Power Systems: Other Mazda 6 GH рестайлинг

Ignition Switch/steering Lock 12 illustrations ~338 words

FUSE SERVICE CAUTIONS

CAUTIONIf a fuse is burnt out, inspect the cause and repair the malfunctioning part, then replace the fuse with the specified value. If the fuse is replaced before doing this, it could burn again.

FORCED IGNITION ON [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]

CAUTIONWhen performing a forced ignition ON procedure, remove all advanced keys from the vehicle. If an advanced key is left in the vehicle, the forced ignition ON procedure cannot be done.

Note. In order to perform a forced ignition ON, the M-MDS is necessary. If the servicing is being done outside of an Authorized Mazda dealership, contact an Authorized Mazda dealership for instructions. The forced ignition ON procedure forces a power supply to each part when no power is available even after the ignition switch has been operated. However, the engine cannot be started and the steering cannot be unlocked.

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26
  1. Verify that there are no advanced keys in the vehicle.
  2. Get PCM part number from As-built site.
  3. Connect the M-MDS to the DLC-2.
  4. Manual vehicle identification. When using the IDS (laptop PC) Select "Manual Vehicle Entry". When using the PDS (Pocket PC) Select "Vehicle ID button". Select "keyboard button".
  5. Select the "All other" from Vehicle list.
  6. Input the PCM part number on the following screen. IDS (laptop PC) display PDS (Pocket PC) display
  7. Select the following items from the initial screen of the M-MDS. When using the IDS (laptop PC) Select "Body". Select "Special Ignition ON". When using the PDS (Pocket PC) Select "All Tests and Calibrations". Select "Special Ignition ON".
  8. Perform the procedure according to the directions on the screen.
  9. Delete session with keeping ignition ON.
  10. Normal vehicle identification.

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28: RELAY LOCATION
Scheme 28: RELAY LOCATION
1Fuel pump relay
2Horn relay
3Starter relay No. 2 (MZI 3.7 V6)
4Front fog light relay
5Starter relay
6A/C relay
7Fan control module relay
8Blower relay
9AT main relay (MZR 2.5, ATX)
Back-up light relay (MZR 2.5, MTX)
10Main relay
11Headlight relay
12Rear window defroster relay

PARTS DESCRIPTION CHART

Relay Type

Connector typePart name
Type AFront fog light relay A/C relay Rear window defroster relay Starter relay Horn relay Back-up light relay (MZR 2.5, MTX) AT main relay (MZR 2.5, ATX) Starter relay No. 2 (MZI 3.7 V6)
Type BFuel pump relay
Type CBlower relay Headlight relay Fan control module relay
Type DMain relay

CONNECTOR TYPE SPECIFICATION CHART

Type A

  1. Verify that the continuity is as indicated in the table.
  1. If not as indicated in the table, replace the relay.

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Type B

  1. Verify that the continuity is as indicated in the table.
  1. If not as indicated in the table, replace the relay.

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32

Type C

  1. Verify that the continuity is as indicated in the table.
  1. If not as indicated in the table, replace the relay.

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Type D

  1. Verify that the continuity is as indicated in the table.
  1. If not as indicated in the table, replaces the relay.

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36
