Interior Trim: Overview Mazda 6 GH facelift

Exterior/interior Trim 6 illustrations ~430 words

Scheme 39

Scheme 39: INTERIOR TRIM LOCATION INDEX
Scheme 39: INTERIOR TRIM LOCATION INDEX
1Inner garnish (See INNER GARNISH REMOVAL/INSTALLATION.)
2Center panel upper (See CENTER PANEL UPPER REMOVAL/INSTALLATION.)
3Center ventilator grille (See VENTILATOR GRILLE REMOVAL/INSTALLATION.)
4Dashboard (See DASHBOARD REMOVAL/INSTALLATION.) (See DASHBOARD DISASSEMBLY/ASSEMBLY.)
5Ventilator grille (See VENTILATOR GRILLE REMOVAL/INSTALLATION.)
6Grove compartment (See GLOVE COMPARTMENT REMOVAL/INSTALLATION.)
7Dashboard under cover (See DASHBOARD UNDER COVER REMOVAL/INSTALLATION.)
8Decoration panel (See DECORATION PANEL REMOVAL/INSTALLATION.)
9Shift panel (See SHIFT PANEL REMOVAL/INSTALLATION.)
10Center panel lower (See CENTER PANEL LOWER REMOVAL/INSTALLATION.)
11Knee bolster (See KNEE BOLSTER REMOVAL/INSTALLATION.)
12Lower panel (See LOWER PANEL REMOVAL/INSTALLATION.)
13Front side trim (See FRONT SIDE TRIM REMOVAL/INSTALLATION.)

PARTS DESCRIPTION CHART

Scheme 40

Scheme 40
Scheme 40
1Speaker grille (See SPEAKER GRILLE REMOVAL/INSTALLATION.)
2Sunvisor (See SUNVISOR REMOVAL/INSTALLATION.)
3Meter hood (See METER HOOD REMOVAL/INSTALLATION.)
4Column cover (See COLUMN COVER REMOVAL/INSTALLATION.)
5A-pillar trim (See A-PILLAR TRIM REMOVAL/INSTALLATION.)
6Front door trim (See FRONT DOOR TRIM REMOVAL/INSTALLATION.) (see FRONT DOOR TRIM DISASSEMBLY/ASSEMBLY.)
7B-pillar lower trim (See B-PILLAR LOWER TRIM REMOVAL/INSTALLATION.)
8B-pillar upper trim (See B-PILLAR UPPER TRIM REMOVAL/INSTALLATION.)
9Assist handle (See ASSIST HANDLE REMOVAL/INSTALLATION.)
10Rear door trim (See REAR DOOR TRIM REMOVAL/INSTALLATION.)
11C-pillar trim (See C-PILLAR TRIM REMOVAL/INSTALLATION.)
12Rear package trim (See REAR PACKAGE TRIM REMOVAL/INSTALLATION.)
13Headliner (See HEADLINER REMOVAL/INSTALLATION.)
14Trunk side trim (See TRUNK SIDE TRIM REMOVAL/INSTALLATION.)
15Side panel (See SIDE PANEL REMOVAL/INSTALLATION.)
16Rear console (See REAR CONSOLE REMOVAL/INSTALLATION.) (See REAR CONSOLE DISASSEMBLY/ASSEMBLY.)
17Upper panel (See UPPER PANEL REMOVAL/INSTALLATION.)
18Fuel-filler lid opener bezel (See FUEL-FILLER LID OPENER BEZEL REMOVAL/INSTALLATION.)
19Front scuff plate (See FRONT SCUFF PLATE REMOVAL/INSTALLATION.)
20Floor covering (See FLOOR COVERING REMOVAL/INSTALLATION.)
21Rear scuff plate (See REAR SCUFF PLATE REMOVAL/INSTALLATION.)

PARTS DESCRIPTION CHART

Scheme 41

Scheme 41
Scheme 41
1Trunk lid trim (See TRUNK LID TRIM REMOVAL/INSTALLATION.)
2Trunk end trim (See TRUNK END TRIM REMOVAL/INSTALLATION.)

PARTS DESCRIPTION CHART

Scheme 42

Scheme 42: DASHBOARD REMOVAL/INSTALLATION
Scheme 42: DASHBOARD REMOVAL/INSTALLATION

Scheme 43

Scheme 43
Scheme 43
  1. Disconnect the negative battery cable.
  2. Remove the following parts: Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-448656-S36262450112012012000000).) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-448656-S15925168382012012000000).) Front scuff plates (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S42845656582012012000000).) Front side trims (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-448656-S24645152862012012000000).) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-448656-S41204061692012012000000).) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-448656-S12186936852012012000000).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(/mazda/6/gh-facelift-2009-2013/remont/manual-trans/#manual-transmission-manual-transaxle-shift-mechanism).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-448656-S21764171192012012000000).) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-448656-S13809786282012012000000).) Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-448606-S32061511212012012000000).) (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [MANUAL AIR CONDITIONER]»(ref-448607-S20228354472012012000000).) Rear console (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-448656-S24311442192012012000000).) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-448614-S41008846102012012000000).) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-448656-S04202039792012012000000).) Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-448570-S41657307962012012000000).) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-448619-S01292366382012012000000).) (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-448619-S18771656912012012000000).) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-448656-S12743804542012012000000).) Combination switch (See «COMBINATION SWITCH REMOVAL/INSTALLATION»(ref-448651-S19122248902012012000000).) Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-448656-S09959257172012012000000).) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-448586-S17394319142012012000000).) Center panel upper (See «CENTER PANEL UPPER REMOVAL/INSTALLATION»(ref-448656-S12464949122012012000000).) Audio unit (Vehicles with audio system) (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-448591-S42816289752012012000000).) Car-navigation unit (Vehicles with car-navigation system) (See «CAR-NAVIGATION UNIT REMOVAL/INSTALLATION»(ref-448591-S27809871202012012000000).) Steering shaft cover (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-448619-S01292366382012012000000).) (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-448619-S18771656912012012000000).) Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-448619-S01292366382012012000000).) (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-448619-S18771656912012012000000).) Side panel (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-448656-S21955955632012012000000).) SIRIUS satellite radio unit (See «SIRIUS SATELLITE RADIO UNIT REMOVAL/INSTALLATION»(ref-448591-S17549509352012012000000).) Passenger-side air bag module (See «PASSENGER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-448570-S05866549032012012000000).) A-pillar trims (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-448656-S22638988852012012000000).)
  3. Disconnect antenna feeder No. 1 clip from the A-pillar inner panel.
  4. Disconnect the washer hose. (See «WINDSHIELD WASHER HOSE REMOVAL/INSTALLATION»(ref-448630-S41929098372012012000000).)
  5. Disconnect the dashboard wiring harness connectors.
  6. Remove the caps.
  7. Remove bolts A, B, C, D and E.
  8. Raise the back side of the dashboard rotate it in the direction of the arrow shown in the illustration.
  9. Take the dashboard out through the opened driver's door.
  10. Install in the reverse order of removal.

Scheme 44

Scheme 44: SPEAKER GRILLE REMOVAL/INSTALLATION
Scheme 44: SPEAKER GRILLE REMOVAL/INSTALLATION
  1. Pull the speaker grille while remove the clips.
  2. Remove the speaker grille.
  3. Install in the reverse order of removal.
