme 163): Pushing Assist Handle Cover

Scheme 164

Scheme 165

1. Disconnect the negative battery cable, (with vanity mirror illumination) (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the screw A.
3. Rotate the sunvisor in the direction of the arrow. (Scheme 164): Rotating Sunvisor
4. Unhook and remove the sunvisor.
5. Disconnect the vanity mirror illumination connector, (with vanity mirror illumination)
6. Press the center adaptor tabs as shown in the figure using two tape-wrapped flathead screwdrivers, and remove the center adaptor. (Scheme 165): Removing Center Adaptor
7. Install in the reverse order of removal.

Scheme 166

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the following parts: Sunroof seaming welt (with sunroof system) (See «SUNROOF UNIT REMOVAL/INSTALLATION»(ref-615484-S04733214242014051000000) ). A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-615455-S18284409542014051000000) ). Front map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-615452-S19821275172014051000000) ). Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-615455-S21135452612014051000000) ). Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-615455-S15598834492014051000000) ). Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-615455-S30956965972014051000000) ). B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-615455-S28493908822014051000000) ). Adjust anchor cover (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-615482-S42598094432014051000000) ). Upper anchor installation bolt on the seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-615482-S42598094432014051000000) ). B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-615455-S13404345382014051000000) ). Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-615455-S08116469212014051000000) ). Trunk board (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-615455-S29131302172014051000000) ). Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-615455-S40973116952014051000000) ). Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-615455-S22359050062014051000000) ). D-pillar trim (See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-615455-S20578915672014051000000) ). C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-615455-S09907123002014051000000) ).
3. Disconnect the roof wiring harness connector and remove the roof wiring harness connector clip from the body.
4. Disconnect the rear washer hose C. (with rear washer system) (See «REAR WASHER HOSE REMOVAL/INSTALLATION»(ref-615468-S18625558412014051000000) ).
5. Temporarily install the seaming welt shown in the figure to the headliner. CAUTION: If fasteners are removed without temporarily installing the seaming welt, the headliner may fall off and the part may be damaged. Before removing fasteners, temporarily install the seaming welt to prevent the headliner from falling off. (Scheme 166): Identifying Seaming Welt, Fasteners And Headliners
6. Remove fasteners.
7. Partially peel back the seaming welt. Take the headliner out from the opened liftgate.
8. Install in the reverse order of removal.

Scheme 167

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the following parts: Driver-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-615455-S15598834492014051000000) ). Driver-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-615455-S14137250292014051000000) ). Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-615455-S15150991172014051000000) ). Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-615440-S42122392892014051000000) ). Front console box (See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-615455-S42371732362014051000000) ). Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-615455-S00421900212014051000000) ). Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-615455-S24596820212014051000000) ). Rear console (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-615455-S26190969372014051000000) ). Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-615455-S29263037032014051000000) ). Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-615455-S37957878882014051000000) ). Accelerator pedal (See «ACCELERATOR PEDAL REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-615404-S33394844082014051000000) ).
3. Pull the floor insulator in the direction of the arrow and remove it. (Scheme 167): Pulling Floor Insulator (Driver-Side)
4. Install in the reverse order of removal.

Scheme 168

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the following parts: Passenger-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-615455-S15598834492014051000000) ). Passenger-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-615455-S14137250292014051000000) ). Grove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-615455-S15366383852014051000000) ). Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-615455-S15150991172014051000000) ). Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-615440-S42122392892014051000000) ). Front console box (See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-615455-S42371732362014051000000) ). Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-615455-S00421900212014051000000) ). Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-615455-S24596820212014051000000) ). Rear console (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-615455-S26190969372014051000000) ). Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-615455-S29263037032014051000000) ). Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-615455-S37957878882014051000000) ).
3. Remove the fastener. (Scheme 168): Pulling Floor Insulator (Passenger-Side)
4. Pull the floor insulator in the direction of the arrow and remove it.
5. Install in the reverse order of removal.

Scheme 169

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the following parts: Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-615455-S15598834492014051000000) ). Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-615455-S14137250292014051000000) ). Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-615455-S30956965972014051000000) ). B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-615455-S28493908822014051000000) ). Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-615443-S32063289502014051000000) ). Front seat (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-615443-S08848515662014051000000) ). Lower anchor of the front seat belt (without lap pre-tensioner seat belt) (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-615482-S42598094432014051000000) ). Lap pre-tensioner seat belt (with lap pre-tensioner seat belt) (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-615482-S42598094432014051000000) ). Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-615440-S42122392892014051000000) ). Front console box (See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-615455-S42371732362014051000000) ). Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-615455-S00421900212014051000000) ). Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-615455-S24596820212014051000000) ). Rear console (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-615455-S26190969372014051000000) ). Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-615455-S29263037032014051000000) ). Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-615455-S37957878882014051000000) ). SAS control module (See «SAS CONTROL MODULE REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-615424-S35876496672014051000000) ). (See «SAS CONTROL MODULE REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-615423-S33081355292014051000000) ). Parking brake lever (See «PARKING BRAKE LEVER REMOVAL/INSTALLATION»(ref-615444-S06065681772014051000000) ). Joint cover (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-615435-S37273804732014051000000) ).
3. Remove fasteners. (Scheme 169): Identifying Floor Covering And Fasteners
4. Take the floor covering out from the opened door.
5. Install in the reverse order of removal.
