Air Bag System Components Location (1 Of 2). Scheme 136
Scheme 136: Air Bag System Components Location (1 Of 2)
Air Bag System Components Location (2 Of 2). Scheme 137
Scheme 137: Air Bag System Components Location (2 Of 2)
Scheme 138
Scheme 138: Air Bag Module Inspection
- Inspecting an air bag module using a tester can operate (deploy) the air bag module, which may cause serious injury. Do not use a tester to inspect an air bag module. Always use the on-board diagnostic function to diagnose the air bag module for malfunctions. (Scheme 138): Caution For Inspecting Air Bag Module
Scheme 139
Scheme 139: Air Bag Module Handling
Scheme 140
- Before removing the air bag module or disconnecting the air bag module connector, always switch the ignition off, disconnect the negative battery cable, and then wait for 1 min or more to allow the backup power supply of the SAS control module to deplete its stored power.
- Handling a live (undeployed) air bag module that is pointed toward your body could result in serious injury if the air bag module were to accidentally operate (deploy). When carrying a live (undeployed) air bag module, point the deployment surface away from your body to lessen the chance of injury in case it operates (deploys). (Scheme 139): Identifying Proper And Improper Handling Of Air Bag Module
- A live (undeployed) air bag module placed with its deployment surface to ground is dangerous. If the air bag module were to accidentally operate (deploy), it could cause serious injury. Always place a live (undeployed) air bag module with its deployment surface up. (Scheme 140): Caution For Handling Air Bag Module
