Interior Trim: Removal & Installation Mazda 6 GH рестайлинг

CENTER PANEL UPPER REMOVAL/INSTALLATION

Scheme 45

Scheme 46

Scheme 47

1. Disconnect the negative battery cable.
2. Insert a tape-wrapped fastener remover into the position indicated by the arrow in the illustration, slide it to remove the hook A and clips B, and raise the front side of the center panel upper.
3. Pull the center panel upper in the direction of the arrow shown in the illustration and remove it while detaching clips C.
4. Disconnect the center speaker connector.
5. Disconnect the hazard warning switch connector.
6. Disconnect the information display connector.
7. Install in the reverse order of removal.

Scheme 48

1. Disconnect the negative battery cable.
2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-448656-S41204061692012012000000) .) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-448656-S12186936852012012000000) .) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-448657-S11374618932012012000000) .) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-448656-S21764171192012012000000) .)
3. Pull the center panel lower in the direction of the arrow(1) shown in the illustration while detaching clips B.
4. Pull the center panel lower in the direction of the arrow(2) shown in the illustration and remove it while detaching clips B and hooks A.
5. Disconnect the PAD indicator light bulb connector. (Vehicles with PAD indicator light bulb)
6. Disconnect the seat warmer switch connector. (Vehicles with seat warmer)
7. Disconnect the advanced keyless entry and push button start connector. (Vehicles with advanced keyless entry and push button start system)
8. Disconnect the accessory socket (front) connector.
9. Disconnect the cigarette lighter socket connector. (Arab Gulf Cooperation Council)
10. Install in the reverse order of removal.

Scheme 49

1. Disconnect the negative battery cable.
2. Remove the following parts: Driver-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S42845656582012012000000) .) Driver-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-448656-S24645152862012012000000) .) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-448656-S41204061692012012000000) .) Driver-side decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-448656-S12186936852012012000000) .) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-448614-S41008846102012012000000) .) Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-448656-S09959257172012012000000) .)
3. Remove the screw A, pull the lower panel in the direction of the arrow in the order of (1) (2), (3) and remove the lower panel while detaching the hooks B, C, clips D and guide pin E.
4. Disconnect the switch connector.
5. Install in the reverse order of removal.

Scheme 50

1. Pull the side panel in the direction of the arrow in the order of (1) and (2), then remove it while detaching the clips A, B, C and guide D.
2. Remove the side panel.
3. Install in the reverse order of removal.

Scheme 51

1. Pull the meter hood in the direction of the arrow shown in the illustration and remove it while detaching the clips A, tab B and blind rubber.
2. Remove the meter hood.
3. Install in the reverse order of removal.

GLOVE COMPARTMENT REMOVAL/INSTALLATION

Scheme 52

Scheme 53

Scheme 54

1. Pull the stay damper in the direction of the arrow shown in the illustration, and detach the connecting part between the glove compartment and the stay damper.
2. Push both ends of the inner-side glove compartment in the direction of the arrow shown in the illustration.
3. Lower the glove compartment in the direction of the arrow shown in the illustration.
4. Detach the hook from the dashboard in the direction of the arrow shown in the illustration and remove the glove compartment.
5. Install in the reverse order of removal.

Scheme 55

1. Disconnect the negative battery cable.
2. Remove the center panel upper. (See «CENTER PANEL UPPER REMOVAL/INSTALLATION»(ref-448656-S12464949122012012000000) .)
3. Remove the screw.
4. Remove the center ventilator grille from the center panel upper.
5. Install in the reverse order of removal.

Scheme 56

1. Pull out the fin of the side ventilator grill with turning it while disconnecting the tab of the ventilator grill cover.
2. Install in the reverse order of removal.

Scheme 57

1. Disconnect the negative battery cable.
2. Remove the rear console panel. (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-448656-S24311442192012012000000) .)
3. Remove the tabs A
4. Remove the rear ventilator grille.
5. Install in the reverse order of removal.

Scheme 58

1. Disconnect the negative battery cable.
2. Remove the following parts: Driver-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S42845656582012012000000) .) Drive-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-448656-S24645152862012012000000) .) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-448656-S41204061692012012000000) .) Drive-side decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-448656-S12186936852012012000000) .) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-448614-S41008846102012012000000) .) Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-448656-S09959257172012012000000) .) Drive-side lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-448656-S04202039792012012000000) .)
3. Remove the bolts.
4. Remove the knee bolster.
5. Install in the reverse order of removal.

Scheme 59

1. Detach clip A, pin B and guide C by pulling them in the direction of the arrow (1), (2).
2. Remove the dashboard under cover.
3. Install in the reverse order of removal.

UPPER PANEL REMOVAL/INSTALLATION

Scheme 60

Scheme 61

1. Pull the upper panel in the direction of the arrow in the order of (1) and (2), then remove it while detaching the clip A, B and C.
2. Move the upper panel in the direction of the arrow in the order of (3), and remove it.
3. install in the reverse order of removal.

Scheme 62

Scheme 63

1. Remove the shift knob. (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-448657-S11374618932012012000000) .)
2. Pull the shift panel in the direction of the arrow shown in the illustration and remove it while detaching the hooks. ATX MTX
3. Remove the shift panel.
4. Install in the reverse order of removal.

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

1. Disconnect the negative battery cable.
2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-448656-S41204061692012012000000) .) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-448657-S11374618932012012000000) .) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-448656-S21764171192012012000000) .) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-448656-S12186936852012012000000) .) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-448656-S13809786282012012000000) .)
3. Disconnect the auxiliary jack connector and accessory socket connector.
4. Remove the screws A, B and screw C.
5. Open the console lid and remove the storage box and mat.
6. Remove the screws D.
7. Pull the rear console in the direction of the arrow in the order of (1), then detaching clip E.
8. Pull up the rear console in the direction of the arrow (2) shown in the illustration, move the rear console in the direction of the arrow (3), and remove it avoiding the parking brake lever.
9. Install in the reverse order of removal.

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

1. Disconnect the negative battery cable.
2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-448656-S41204061692012012000000) .) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-448657-S11374618932012012000000) .) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-448656-S21764171192012012000000) .) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-448656-S12186936852012012000000) .) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-448656-S13809786282012012000000) .)
3. Disconnect the auxiliary jack connector and accessory socket connector.
4. Remove the screws A, B and screw C.
5. Open the console lid and remove the storage box and mat.
6. Remove the screws D.
7. Remove the dip F and hook G.
8. Remove the rear console panel.
9. Remove the rear fan switch connector.
10. Remove the screw H.
11. Pull the rear console in the direction of the arrow in the order of (1), then detaching clip E.
12. Pull up the rear console in the direction of the arrow (2) shown in the illustration, move the rear console in the direction of the arrow (3), and remove it avoiding the parking brake lever.
13. Install in the reverse order of removal.

TRUNK SIDE TRIM REMOVAL/INSTALLATION

1. Remove the trunk end trim. (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-448656-S09132241602012012000000) .)
2. Remove the rear seat cushion. (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-448628-S22827010952012012000000) .)
3. Remove the rear side seat back. (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-448628-S17042362982012012000000) .)

Scheme 75

1. Remove the fasteners and hook, then remove the trunk side trim. (See «HOOK REMOVAL NOTE»(ref-448656-S01147596512012012000000) .)
2. Install in the reverse order of removal.

Scheme 76

1. Remove the fasteners and hook, then remove the trunk side trim. (See «HOOK REMOVAL NOTE»(ref-448656-S01147596512012012000000) .)
2. Install in the reverse order of removal.

Hook Removal Note

1. Remove hook by inserting a small flathead screwdriver into the service hole as shown in the illustration.

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

1. Disconnect the negative battery cable.
2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-448656-S17163868202012012000000) .)
3. Pull the cover of inner handle and remove it while detaching tabs.
4. Remove the recess cover.
5. Remove the screws.
6. Pull in the direction of the arrow shown in the illustration and remove clips from the door inner panel using a fastener remover.
7. Remove the front door trim in the direction of the arrow shown in the illustration.
8. Remove the inner handle and move the front door trim in the direction of the arrow shown in the illustration.
9. Turn the inner handle 90° in the direction of the arrow and remove it from the front door trim.
10. Disconnect the power outer mirror switch connector and power window main switch connector. (driver-side)
11. Disconnect the power window subswitch connector. (passenger-side)
12. Remove the door courtesy illumination bulb socket. (See «COURTESY LIGHT BULB REMOVAL/INSTALLATION»(ref-448651-S24277826812012012000000) .)
13. Install in the reverse order of removal.

Installation

1. insert the assist handle in the assist handle bracket.
2. Push the assist handle cover in the direction of the arrow shown in the illustration to install the assist handle.

Scheme 83

Scheme 84

1. Disconnect the negative battery cable.
2. Remove the screw.
3. Rotate the sunvisor in the direction of the arrow.
4. Unhook and remove the sunvisor.
5. Disconnect the vanity mirror illumination connector.
6. Press the center adaptor tabs as shown in the illustration using two tape-wrapped flathead screwdrivers, and remove the center adaptor.
7. Install in the reverse order of removal.

Scheme 85

Scheme 86

Scheme 87

1. Disconnect the negative battery cable.
2. Partially peel back the seaming welt.
3. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-448630-S41753305522012012000000) .)
4. Disconnect the rain sensor connector. (Vehicles auto light/wiper system)
5. Remove the following parts: Sunroof seaming welt (vehicles with sunroof system) A-pillar trims (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-448656-S22638988852012012000000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S42845656582012012000000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S10692943582012012000000) .) B-pillar lower trims (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-448656-S35625955382012012000000) .) Front seat belt upper anchor installation bolts (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-448671-S24354888492012012000000) .) B-pillar upper trims (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-448656-S29824177632012012000000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-448628-S22827010952012012000000) .) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-448628-S17042362982012012000000) .) C-pillar trims (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-448656-S21191719082012012000000) .)
6. Disconnect the auto-dimming mirror connector. (vehicles with auto-dimming mirror)
7. Remove the sunvisors. (See «SUNVISOR REMOVAL/INSTALLATION»(ref-448656-S17577240092012012000000) .)
8. Remove the map light. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-448651-S38096746852012012000000) .)
9. Remove the assist handle. (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-448656-S04086798262012012000000) .)
10. Disconnect the roof harness connector, remove the clip, and remove the connector.
11. Remove the fasteners.
12. Remove the retainer holding the roof panel and remove the headliner.
13. Take the headliner off from the passenger-side door opening.
14. Install in the reverse order of removal.

Scheme 88

Scheme 89

1. Disconnect the negative battery cable.
2. Remove the following parts: Front seats (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-448628-S07156841762012012000000) .) Audio amplifier (Vehicles with Bose® system) (See «AUDIO AMPLIFIER REMOVAL/INSTALLATION»(ref-448591-S23931709092012012000000) .) Front scuff plates (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S42845656582012012000000) .) Rear scuff plates (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S10692943582012012000000) .) Front side trims (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-448656-S24645152862012012000000) .) Steering shaft cover (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-448619-S01292366382012012000000) .) (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-448619-S18771656912012012000000) .) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-448656-S41204061692012012000000) .) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-448656-S12186936852012012000000) .) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM LOCATION INDEX»(ref-448657-S31582424492012012000000) .) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-448656-S21764171192012012000000) .) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-448656-S13809786282012012000000) .) Rear console (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-448656-S24311442192012012000000) .) B-pillar lower trims (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-448656-S35625955382012012000000) .) Fuel-filler lid opener bezel (See «FUEL-FILLER LID OPENER BEZEL REMOVAL/INSTALLATION»(ref-448656-S05403168622012012000000) .) Front seat belt lower anchor installation bolts (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-448671-S24354888492012012000000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-448628-S22827010952012012000000) .) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-448628-S17042362982012012000000) .)
3. Remove the fasteners A and B.
4. Remove the flange cap nuts C and harness clips D.
5. Take the floor covering off from the front passenger-side door opening.
6. Install in the reverse order of removal.
