Power Systems: Other Mazda 6 GJ

FUSE SERVICE CAUTIONS

Scheme 14

1. Disconnect the negative battery cable.
2. Remove the nuts. (Scheme 14): Main Fuse Block, Main Fuse And Nuts With Torque Specification
3. Remove the main fuse from the main fuse block.
4. Install in the reverse order of removal.

Scheme 15

Scheme 16

Scheme 17

1. Disconnect the negative battery cable.
2. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-581614-S36009183262013101400000).)
3. Pull the pin in the direction of the arrow shown in the figure and release the lock. (Scheme 15): Ignition Switch Connector Pin
4. Disconnect the connector.
5. Remove the screw. (Scheme 16): Ignition Switch And Screw
6. Remove the tabs. (Scheme 17): Ignition Switch And Tabs
7. Remove the ignition switch.
8. Install in the reverse order of removal.

Scheme 18

Scheme 19

1. Disconnect the negative battery cable.
2. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-581614-S36009183262013101400000).)
3. Remove the ignition switch. (See «IGNITION SWITCH REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581640-S03122966592013101400000).)
4. Verify that the continuity between the ignition switch terminals is as indicated in the table. (Scheme 18): Ignition Switch Connector Terminals (Without Advanced Keyless Entry And Push Button Start System) If not as indicated in the table, replace the ignition switch. (Scheme 19): Ignition Switch Connector Terminal Continuity Chart (Without Advanced Keyless Entry And Push Button Start System)

Scheme 20

Scheme 21

1. Disconnect the negative battery cable.
2. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-581614-S36009183262013101400000).)
3. Disconnect the key reminder switch connector. (Scheme 20): Identifying Key Reminder Switch Connector
4. Detach the key reminder switch tab. (Scheme 21): Identifying Key Reminder Switch And Tab
5. Remove the key reminder switch.
6. Install in the reverse order of removal.

Scheme 22

Scheme 23

Scheme 24

1. Disconnect the negative battery cable.
2. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-581614-S36009183262013101400000).)
3. Disconnect the key reminder switch connector. (Scheme 22): Identifying Key Reminder Switch Connector
4. Verify that the continuity between the key reminder switch terminals is as indicated in the table. (Scheme 23): Key Reminder Switch Circuit And Terminal Identification If not as indicated in the table, replace the key reminder switch. (Scheme 24): Key Reminder Switch Terminals Continuity Chart

FORCED IGNITION ON [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]

Note. In order to perform a forced ignition ON, the M-MDS is necessary. If the servicing is being done outside of an Authorized Mazda dealership, contact an Authorized Mazda dealership for instructions. The forced ignition ON procedure forces a power supply to each part when no power is available even after the ignition switch has been operated. However, the engine cannot be started and the steering cannot be unlocked.

Scheme 25

Scheme 26

1. Verify that there are no advanced keys in the vehicle.
2. Get PCM part number from As-built site.
3. Connect the M-MDS to the DLC-2. see scheme 25: Identifying DLC-2
4. Manual vehicle identification. When using the IDS (laptop PC) Select "Manual Vehicle Entry". When using the PDS (Pocket PC) Select "Vehicle ID button". Select "keyboard button".
5. Select the "All other" from Vehicle list.
6. Input the PCM part number on the following screen. (Scheme 25): Screen Display - IDS (Laptop PC) (Scheme 26): Screen Display - PDS (Pocket PC)
7. Select the following items from the initial screen of the M-MDS. When using the IDS (laptop PC) Select "Body". Select "Special Ignition ON". When using the PDS (Pocket PC) Select "All Tests and Calibrations". Select "Special Ignition ON".
8. Perform the procedure according to the directions on the screen.
9. Delete session with keeping ignition ON.
10. Normal vehicle identification.

Identifying Main Fuse Block. Scheme 27

Relay Type

Scheme 28

Scheme 29

1. Verify that the continuity is as indicated in the table. (Scheme 28): Relay Circuit (Type A) If not as indicated in the table, replace the relay. (Scheme 29): Relay Terminal Continuity Chart (Type A)

Scheme 30

Scheme 31

1. Verify that the continuity is as indicated in the table. (Scheme 30): Relay Circuit (Type B) If not as indicated in the table, replace the relay. (Scheme 31): Relay Terminal Continuity Chart (Type B)

Scheme 32

Scheme 33

1. Verify that the continuity is as indicated in the table. (Scheme 32): Relay Circuit (Type C) If not as indicated in the table, replace the relay. (Scheme 33): Relay Terminal Continuity Chart (Type C)

Scheme 34

Scheme 35

1. Verify that the continuity is as indicated in the table. (Scheme 34): Relay Circuit (Type D) If not as indicated in the table, replace the relay. (Scheme 35): Relay Terminal Continuity Chart (Type D)
