Starting/charging 2.3l — 2.3l, starting circuit Mazda 6 GH
All systems — 38 systems
- Air conditioning 2.3l 2
- Air conditioning 3.0l 2
- Anti-lock brakes 2
- Anti-theft 2
- Body control modules
- Computer data lines
- Cooling fan 2.3l
- Cooling fan 3.0l
- Cruise control 2.3l
- Cruise control 3.0l
- Defoggers
- Engine performance 2.3l 2
- Engine performance 3.0l
- Exterior lights 2
- Ground distribution
- Headlights 2
- Horn
- Instrument cluster 2
- Interior lights 2
- Navigation
- Power distribution
- Power door locks 2
- Power mirrors
- Power seats 2
- Power top/sunroof
- Power windows
- Radio 2
- Shift interlock
- Starting/charging
- Starting/charging 2.3l
- Starting/charging 3.0l
- Supplemental restraints
- Transmission
- Transmission 2.3l
- Transmission 3.0l
- Trunk, tailgate, fuel door
- Warning systems
- Wiper/washer 2
Components on these wiring diagrams 9
Click a component to highlight it on every diagram it appears on.
