Interior Trim: Overview Mazda CX-5 I

Scheme 58

1. Disassemble in the order indicated in the table. (Scheme 58): Disassembled View Of Dashboard
2. Assemble in the reverse order of disassembly.

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]» ).
2. Remove the following parts: Windshield wiper arm and blade (See «WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION» ). Cowl grille (See «COWL GRILLE REMOVAL/INSTALLATION» ). Windshield wiper motor (See «WINDSHIELD WIPER MOTOR AND LINK REMOVAL/INSTALLATION» ). Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION» ). Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION» ). Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION» ). Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION» ). Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION» ). Center panel (See «CENTER PANEL REMOVAL/INSTALLATION» ). Audio unit (See «AUDIO UNIT REMOVAL/INSTALLATION» ). Front console box (See «FRONT CONSOLE BOX REMOVAL/INSTALLATION» ). Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(/mazda/cx-5/i-2011-2015/remont/manual-trans/#manual-transaxle-shift-mechanism) ). Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION» ). Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION» ). Rear console (See «REAR CONSOLE REMOVAL/INSTALLATION» ). Side wall (See «SIDE WALL REMOVAL/INSTALLATION» ). Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION» ). Selector lever component (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(/mazda/cx-5/i-2011-2015/remont/manual-trans/#manual-transaxle-shift-mechanism) ). Selector lever component (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION» ). Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION» ). Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION» ). Knee bolster (See «KNEE BOLSTER REMOVAL/INSTALLATION» ). Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]» ). (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [MANUAL AIR CONDITIONER]» ). Column cover (See «COLUMN COVER REMOVAL/INSTALLATION» ). Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]» ). (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]» ). Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION» ). Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION» ). Switch panel (See «SWITCH PANEL REMOVAL/INSTALLATION» ). Meter hood (See «METER HOOD REMOVAL/INSTALLATION» ). Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION» ). A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION» ).
3. Set the parking brake cover aside.
4. Disconnect the dashboard harness connectors at the tunnel area and remove the wiring harness clip. (Scheme 59): Removing Wiring Harness Clip
5. Pull out the dashboard harness in the direction of the arrow shown in the figure while avoiding the floor covering. CAUTION: When pulling out the dashboard harness, if the connector is hooked to the floor mat, it may cause a short circuit in the wiring harness or the connector may be damaged. Pull out the dashboard harness while lifting the floor mat so as not to hook the connector.
6. Remove the bolts A and nut B shown in the figure. (Scheme 60): Identifying Dashboard Bolt And Nuts With Torque Specifications
7. Remove the dashboard bracket.
8. Remove the bolt C. (See «DASHBOARD INSTALLATION NOTE» ). (Scheme 61): Identifying Dashboard Bolts With Torque Specifications
9. Disconnect the dashboard harness connectors.
10. Remove the caps. (Scheme 62): Identifying Dashboard Bolts And Cap With Torque Specifications
11. Remove the bolt D and bolt E. (See «DASHBOARD INSTALLATION NOTE» ). CAUTION: Bolts D cannot be removed completely because they contact the front door. If the front door is closed with the bolts D sticking out, it may cause a dent or damage to the coating film. After taking out the dashboard from the cabin, secure removed bolts D to the vehicle body using tape so that they do not stick out. (Scheme 63): Identifying Protective Tape Applying Area On Dashboard
12. Pull up the dashboard in the direction shown in the direction of the arrow in the order of (1), (2) shown in the figure, then remove the guide pin. (Scheme 64): Removing Guide Pin
13. Turn the dashboard 90° in the direction of the arrow shown in the figure. (Scheme 65): Turning Dashboard
14. Take the dashboard off from the front driver-side door or front passenger-side door opening.
15. Install in the reverse order of removal.

Scheme 66

1. When installing the dashboard, if the position of the member junction is deviated, the bolts cannot be installed. Before installing the dashboard, align the member junction and bolts to the position shown in the figure. (Scheme 66): Identifying Member Junctions

Scheme 67

Scheme 68

1. Insert a tape-wrapped flathead screwdriver into shown in the figure and remove hooks A in the direction of arrow (1). (Scheme 67): Removing Centre Speaker Grille With Torque Specifications
2. Take the shaded area shown in the figure, and remove the center speaker grille in the direction of arrow (2) while detaching hooks B. (Scheme 68): Removing Center Speaker Grille
3. Install in the reverse order of removal.

Scheme 69

Scheme 70

1. Insert a tape-wrapped flathead screwdriver into the service hole and remove hooks A in the direction of arrow (1). (Scheme 69): Removing Side Speaker Grille
2. Pull the side speaker grille in the direction of the arrow (2), and remove the side speaker grille while detaching hooks B. (Scheme 70): Removing Side Speaker Grille
3. Install in the reverse order of removal.
