Scheme 47
![Scheme 47: CONTROL SYSTEM LOCATION INDEX [MZI 3.7 V6]](https://i.diagnostdata.com/repair/86/8651b6ff2db7f548408418558acfd7f86ca0e21568762818b682b974e4fc9c68.webp)
| 1 | APP sensor (See ACCELERATOR PEDAL POSITION (APP) SENSOR INSPECTION [MZI 3.7 V6].) (See ACCELERATOR PEDAL REMOVAL/INSTALLATION [MZI 3.7 V6].) |
|---|---|
| 2 | A/F sensor (See AIR FUEL RATIO (A/F) SENSOR REMOVAL/INSTALLATION [MZI 3.7 V6].) (See AIR FUEL RATIO (A/F) SENSOR INSPECTION [MZI 3.7 V6].) |
| 3 | HO2S (See HEATED OXYGEN SENSOR (HO2S) REMOVAL/INSTALLATION [MZI 3.7 V6].) (See HEATED OXYGEN SENSOR (HO2S) INSPECTION [MZI 3.7 V6].) |
| 4 | Fuel tank pressure sensor (See FUEL TANK PRESSURE SENSOR INSPECTION [MZI 3.7 V6].) (See FUEL TANK REMOVAL/INSTALLATION [MZI 3.7 V6].) |
| 5 | PSP switch (See POWER STEERING PRESSURE (PSP) SWITCH INSPECTION [MZI 3.7 V6].) (See POWER STEERING OIL PUMP DISASSEMBLY/ASSEMBLY [MZI 3.7 V6].) |
| 6 | CHT sensor (See CYLINDER HEAD TEMPERATURE (CHT) SENSOR REMOVAL/INSTALLATION [MZI 3.7 V6].) (See CYLINDER HEAD TEMPERATURE (CHT) SENSOR INSPECTION [MZI 3.7 V6].) |
| 7 | KS (See KNOCK SENSOR (KS) REMOVAL/INSTALLATION [MZI 3.7 V6].) (See KNOCK SENSOR (KS) INSPECTION [MZI 3.7 V6].) |
| 8 | CMP sensor (See CAMSHAFT POSITION (CMP) SENSOR REMOVAL/INSTALLATION [MZI 3.7 V6].) (See CAMSHAFT POSITION (CMP) SENSOR INSPECTION [MZI 3.7 V6].) |
| 9 | MAF/IAT sensor (See MASS AIR FLOW (MAF)/INTAKE AIR TEMPERATURE (IAT) SENSOR REMOVAL/INSTALLATION [MZI 3.7 V6].) (See MASS AIR FLOW (MAF) SENSOR INSPECTION [MZI 3.7 V6].) (See INTAKE AIR TEMPERATURE (IAT) SENSOR INSPECTION [MZI 3.7 V6].) |
| 10 | TP sensor (See THROTTLE POSITION (TP) SENSOR INSPECTION [MZI 3.7 V6].) (See INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [MZI 3.7 V6].) |
| 11 | CKP sensor (See CRANKSHAFT POSITION (CKP) SENSOR REMOVAL/INSTALLATION [MZI 3.7 V6].) (See CRANKSHAFT POSITION (CKP) SENSOR INSPECTION [MZI 3.7 V6].) |
| 12 | PCM (See PCM REMOVAL/INSTALLATION [MZI 3.7 V6].) (See PCM INSPECTION [MZI 3.7 V6].) (See PCM CONFIGURATION [MZI 3.7 V6].) |
CONTROL SYSTEM REFERENCE CHART
Scheme 48
![Scheme 48: CONTROL SYSTEM DIAGRAM [MZI 3.7 V6]](https://i.diagnostdata.com/repair/63/63e64b81bde182306d81c6d8f13666e35c8a4b577bd9ae469f0fce4937977321.webp)
Scheme 49
![Scheme 49: CONTROL SYSTEM WIRING DIAGRAM [MZI 3.7 V6]](https://i.diagnostdata.com/repair/42/42f5cf37b022023d803edeed3ea9fbf97eb388f1fb00c9295b5eb12bfc3c4971.webp)
Scheme 50
Scheme 51
Scheme 52
![Scheme 52: PCM REMOVAL/INSTALLATION [MZI 3.7 V6]](https://i.diagnostdata.com/repair/08/083b42b07822ad3e0ab2baf47e8a9ad10e266df44ebf158b021e8a7dc2fc7e33.webp)
Scheme 53
- Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZI 3.7 V6]»(ref-448609-S21137111942012012000000).)
- Remove the battery and battery tray. (See «BATTERY REMOVAL/INSTALLATION [MZI 3.7 V6]»(ref-448609-S21137111942012012000000).)
- Remove all connectors and clips which may interfere with servicing.
- Loosen the PCM bracket nuts.
- Remove the PCM from the PCM bracket.
- Remove the PCM bracket.
- Install in the reverse order of removal.
- When replacing the PCM on the vehicles, perform the following
- PCM configuration (See «PCM CONFIGURATION [MZI 3.7 V6]»(ref-448597-S04520589902012012000000).)
- Immobilizer system component replacement/key addition and clearing (See «IMMOBILIZER SYSTEM-RELATED PARTS PROGRAMMING [KEYLESS ENTRY SYSTEM]»(ref-448614-S28546032012012012000000).) (See «IMMOBILIZER SYSTEM-RELATED PARTS PROGRAMMING [ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-448614-S31570466142012012000000).)
Scheme 54
See also:
• ON-BOARD DIAGNOSTIC TEST [MZI 3.7 V6]
