PCM REMOVAL/INSTALLATION [L3 WITH TC]

Note. For PCM replacement, set up the WDS and perform the PCM configuration. (See PCM CONFIGURATION [L3 WITH TC] ).

Scheme 170

Scheme 170: PCM REMOVAL/INSTALLATION [L3 WITH TC]

Disconnect the negative battery cable.
Remove in the order indicated in the table.
Install in the reverse order of removal.

ENGINE COOLANT TEMPERATURE (ECT) SENSOR REMOVAL/INSTALLATION [L3 WITH TC]

WARNING

A hot engine can cause severe burns. Turn off the engine and wait until it is cool before removing the ECT sensor.

Scheme 171

Remove the charge air cooler cover.
Drain the engine coolant. (See «COOLING SYSTEM SERVICE WARNINGS [L3 WITH TC]»(ref-244581-S05532361152006092500000) ).
Disconnect the ECT sensor connector.
Remove the ECT sensor.
Install in the reverse order of removal. Tightening torque 10-14 N.m {1.02-1.42 kgf.m, 7.38-10.32 ft.lbf}
Refill the engine coolant. (See «COOLING SYSTEM SERVICE WARNINGS [L3 WITH TC]»(ref-244581-S05532361152006092500000) ).

FUEL PRESSURE SENSOR REMOVAL/INSTALLATION [L3 WITH TC]

Note. If the fuel pressure sensor is removed, do not reuse the fuel pressure sensor and the fuel delivery pipe. When you replace the fuel pressure sensor, replace a new fuel delivery pipe with a new fuel pressure sensor. 01-14B-25 FUEL INJECTOR REMOVAL/INSTALLATION [L3 WITH TC]

KNOCK SENSOR (KS) REMOVAL/INSTALLATION [L3 WITH TC]

CAUTION

Be careful not to impact the sensor. Verify that there is no debris between the sensor and the cylinder block before installing.

Scheme 172

Remove the intake manifold. (See «INTAKE AIR SYSTEM REMOVAL/INSTALLATION [L3 WITH TC]»(ref-244582-S40996001322006092500000) ).
Remove the KS attachment bolt to remove the KS.
Install in the reverse order of removal. Tightening torque 16-24 N.m {1.7-2.4 kgf.m, 12-17 ft.lbf}

Removal

Perform the following procedure to allow for enough working space. Remove the Front wheel (RH). Remove the splash shield.
Disconnect the CKP sensor connector.
Remove the installation bolts to remove the CKP sensor.

Installation

CAUTION

When foreign material, such as an iron chips, gets on the CKP sensor, it can cause abnormal output from the sensor because of flux turbulence and adversely affect engine control. Be sure there is no foreign material on the CKP sensor when replacing.

Scheme 173

Scheme 174

Perform the following procedure so that piston No.1 is at the top dead center. Remove the drive shaft (RH). (See «FRONT DRIVE SHAFT REMOVAL/INSTALLATION [L3, L3 WITH TC]»(ref-244605-S25656314442006092500000) ). Remove the cylinder block lower blind plug and install the SST . Turn the crankshaft pulley to the clockwise until it stops.
Using a straight edge, draw a straight line directly in the center of the twentieth tooth of the crankshaft pulley pulse wheel (counting counterclockwise from the empty space). CAUTION: If the line is not accurately drawn, ignition timing, fuel injection and other engine control systems will be adversely effected. Draw the straight line carefully using a straight edge.
Align the center line of the crankshaft position sensor and the line drawn in Step 2 , then install the sensor.
Install the CKP sensor fitting bolts. Tightening torque 5.5-7.5 N.m {56-76 kgf.cm, 49-66 in.lbf}
Remove the SST then install the cylinder block lower blind plug. Tightening torque 18-22 N.m {1.9-2.2 kgf.m, 14-16 ft.lbf}
Install the front drive shaft (RH). (See «FRONT DRIVE SHAFT REMOVAL/INSTALLATION [L3, L3 WITH TC]»(ref-244605-S25656314442006092500000) ).
