Power Systems: Diagnosis Mazda 6 GJ

Ignition Switch/steering Lock 11 illustrations ~635 words

STEERING LOCK UNIT INSPECTION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]

  1. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-581614-S36009183262013101400000) .)
  2. Measure each terminal voltage under the measurement condition. If the voltage is not as specified in the terminal voltage table, inspect the parts under "Inspection item(s)". If the system does not work normally even though the inspection items are normal, replace the steering lock unit.

Identifying Steering Lock Unit Connector Terminals (With Advanced Keyless Entry And Push Button Start System). Scheme 3

Scheme 3: Identifying Steering Lock Unit Connector Terminals (With Advanced Keyless Entry And Push Button Start System)
Scheme 3: Identifying Steering Lock Unit Connector Terminals (With Advanced Keyless Entry And Push Button Start System)
TerminalSignal nameConnected toMeasurement conditionVoltage (V)Inspection item(s)
A
BSteering lock unit groundKeyless control moduleSteering lock unit is operating (lock operating only)1.0 or lessKeyless control module Related wiring harness
Except above1.0 or more
CSerial communicationKeyless control moduleTerminal used for communication therefore determination based on terminal voltage inspection not possible.
D
EUNLOCK outputKeyless control moduleSteering wheel is lockedB+Keyless control module Related wiring harness
Steering wheel is unlocked1.0 or less
FPower supplyKeyless control moduleSteering lock unit is operatingB+Keyless control module Related wiring harness
Except above1.0 or less
G
HGroundBody groundUnder any condition1.0 or lessRelated wiring harness

Scheme 4

Scheme 4: PUSH BUTTON START REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]
Scheme 4: PUSH BUTTON START REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]
  1. Disconnect the negative battery cable.
  2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-581614-S15065956352013101400000).) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-581614-S30597239632013101400000).) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-581615-S07668845722013101400000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-581614-S38776581642013101400000).) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-581614-S05740589362013101400000).)
  3. Release the tabs and remove the push button start from the center panel lower. (Scheme 4): Push Button Start Components And Center Panel Lower
  4. Install in the reverse order of removal.

Scheme 5

Scheme 5: PUSH BUTTON START INSPECTION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]
Scheme 5: PUSH BUTTON START INSPECTION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7
  1. Disconnect the negative battery cable.
  2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-581614-S15065956352013101400000).) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-581614-S30597239632013101400000).) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-581615-S07668845722013101400000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-581614-S38776581642013101400000).) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-581614-S05740589362013101400000).) Push button start (See «PUSH BUTTON START REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581640-S26233673752013101400000).)
  3. Verify that the continuity is as indicated in the table. (Scheme 5): Push Button Start Circuit (With Advanced Keyless Entry And Push Button Start System) If not as indicated in the table, replace the push button start. (Scheme 6): Push Button Start Terminals Continuity Chart (With Advanced Keyless Entry And Push Button Start System)
  4. Apply battery positive voltage and connect the ground to the push button start terminals and verify that the LED illuminates. If the LEDs does not illuminate, replace the push button start. Terminal Illumination positions B+ Ground C E ACC indicator light C G ON indicator light C H Indicator (Green) C F Indicator (Red) D J START/STOP/ENGINE (Scheme 7): Push Button Start Circuit

Scheme 8

Scheme 8: RELAY BLOCK REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]
Scheme 8: RELAY BLOCK REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10
  1. Disconnect the negative battery cable.
  2. Remove the lower panel. (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-581614-S08723493922013101400000).)
  3. Remove the knee bolster. (See «KNEE BOLSTER REMOVAL/INSTALLATION»(ref-581614-S28871510292013101400000).)
  4. Remove the wiring harness clip. (Scheme 8): Wiring Harness Clips
  5. Remove the clips.
  6. Remove the relay block. (Scheme 9): Identifying Relay Block
  7. Disconnect the connectors. (Scheme 10): Relay Block And Connectors
  8. Install in the reverse order of removal.

Scheme 11

Scheme 11: RELAY BLOCK INSPECTION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]
Scheme 11: RELAY BLOCK INSPECTION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]

Scheme 12

Scheme 12
Scheme 12
  1. Disconnect the negative battery cable.
  2. Remove the lower panel. (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-581614-S08723493922013101400000).)
  3. Remove the knee bolster. (See «KNEE BOLSTER REMOVAL/INSTALLATION»(ref-581614-S28871510292013101400000).)
  4. Remove the relay block. (See «RELAY BLOCK REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581640-S21634351452013101400000).)
  5. Verify that the continuity is as indicated in the table. (Scheme 11): Relay Block Circuit (With Advanced Keyless Entry And Push Button Start System) If not as indicated in the table, replace the relay block. (Scheme 12): Relay Block Terminals Continuity Chart (With Advanced Keyless Entry And Push Button Start System)

Scheme 13

Scheme 13: POWER SYSTEMS PERSONALIZATION FEATURES SETTING PROCEDURE
Scheme 13: POWER SYSTEMS PERSONALIZATION FEATURES SETTING PROCEDURE
  1. Connect the M-MDS (IDS) to the DLC-2. (Scheme 13): Identifying DLC-2
  2. After the vehicle is identified, select the following items from the initial screen of the M-MDS (IDS). Select the "Module Programming".
  3. Then, select items from the screen menu in the following order. Select "Programmable Parameters". Select "RKE".
  4. Select an item name, and then select option. M-MDS display Function Initial setting Setting content Control unit ACC auto off The function to automatically switch off the ignition after one hour has elapsed since the ignition was switched to ACC can be set to operable or inoperable. Enabled Disabled/Enabled Keyless control module Power off mode The transition pattern in which the ignition position is switched by pressing the push button start can be selected. Direct Direct/Stepwise Keyless control module
