Sunroof: Overview Mazda 6 GG

Scheme 1

Scheme 2

1. Fully open the glass panel.
2. Remove the headliner.
3. Remove the screws.
4. Disengage the tabs by performing the following procedure. Press the rear end of the tabs. After sliding the hooks rearward, press them upward.
5. Remove the deflector.
6. Install in the reverse order of removal.

Scheme 3

Scheme 4

1. Fully close the glass panel.
2. Fully open the sunshade.
3. Remove the screws, and then remove the glass panel.
4. Peel the weatherstrip off the glass panel.
5. Install in the reverse order of removal.
6. Adjust the glass panel. (See «GLASS PANEL ADJUSTMENT»(ref-193886-S10284840682005092600000) .)

Scheme 5

Scheme 6

1. Fully close the glass panel.
2. Measure the gap and height difference between the glass panel and body.
3. If not as specified, loosen the glass panel installation screws and reposition the glass panel. Clearance a: 0.2-2.2 mm {0.008-0.087 in} b: 0.2-2.2 mm {0.008-0.087 in} c: 1.0-3.0 mm {0.040-0.118 in} d: 0.9-2.9 mm {0.04-0.11 in} e: 0 mm {0 in}
4. Tighten the installation screws.
5. Insert a prepaid card between the weatherstrip and the body of the vehicle. Verify that the sunroof is shut tightly (there is resistance when the prepaid card is moved). If the sunroof is not shut tightly, readjust by performing Steps 3 and 4.

Scheme 7

1. Remove the headliner.
2. Disconnect the front drain hose from the sunroof frame.
3. Remove the front drain hose from the clips.
4. Pull the front drain hose into the room side.
5. Remove the front drain hose.
