INSTALLATION OF RADIO SYSTEM
- If a radio system is installed improperly or if a high-powered type is used, the CIS and other systems may be affected. When the vehicle is to be equipped with a radio, observe the following precautions: Install the antenna at the farthest point from control modules. Install the antenna feeder as far as possible from the control module harnesses. Ensure that the antenna and feeder are properly adjusted. Do not install a high-powered radio system.
Scheme 11
- Before disconnecting connectors or removing electrical parts, disconnect the negative battery cable. (Scheme 11): Disconnecting Battery Cables
Scheme 12
Scheme 12: Wiring Harness
Scheme 13
- To remove the wiring harness from the clip in the engine room, pry up the hook of the clip using a flathead screwdriver. (Scheme 12): Prying Up Hook Of Clip Using Flathead Screwdriver CAUTION: Do not remove the harness protective tape. Otherwise, the wires could rub against the body, which could result in water penetration and electrical shorting. (Scheme 13): Precaution For Harness Protective Tape
Scheme 14
Scheme 14: Disconnecting connectors
- When disconnecting connector, grasp the connectors, not the wires.
- Connectors can be disconnected by pressing or pulling the lock lever as shown. (Scheme 15): Disconnecting Connectors
Scheme 15
Scheme 15: Locking connector
- When locking connectors, listen for a click indicating they are securely locked. see scheme 30: Locking Connector With Audible Click Sound
