Seats: Removal & Installation Mazda 6 GH

Seats 9 illustrations ~360 words

FRONT SEAT REMOVAL/INSTALLATION [EXCEPT L3 WITH TC]

WARNINGHandling the front seat (with a side air bag) improperly can accidentally deploy the side air bag, which may seriously injure you. Read air bag system service warnings and cautions before handling the front seat (with a side air bag). (See SERVICE WARNINGS. ) (See SERVICE CAUTIONS. )
CAUTIONWhen the passenger's seat is removed, perform the seat weight sensor inspection using the M-MDS after installing the passenger's seat. (See SEAT WEIGHT SENSOR INSPECTION. ) When the passenger's seat is replaced with a new one, perform the seat weight sensor calibration using the M-MDS. (See SEAT WEIGHT SENSOR CALIBRATION. )

Scheme 1

Scheme 1
Scheme 1
  1. Turn the ignition switch to the LOCK position.
  2. Disconnect the negative battery cable and wait for more than 1 minute.
  3. Remove the seat belt anchor (passenger's side). (See «FRONT SEAT BELT REMOVAL/INSTALLATION.»(ref-288742-S36285068912008062500000) )
  4. Remove in the order indicated in the table. (Scheme 1): Front Seat (Except L3 With TC) & Torque Specification
  5. Install in the reverse order of removal.

Seat Warmer Switch Removal Note

  1. Squeeze the tabs of seat warmer switch and pull it outward to remove it.

Scheme 2

Scheme 2: SEAT WARMER SWITCH INSPECTION
Scheme 2: SEAT WARMER SWITCH INSPECTION

Scheme 3

Scheme 3
Scheme 3
  1. Inspect for continuity between the seat warmer switch terminals using an ohmmeter. If not as specified, replace the seat warmer switch. (Scheme 3): Seat Warmer Switch Continuity Reference Chart (Scheme 4): Inspecting For Continuity Between Seat Warmer Switch Terminals

Scheme 4

Scheme 4: Seat Cushion
Scheme 4: Seat Cushion

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7
  1. Remove the front seat. (See «FRONT SEAT REMOVAL/INSTALLATION [EXCEPT L3 WITH TC]»(ref-288736-S34803982802008062500000) ).
  2. Remove the seat cushion trim. (See «FRONT SEAT DISASSEMBLY/ASSEMBLY [EXCEPT L3 WITH TC]»(ref-288736-S15282853952008062500000) ).
  3. While inspecting for continuity between the connector terminals A and B, use a dryer to warm the thermostat of the seat warmer unit on seat cushion. (Scheme 5): Drying To Warm Thermostat Of Seat Warmer Unit On Seat Cushion
  4. When the ohmmeter indicates that there is no continuity, turn off the dryer, then use a thermometer to measure the temperature of the thermostat.
  5. Verify that the temperature is approx. 37 °C {99 °F}. (Scheme 6): Measuring Temperature Of Thermostat
  6. Using an ohmmeter, verify that there is continuity between the seat warmer unit connector terminals when temperature drops to approx. 28 °C {82 °F}. If not as indicated in the table, replace the seat warmer unit. (Scheme 7): Thermostat Temperature Continuity Reference Chart (Scheme 8): Measuring Continuity Between Seat Warmer Unit Connector Terminals

Scheme 8

Scheme 8: Seat Back
Scheme 8: Seat Back

Scheme 9

Scheme 9
Scheme 9
  1. Remove the front seat. (See «FRONT SEAT REMOVAL/INSTALLATION [EXCEPT L3 WITH TC]»(ref-288736-S34803982802008062500000) ).
  2. Verify that the continuity between terminals A and B is as indicated in the table. If not as indicated in the table, replace the seat warmer unit. (Scheme 9): Continuity Reference Chart see scheme 38: Measuring Continuity Between Terminals A And B
