Entertainment System: Removal & Installation Mazda 6 GG

AUDIO CONTROL SWITCH REMOVAL/INSTALLATION

Note. The audio control switch and the cruise control switch use a common connector.

Scheme 88

Scheme 89

1. Disconnect the negative battery cable.
2. Remove the driver-side air bag module. (See «DUAL-STAGE DRIVER-SIDE AIR BAG MODULE»(ref-160473-S19123802582004021000000) .)
3. Remove the steering wheel.
4. Remove in the order indicated.
5. Install in the reverse order of removal.

Scheme 90

Scheme 91

1. Disconnect the negative battery cable.
2. Remove the driver-side air bag module. (See «DUAL-STAGE DRIVER-SIDE AIR BAG MODULE»(ref-160473-S19123802582004021000000) .)
3. Disconnect the audio control switch connector.
4. Measure the resistance and inspect for continuity between the cruise control switch terminals using an ohmmeter. If not as specified, replace the cruise control switch.

Scheme 92

Scheme 93

1. Disconnect the negative battery cable.
2. Remove in the order indicated.
3. Install in the reverse order of removal.

Scheme 94

Scheme 95

1. Disconnect the negative battery cable.
2. Remove the rear package trim.
3. Remove in the order indicated.
4. Install in the reverse order of removal.

Scheme 96

Scheme 97

1. Inspect for resistance and continuity between the noise filter terminals using an ohmmeter. If not as specified, replace the noise filter.

Scheme 98

Scheme 99

1. Inspect for resistance and continuity between the noise filter terminals using an ohmmeter. If not as specified, replace the noise filter.

Scheme 100

Scheme 101

1. Disconnect the negative battery cable.
2. Remove the rear package trim.
3. Remove in the order indicated.
4. Install in the reverse order of removal.

Scheme 102

Scheme 103

1. Disconnect the negative battery cable.
2. Remove in the order indicated.
3. Install in the reverse order of removal.

Scheme 104

Scheme 105

Scheme 106

1. Insert a tape-wrapped flathead screwdriver into the socket hole, then push on the ring protrusion to lift the socket toward you.
2. As shown in the figure (Scheme 105), lift out the socket until the ring protrusion locks into the lower socket hole.
3. Remove the boot panel.
4. Front behind the boot panel, slide a tape-wrapped flathead screwdriver in between the socket and the ring protrusion.
5. While twisting the ring protrusion with the screwdriver, push out and remove the socket.

Scheme 107

1. Pull the ring forward while squeezing the tabs.
