Interior Trim: Other Mazda 6 GH рестайлинг

Vehicles Without Rear Ventilator Grille

1. Disassemble in the order indicated in the table.
2. Assemble in the reverse order of disassembly.

Scheme 95

PARTS DESCRIPTION CHART

Vehicles With Rear Ventilator Grille

1. Disassemble in the order indicated in the table.
2. Assemble in the reverse order of disassembly.

Scheme 96

PARTS DESCRIPTION CHART

Scheme 97

1. Remove the upper panel. (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-448656-S41204061692012012000000) .)
2. Pull the decoration panel in the direction of the arrow in the order of (1) and (2), then remove it while detaching the hooks A, clips B and pin C.
3. Remove the decoration panel.
4. Install in the reverse order of removal.

Scheme 98

1. Remove the upper panel. (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-448656-S41204061692012012000000) .)
2. Pull the decoration panel in the direction of the arrow in the order of (1) and (2), then remove it while detaching the hooks A, clips B and pin C.
3. Remove the decoration panel.
4. Install in the reverse order of removal.

Scheme 99

1. Partially peel back the seaming welt.
2. Pull the upper end of the A-pillar trim in the direction of the arrow (1), (2) shown in the illustration and remove clip A, B and tab C. CAUTION: When pulling out the A-pillar trim, be careful not to damage the tabs.
3. When installing the A-pillar, Install the new clip A to the A-pillar trim in advance.
4. Install in the reverse order of removal.

Scheme 100

1. Remove the front scuff plate. (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S42845656582012012000000) .)
2. Partially peel back the seaming welt.
3. Remote the cap nut
4. Pull the front side trim in the direction of the arrow shown in the illustration and remove it while detaching clip.
5. Remove the front side trim.
6. Install in the reverse order of removal.

Scheme 101

1. Remove the following parts: High-mount brake light (See «HIGH-MOUNT BRAKE LIGHT REMOVAL/INSTALLATION»(ref-448651-S22360427792012012000000) .) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-448628-S17042362982012012000000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-448656-S21191719082012012000000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-448628-S22827010952012012000000) .)
2. Fold the rear seat back.
3. Remove the fastener A.
4. Pull up the rear package trim in the direction of the arrow (1) shown in the illustration to remove the clips B, pull the rear package trim in the direction of the arrow (2), and remove it while pulling out the guides C.
5. Remove the rear package trim.
6. Install in the reverse order of removal.

Scheme 102

1. Remove the front scuff plate. (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S42845656582012012000000) .)
2. Remove the rear scuff plate. (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S10692943582012012000000) .)
3. Partially peel back the seaming welt.
4. Pull the B-pillar lower trim in the direction of the arrow (1), (2), (3) shown in the illustration, detach pin A, tab B, clip C, pin D, and clip E then remove the B-pillar lower trim.
5. Remove the B-pillar lower trim.
6. Install in the reverse order of removal.

Scheme 103

Scheme 104

1. Remove the following parts: Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S42845656582012012000000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S10692943582012012000000) .) Adjuster anchor cover (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-448671-S24354888492012012000000) .) Front seat belt upper anchor installation bolts (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-448671-S24354888492012012000000) .)
2. Partially peel back the seaming welt.
3. Remove the B-pillar lower trim. (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-448656-S35625955382012012000000) .)
4. Grasp the lower end of the B-pillar upper trim, pull it in the direction of the arrow shown in the illustration, and remove clip A, pin B, and hook C.
5. Remove the B-pillar upper trim in the direction of the arrow shown in the illustration. CAUTION: When removing the B-pillar upper trim, be careful not to damage the tabs.
6. Install in the reverse order of removal.

Scheme 105

Scheme 106

1. Remove the following parts: Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-448628-S22827010952012012000000) .) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-448628-S17042362982012012000000) .)
2. Partially peel back the seaming welt.
3. Pull the C-pillar trim in the direction of the arrow (1), (2), (3) shown in the illustration, then detaching clip A and B.
4. Remove the C-pillar trim in the direction of the arrow shown in the illustration while remove the tabs C and D. CAUTION: When removing the C-pillar trim, be careful not to damage the tabs C and D.
5. When installing the C-pillar, install the new clip A to the C-pillar trim in advance.
6. Install in the reverse order of removal.

Scheme 107

1. Detach tabs A while pulling the front scuff plate in the direction of the arrow (1) shown in the illustration, then detach tabs B, pins C, clips D, pin E and guides F while pulling in the direction of the arrow (2).
2. Remove the front scuff plate.
3. Install in the reverse order of removal.

Scheme 108

1. Remove the rear seat cushion. (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-448628-S22827010952012012000000) .)
2. Remove the fastener A.
3. Detach tab B while pulling the rear scuff plate in the direction of the arrow (1) shown in the illustration, then detach tab C, pin D, E, clip F and G while pulling in the direction of the arrow (2).
4. Remove the rear scuff plate.
5. Install in the reverse order of removal.

Scheme 109

1. Disconnect the negative battery cable.
2. Pull the inner garnish in the direction of the arrow shown in the illustration and remove it while detaching clips and tab.
3. Disconnect the front tweeter connector. (Vehicles with tweeter)
4. Install in the reverse order of removal.

Scheme 110

Scheme 111

1. Remove the screw.
2. Move the fuel-filler lid opener bezel in the direction of the arrow shown in the illustration.
3. Install in the reverse order of removal.

Driver-side

1. Disassemble in the order shown in the illustration.
2. Assemble in the reverse order of disassemble.

Scheme 112

PARTS DESCRIPTION CHART

Passenger-side

1. Disassemble in the order shown in the illustration.
2. Assemble in the reverse order of disassemble.

Scheme 113

PARTS DESCRIPTION CHART

Scheme 114

Scheme 115

Scheme 116

Scheme 117

Scheme 118

1. Disconnect the negative battery cable.
2. Pull the cover of inner handle and remove it while detaching tabs.
3. Remove the recess cover.
4. Remove the screws.
5. Pull in the direction of the arrow shown in the illustration and remove clips from the door inner panel using a fastener remover.
6. Remove the rear door trim in the direction of the arrow shown in the illustration.
7. Remove the inner handle and move the rear door trim in the direction of the arrow shown in the illustration.
8. Turn the inner handle 90° in the direction of the arrow and remove it from the rear door trim.
9. Disconnect the power window subswitch connector.
10. Install in the reverse order of removal.

Scheme 119

1. Remove the recess. (See «RECESS REMOVAL/INSTALLATION»(ref-448656-S23387134952012012000000) .)
2. Remove the fasteners, then remove the trunk lid trim.
3. Install in the reverse order of removal.

Scheme 120

Scheme 121

1. Insert a fastener remover in the position indicated by the arrow in the illustration and detach tabs A.
2. Remove the recess in the direction of the arrow shown in the illustration avoiding tabs B.
3. Install in the reverse order of removal.

Scheme 122

1. Insert a fastener remover into the assist handle service hole and remove the assist handle cover.
2. Insert the fastener remover in the position indicated by the arrow in the illustration, push down the dip by moving the fastener remover in the direction of the arrow, and remove the assist handle from the assist handle bracket while shaking the assist handle up and down.

Scheme 123
