STARTER REMOVAL/INSTALLATION [L3, AJ]
| WARNING | When the battery cables are connected, touching the vehicle body with starter terminal B generates sparks. This cap cause personal injury, fire, and damage to the electrical components. Always disconnect the battery before performing the following operation. |
Scheme 19
- Disconnect the negative battery cable.
- Remove the air cleaner. (See «INTAKE AIR SYSTEM REMOVAL/INSTALLATION [L3]»(ref-288764-S40241065462008062500000) ).
- Remove the under cover.
- Remove the clutch release cylinder with the pipes still connected. (MTX) (See «CLUTCH RELEASE CYLINDER REMOVAL/INSTALLATION [G35M-R, A65M-R]»(ref-288791-S42915850162008062500000) ).
- Remove in the order indicated in the table.
- Install in the reverse order of removal.
Starter Installation Note
Note. If there is peeling on or damage to the insulator, attach a new insulator using the following procedure: Peel off the insulator from the starter completely using a scraper. Degrease the insulator attachment area. Attach a new insulator to the starter.
Scheme 20
Scheme 21
- Remove the battery and the battery tray. (See «BATTERY REMOVAL/INSTALLATION [L3, AJ]»(ref-288749-S37743279082008062500000) ).
- Remove the air cleaner. (See «INTAKE AIR SYSTEM REMOVAL/INSTALLATION [AJ]»(ref-288770-S05460329182008062500000) ).
- Disconnect the selector cable and the selector cable bracket. (See «SELECTOR LEVER COMPONENT REMOVAL/INSTALLATION»(ref-288765-S18622223502008062500000) ). (ATX)
- Position the harness bracket out of the way. (ATX)
- Remove in the order indicated in the table. MTX ATX
- Install in the reverse order of removal.
