TOUCH SENSOR REMOVAL/INSTALLATION [ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM] Mazda 6 GH facelift

TOUCH SENSOR REMOVAL/INSTALLATION [ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]

Note. The touch sensor are built into the front outer handles. (See FRONT OUTER HANDLE REMOVAL/INSTALLATION .)

Scheme 131

Scheme 131: TOUCH SENSOR REMOVAL/INSTALLATION [ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]

Scheme 132

Scheme 132: REQUEST SWITCH INSPECTION [ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]

Scheme 133

Scheme 133
  1. To access the glass installation bolt, position the front door glass so that the distance from the top of the front door glass to the upper part of the front beltline molding is approx. 80 mm {3.1 in}.
  2. Disconnect the negative battery cable.
  3. Remove the following parts: Inner garnish (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-448656-S17163868202012012000000) .) Front door trim (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-448656-S34800399052012012000000) .) Front door speaker (See «FRONT DOOR SPEAKER REMOVAL/INSTALLATION»(ref-448591-S04868612742012012000000) .) Front door glass (See «FRONT DOOR GLASS REMOVAL/INSTALLATION»(ref-448571-S41149988882012012000000) .) Front door module panel (See «FRONT DOOR MODULE PANEL REMOVAL/INSTALLATION»(ref-448692-S06652197342012012000000) .) Front door key cylinder (Driver's side) (See «FRONT DOOR KEY CYLINDER REMOVAL/INSTALLATION»(ref-448614-S11884518702012012000000) .) Front outer handle (See «FRONT OUTER HANDLE REMOVAL/INSTALLATION»(ref-448614-S37930953932012012000000) .)
  4. Verify the continuity of request switch terminals A and D.
  5. Verify that the continuity is as indicated in the table.

Scheme 134

Scheme 134
  1. If not as indicated in the table, replace the front outer handle.
