General Information: Other Mazda 6 GH рестайлинг

Range of Topics

1. This manual contains procedures for performing all required service operations. The procedures are divided into the following five basic operations: Removal/Installation Disassembly/Assembly Replacement Inspection Adjustment
2. Simple operations which can be performed easily just by looking at the vehicle (i.e., removal/installation of parts, jacking, vehicle lifting, cleaning of parts, and visual inspection) have been omitted.

Scheme 41

1. Inspection and adjustment procedures are divided into steps. Important points regarding the location and contents of the procedures are explained in detail and shown in the illustrations.

Scheme 42

1. Most repair operations begin with an overview illustration. It identifies the components, shows how the parts fit together, and describes visual part inspection. However, only removal/installation procedures that need to be performed methodically have written instructions.
2. Expendable parts, tightening torques, and symbols for oil, grease, and sealant are shown in the overview illustration. In addition, symbols indicating parts requiring the use of special service tools or equivalent are also shown.
3. Procedure steps are numbered and the part that is the main point of that procedure is shown in the illustration with the corresponding number. Occasionally, there are important points or additional information concerning a procedure. Refer to this information when servicing the related part.

Scheme 43

1. There are eight symbols indicating oil, grease, fluids, sealant, and the use of SST or equivalent. These symbols show application points or use of these materials during service.

Advisory Messages

1. You will find several Warnings, Cautions, Notes, Specifications and Upper and Lower Limits in this manual. WARNING: A Warning indicates a situation in which serious injury or death could result if the warning is ignored. CAUTION: A Caution indicates a situation in which damage to the vehicle or parts could result if the caution is ignored. NOTE: A Note provides added information that will help you to complete a particular procedure.

Upper and lower limits

1. The values indicate the upper and lower limits that must not be exceeded when performing inspections or adjustments.

Scheme 44

UNITS

UNITS REFERENCE CHART

Conversion from SI Units (Systeme International d'Unites)

1. All numerical values in this manual are based on SI units. Numbers shown in conventional units are converted from these values.

Number Of Digits For Converted Values

1. The number digits for converted values is the same as the number of significant figures *1 of the SI unit.
2. For the torque value, the number of significant figures is, in principle, is 2 digits, in consideration of market practicalities. However, if the number of decimal places at the upper and lower limits of the converted value differs, the one with least number of decimal places is used. In addition, if the integer part is 3 digits or more, the integer part becomes the significant number of figures.

*1 : The number of significant figures is the number of digits from the left-most non-zero digit to the right-most digit including 0. (Example: 0.12 is 2 digits, 41.0 is 3 digits)

Converted Value Rounding Off And Rounding Up/down

1. If there is no tolerance in the SI unit value, after conversion, rounding off is to within the number of significant digits.
2. If there is tolerance in the SI unit value and the figure after conversion indicates the upper limit, the number of digits is rounded down to within the number of significant figures. If it indicates the lower limit, they are rounded up to within the number of significant figures.
3. Even if the SI unit value is the same, the converted value may differ based on whether that value is the upper or lower limit.

Injury/damage Prevention Precautions

1. Depending on the vehicle, the cooling fan may operate suddenly even when the ignition is switched to off. Therefore, keep hands and tools away from the cooling fan even if the cooling fan is not operating to prevent injury to personnel or damage to the cooling fan. Always disconnect the negative battery cable when servicing the cooling fan or parts near the cooling fan.

Scheme 45

1. Always be sure to cover fenders, seats and floor areas before starting work.

Scheme 46

1. Be sure that all necessary tools and measuring equipment are available before starting any work.

Scheme 47

1. Use special service tools or equivalent when they are required.

Negative Battery Cable Disconnection/connection

Negative battery cable disconnection/required procedures after connecting

NEGATIVE BATTERY CABLE DISCONNECTION/REQUIRED PROCEDURES REFERENCE CHART

Dynamometer

1. When inspecting and servicing the power train on the dynamometer or speed meter tester, pay attention to the following: Place a fan, preferably a vehicle-speed proportional type, in front of the vehicle. Make sure the vehicle is in a facility with an exhaust gas ventilation system. Keep the rear bumper cool by placing a cooling fan near the exhaust pipe so that the rear bumper does not get deformed by the heat from the exhaust. Keep the area around the vehicle uncluttered so that heat does not build up. Watch the water temperature gauge and don't overheat the engine. Avoid added load to the engine and maintain normal driving conditions as much as possible. NOTE: When only the front or rear wheels are rotated on a chassis dynamometer or equivalent, the DSC HU/CM determines that there is a malfunction in the DSC and illuminates the following lights: ABS warning light Brake system warning light DSC indicator light If the above lights are illuminated, dismount the vehicle from the chassis dynamometer and switch the ignition OFF (LOCK). Then, switch the ignition ON, run the vehicle at 10 km/h {6.2 mph} or more and verify that the warning lights go out. In this case, a DTC will be stored in the memory. Clear the DTC from the memory by following the memory clearing procedure [DSC] in the on-board diagnostic system. (See «ON-BOARD DIAGNOSIS [DYNAMIC STABILITY CONTROL (DSC)]»(ref-448572-S14766025222012012000000) .)

SST

1. Some global SST or equivalent are used as SSTs necessary for engine repair. Note that these SSTs are marked with global SST numbers.
2. Note that a global SST number is written together with a corresponding Mazda SST number as shown below.

Example (SST List)

Scheme 48

Example (In Text)

Scheme 49

Direction of View for Connector

1. The viewing direction of connectors is indicated with a symbol.
2. The figures showing the viewing direction are the same as those used in Wiring Diagrams.
3. The viewing directions are shown in the following three ways

Part-side connector

The viewing direction of part-side connectors is from the terminal side.

* : Part names are shown only when there are multiple connector drawings.

Scheme 50

Other

When it is necessary to show the terminal side of vehicle harness-side connectors, such as the following connectors, the viewing direction is from the terminal side.

Scheme 51

1. Main fuse block and the main fuse block relays
2. Data link connector
3. Check connector
4. Relay box

Jumper wire

Scheme 52

1. A jumper wire is used to create a temporary circuit. Connect the jumper wire between the terminals of a circuit to bypass a switch.

Scheme 53

1. The DC voltmeter is used to measure circuit voltage. A voltmeter with a range of 15 V or more is used by connecting the positive (+) probe (red lead wire) to the point where voltage will be measured and the negative (-) probe (black lead wire) to a body ground.

Ohmmeter

Scheme 54

1. The ohmmeter is used to measure the resistance between two points in a circuit and to inspect for continuity and short circuits.

Precautions Before Welding

A vehicle has various electrical parts. To protect the parts from excessive current generated when welding, be sure to perform the following procedure.

Scheme 55

Scheme 56

1. Switch the ignition to OFF (LOCK).
2. Disconnect the battery cables.
3. Securely connect the welding machine ground near the welding area.
4. Cover the peripheral parts of the welding area to protect them from weld spatter.

Jacking Positions

1. Use safety stands to support the vehicle after it has been lifted.

Front

Note. To prevent obstruction between the jack body and front bumper when the jack body is inserted, use a low-floor type jack.

1. Near the center of the front crossmember.

Scheme 57

1. Near the center of the rear crossmember.

Front and rear

Scheme 58

1. Both sides of the vehicle, on side sills.

Scheme 59

1. Proper lifting and towing are necessary to prevent damage to the vehicle. Government and local laws must be followed.
2. A towed vehicle usually should have its drive wheels (front wheels) off the ground. If excessive damage or other conditions prevent this, use wheel dollies.
3. When towing with the rear wheels on the ground, release the parking brake.

Scheme 60

Scheme 61

Scheme 62

1. When transporting the vehicle by flat bed tow truck or trailer, secure the vehicle to the trailer using the holes and left tiedown loop shown in the illustration.

SAE STANDARDS

1. In accordance with new regulations, SAE (Society of Automotive Engineers) standard names and abbreviations are now used in this manual. The table below lists the names and abbreviations that have been used in Mazda manuals up to now and their SAE equivalents.

SAE STANDARDS REFERENCE CHART

Exterior

INSPECT and ADJUST, if necessary, the following items to specification

1. Glass, exterior bright metal and paint for damage
2. Wheel lug nuts
3. All weatherstrips for damage or detachment
4. Tire pressures
5. Operation of hood release and lock
6. Operation of trunk lid and fuel-filler lid opener
7. Door operation and alignment including side door and back door
8. Headlight aiming

INSTALL the following parts

1. Flap (front)
2. Wheel caps or rings (if equipped)

Under hood-engine off

INSPECT and ADJUST, if necessary, the following items to specification

1. Fuel, engine coolant, and hydraulic lines, fittings, connections, and components for leaks
2. Engine oil level
3. Power steering fluid level
4. Brake and clutch fluid level
5. Windshield washer reservoir fluid level
6. Radiator coolant level and specific gravity
7. Tightness of water hose clamps
8. Tightness of battery terminals, electrolyte level and specific gravity

Interior

INSTALL the following items

1. Fuse for accessories

INSPECT the operations of the following items

1. Seat controls (slide and recline) and headrests
2. Folding rear seat
3. Door locks, including childproof door locks
4. Seat belts and warning system
5. Ignition switch and steering lock
6. Transaxle range switch
7. Warning buzzers
8. Ignition key reminder alarm
9. Air bag system using warning light
10. Cruise control system (if equipped)
11. Power door lock
12. Shift-lock system (if equipped)
13. Starter interlock
14. All lights including warning, and indicator lights
15. Horn, wipers, and washers
16. Wiper blades performance

Clean wiper blades and windshield, if necessary

1. Antenna
2. Audio system
3. Cigarette lighter and clock
4. Power windows (if equipped)
5. Heater, defroster, and air conditioner at various mode selections (if equipped)

INSPECT the following items

1. Presence of spare fuse
2. Upholstery and interior finish

INSPECT and ADJUST, if necessary, the following items

1. Operation and fit of windows
2. Pedal height and free play of clutch pedal
3. Parking brake

Under hood-engine running at operating temperature

INSPECT the following items

1. Automatic transaxle fluid level
2. Operation of idle-up system for electrical load, air conditioner or power steering (if equipped)
3. Ignition timing
4. Idle speed
5. Operation of throttle position sensor
6. Operation of EGR valve

On hoist

INSPECT the following items

1. Manual transaxle oil level
2. Underside fuel, coolant and hydraulic lines, fittings, connections, and components for leaks
3. Tires for cuts or bruises
4. Steering linkage, suspension, exhaust system, and all underside hardware for looseness or damage

Schedule 1 (Normal Driving Conditions) for USA

1. The vehicle is mainly operated where none of the "unique driving conditions" apply.

MAINTENANCE SCHEDULE CHART

Schedule 2 CANADA, Puerto Rico, and (Unique Driving Conditions) for USA

1. Repeated short-distance driving
2. Driving in dusty conditions
3. Driving with extended use of brakes
4. Driving in areas where salt or other corrosive materials are used
5. Driving on rough or muddy roads
6. Extended periods of idling or low-speed operation
7. Driving for long periods in cold temperatures or extremely humid climates
8. Driving in extremely hot conditions
9. Driving in mountainous conditions continually

MAINTENANCE SCHEDULE CHART

Schedule 1 (Normal Driving Conditions) for Mexico

1. The vehicle is mainly operated where none of the "unique driving conditions" apply.

MAINTENANCE SCHEDULE CHART

Schedule 2 (Unique Driving Conditions) for Mexico

1. Repeated short-distance driving
2. Driving in dusty conditions
3. Driving with extended use of brakes
4. Driving in areas where salt or other corrosive materials are used
5. Driving on rough or muddy roads
6. Extended periods of idling or low-speed operation
7. Driving for long periods in cold temperatures or extremely humid climates
8. Driving in extremely hot conditions
9. Driving in mountainous conditions continually

MAINTENANCE SCHEDULE CHART

MAINTENANCE SCHEDULE CHART
