Wiring color codes
- Two-color wires are indicated by a two-color code symbol.
- The first letter indicates the base color of the wire and the second the color of the stripe.
| CODE | COLOR |
|---|---|
| B | Black |
| BR | Brown |
| G | Green |
| GY | Gray |
| L | Blue |
| LB | Light Blue |
| LG | Light Green |
| O | Orange |
| P | Pink |
| R | Red |
| V | Violet |
| W | White |
| Y | Yellow |
WIRING COLOR CODES REFERENCE CHART
Scheme 37
Scheme 38
Scheme 39
- When replacing a fuse, be sure to replace it with one of the same capacity. If a fuse fails again, the circuit probably has a short and the wiring should be inspected.
- Be sure the negative battery terminal is disconnected before replacing a main fuse.
- When replacing a pullout fuse, use the fuse puller.
Vehicle harness-side connector
The viewing direction of vehicle harness-side connectors is from the harness side.
* : Part names are shown only when there are multiple connector drawings.
