Control System - HVAC (Full Auto Air Conditioner): Overview Mazda 6 GH рестайлинг

Scheme 1

PARTS DESCRIPTION CHART

Scheme 2

1. Disconnect the negative battery cable.
2. Remove the glove compartment. (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION».)
3. Remove in the order indicated in the table. PARTS DESCRIPTION CHART 1 Air intake actuator connector 2 Air intake actuator (See «AIR INTAKE ACTUATOR INSTALLATION NOTE».)
4. Install in the reverse order of removal.

Scheme 3

1. Insert the air intake actuator shaft to the door hole aligned with each shape same as removed position.

Scheme 4

1. Connect battery positive voltage to air intake actuator terminal A (or B), connect terminal B (or A) to ground, and then verify that the air intake actuator operates as shown in the table. If the operation condition is not normal, replace the air intake actuator. TERMINALS DESCRIPTION CHART Terminal Air intake actuator operation A B Ground B+ FRESH --> RECIRCULATE B+ Ground RECIRCULATE --> FRESH

Scheme 5

1. Disconnect the negative battery cable.
2. Remove in the order indicated table. PARTS DESCRIPTION CHART 1 Air mix actuator connector 2 Air mix actuator (See «AIR MIX ACTUATOR INSTALLATION NOTE».)
3. Install in the reverse order of removal.

Scheme 6

1. Disconnect the negative battery cable.
2. Remove the following parts. Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION».) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION».) Front scuff plates (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION».) Front side trims (See «FRONT SIDE TRIM REMOVAL/INSTALLATION».) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION».) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION».) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM LOCATION INDEX»(/mazda/6/gh-2009-2013/remont/manual-trans/#manual-transmission-manual-transaxle-shift-mechanism).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION».) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION».) Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]».) Rear console (See «REAR CONSOLE REMOVAL/INSTALLATION».) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION».) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION».) Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION».) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]».) (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]».) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION».) (17) Combination switch (See «COMBINATION SWITCH REMOVAL/INSTALLATION».) Meter hood (See «METER HOOD REMOVAL/INSTALLATION».) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION».) (20) Center panel upper (See «CENTER PANEL UPPER REMOVAL/INSTALLATION».) Audio unit (See «AUDIO UNIT REMOVAL/INSTALLATION».) Steering shaft cover (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]».) (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]».) Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]».) (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]».) Side panel (See «SIDE PANEL REMOVAL/INSTALLATION».) SIRIUS satellite radio unit (See «SIRIUS SATELLITE RADIO UNIT REMOVAL/INSTALLATION».) Passenger-side air bag module (See «PASSENGER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION».) A-pillar trims (See «A-PILLAR TRIM REMOVAL/INSTALLATION».) Dashboard (See «DASHBOARD REMOVAL/INSTALLATION».)
3. Remove the A/C unit. (See «A/C UNIT REMOVAL/INSTALLATION».)
4. Disassemble the A/C unit. (See «A/C UNIT DISASSEMBLY/ASSEMBLY».)
5. Remove in the order indicated table. PARTS DESCRIPTION CHART 1 Air mix actuator connector 2 Air mix actuator (See «AIR MIX ACTUATOR INSTALLATION NOTE».)
6. Install in the reverse order of removal.

See also:
• MANUAL TRANSAXLE SHIFT MECHANISM LOCATION INDEX
