Power Systems: Other Mazda 6 GH

Ignition Switch/steering Lock 14 illustrations ~287 words

FUSE SERVICE CAUTION

CAUTIONDetermine and correct the cause of the burned fuse before replacing it with the specified type. If the fuse is replaced before doing this, it may burn again.

Scheme 4

Scheme 4: MAIN FUSE REMOVAL/INSTALLATION
Scheme 4: MAIN FUSE REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the main fuse block cover.
  3. Remove in the order indicated in the table.
  4. Install in the reverse order of removal.

Scheme 5

Scheme 5: Bolt Removal Note
Scheme 5: Bolt Removal Note

Scheme 6

Scheme 6
Scheme 6
  1. Press and remove the tabs on the main fuse block at the positions indicated by the arrows.
  2. Lift up the main fuse block and remove the bolts.

Scheme 7

Scheme 7: FUSE BLOCK REMOVAL/INSTALLATION
Scheme 7: FUSE BLOCK REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the left-side front side trim. (See «FRONT SIDE TRIM REMOVAL/INSTALLATION.»(ref-288737-S15216966322008062500000) )
  3. Remove in the order indicated in the table.
  4. Install in the reverse order of removal.

Scheme 8

Scheme 8: IGNITION SWITCH REMOVAL/INSTALLATION
Scheme 8: IGNITION SWITCH REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION.»(ref-288737-S02237188592008062500000) )
  3. Remove in the order indicated in the table.
  4. Install in the reverse order of removal.

Scheme 9

Scheme 9: IGNITION SWITCH INSPECTION
Scheme 9: IGNITION SWITCH INSPECTION

Scheme 10

Scheme 10
Scheme 10
  1. Disconnect the negative battery cable.
  2. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION.»(ref-288737-S02237188592008062500000) )
  3. Disconnect the ignition switch connectors.
  4. Inspect for continuity between the ignition switch terminals. If not as specified, replace the ignition switch.

Scheme 11

Scheme 11: KEY REMINDER SWITCH REMOVAL/INSTALLATION
Scheme 11: KEY REMINDER SWITCH REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the column cover.
  3. Disconnect the key reminder switch connector.
  4. Remove the key reminder switch.
  5. Install in the reverse order of removal.

Scheme 12

Scheme 12: KEY REMINDER SWITCH INSPECTION
Scheme 12: KEY REMINDER SWITCH INSPECTION

Scheme 13

Scheme 13
Scheme 13
  1. Disconnect the negative battery cable.
  2. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION.»(ref-288737-S02237188592008062500000) )
  3. Disconnect the key reminder switch connector.
  4. Inspect for continuity between the key reminder switch terminals. If not as specified, replace the key reminder switch.

Relay Type

Terminal typePart name
Four Terminal RelayType AMain relay Fuel pump relay Starter relay Starter relay No.2 TNS relay IG1 relay Front fog light relay (AJ engine) Horn relay Trunk lid opener relay Rear window defroster relay Woofer relay AT main relay ETC relay A/C relay Blower relay Cooling fan relay No.1 Cooling fan relay No.2 Cooling fan relay No.3 Cooling fan relay No.4 Back-up light relay
Type BHeadlight relay Front fog light relay (L3 engine) Cooling fan relay

RELAY TYPE REFERENCE

Scheme 14

Scheme 14: Type A
Scheme 14: Type A

Scheme 15

Scheme 15
Scheme 15
  1. Remove the relay.
  2. Inspect for continuity between the relay terminals. If not as specified, replace the relay.

Scheme 16

Scheme 16: Type B
Scheme 16: Type B

Scheme 17

Scheme 17
Scheme 17
  1. Remove the relay.
  2. Inspect for continuity between the relay terminals. If not as specified, replace the relay.

More articles — Power Systems
