Washer System & Wiper System: Removal & Installation Mazda 6 GG

Windshield Wiper Link Removal Note

1. Pry off the connection between the windshield wiper motor and windshield wiper link.

Scheme 14

Scheme 15

1. Disconnect the windshield wiper motor connector.
2. Connect battery positive voltage to terminal E or D and ground to terminal B, and inspect operation of the windshield wiper motor as indicated below.
3. Disconnect battery positive voltage from terminal E of the motor while the wipers are operating.
4. Verify that the wipers do not stop in the park position.
5. Short between the motor terminals A and D and connect battery positive voltage to the motor terminal C.
6. Verify that the wipers operate at low speed again, then stop in the park position. If not as specified, replace the windshield wiper motor.

Scheme 16

Scheme 17

1. Disconnect the negative battery cable.
2. Remove the front bumper. (See FRONT BUMPER REMOVAL/INSTALLATION .)
3. Remove in the order indicated in the illustration.
4. Install in the reverse order of removal.

Scheme 18

1. Install the windshield washer hose by inserting it in the washer tank groove.

Scheme 19

Scheme 20

1. Disconnect the negative battery cable.
2. Remove the front bumper. (See FRONT BUMPER REMOVAL/INSTALLATION .)
3. Remove in the order indicated in the illustration.
4. Install in the reverse order of removal.

WINDSHIELD WASHER NOZZLE REMOVAL/INSTALLATION

1. Remove the bonnet insulator.
2. Remove the windshield washer hose from the windshield washer nozzle.
3. Squeeze the tabs of the windshield washer nozzle.
4. Pull the windshield washer nozzle out to remove it.
5. Install in the reverse order of removal.

Scheme 21

1. Clean the washer nozzle by inserting and moving a needle or an equivalent tool back and forth. If the nozzle becomes clogged again after cleaning, remove the hose from washer nozzle. Make sure there is enough washer fluid. Then turn the washer switch on and flush the inside of the hose.

Scheme 22

Scheme 23

1. Remove the bonnet insulator.
2. Partially peel off the right side mud guard.
3. Remove in the order indicated in the figure below.
4. Install in the reverse order of removal.

Scheme 24

1. Install the windshield washer hose by inserting it in the washer tank groove.

Scheme 25

Scheme 26

1. Disconnect the negative battery cable.
2. Remove the column cover.
3. Remove in the order indicated in the illustration.
4. Install in the reverse order of removal.

Scheme 27

Scheme 28

1. Remove the wiper and washer switch. (See «WIPER AND WASHER SWITCH REMOVAL/INSTALLATION»(ref-193890-S38759028252005092600000) .)
2. Inspect for continuity between the wiper and washer switch terminals using an ohmmeter. If not as specified, replace the wiper and washer switch.
