Entertainment System: Overview Mazda 6 GG

Scheme 53

Scheme 54

Scheme 55

1. Disconnect the negative battery cable.
2. Remove the front door trim.
3. Remove in the order indicated.
4. Install in the reverse order of removal.

Scheme 56

1. Attach the speaker with the wiring harness placed in the groove of the door unit panel. CAUTION: If the speaker is attached with the harness placed outside of the groove, the wiring harness might be broken.

Scheme 57

Scheme 58

1. Inspect for resistance between the front door speaker terminals using an ohmmeter. If not as specified, replace the front door speaker.
2. To verify that the front door speaker outputs sound, apply voltage to the front door speaker and release using a 1.5 V battery. If it does not output sound, replace the front door speaker.

Scheme 59

Scheme 60

1. Disconnect the negative battery cable.
2. Remove the rear door trim.
3. Remove in the order indicated.
4. Install in the reverse order of removal

Scheme 61

1. Attach the speaker with the wiring harness placed in the groove of the door unit panel. CAUTION: If the speaker is attached with the harness placed outside of the groove, the wiring harness might be broken.

Scheme 62

Scheme 63

1. Inspect for resistance between the rear door speaker terminals using an ohmmeter. If not as specified, replace the rear door speaker.
2. To verify that the rear door speaker outputs sound, apply voltage to the rear door speaker and release using a 1.5 V battery. If it does not output sound, replace the rear door speaker.

Scheme 64

Scheme 65

1. Disconnect the negative battery cable.
2. Remove in the order indicated.
3. Install in the reverse order of removal.

Scheme 66

Scheme 67

1. To verify the front door speaker outputs sound. If it does output sound, then go to next step. If it does not output sound, inspect the front door speaker and related wiring harnesses. (See «FRONT DOOR SPEAKER INSPECTION».)
2. Remove the center panel module. (See «CENTER PANEL MODULE REMOVAL/INSTALLATION».)
3. Inspect for continuity between the tweeter connector terminals and audio unit connector terminals using an ohmmeter. If there is no continuity, replace the related wiring harnesses. If there is continuity, replace the tweeter.

Scheme 68

Scheme 69

1. Disconnect the negative battery cable.
2. Remove the rear package trim.
3. Remove in the order indicated.
4. Install in the reverse order of removal.

Scheme 70

Scheme 71

1. Inspect for continuity between the audio amplifier connector terminals and woofer connector terminals using an ohmmeter. If not as specified, replace the related wiring harnesses.
2. Verify that there is battery positive voltage at the woofer connector terminal A using a voltmeter. If not as specified, replace the related wiring harness.
3. Inspect continuity between the woofer connector terminal B and body ground using an ohmmeter. If not as specified, replace the related wiring harness. If as specified, replace the woofer.

Scheme 72

Scheme 73

1. Inspect the glass antenna for damage visually.
2. Inspect for continuity between the glass antenna terminals using an ohmmeter. If not as specified, repair the glass antenna. (See «FILAMENT REPAIR».)

Scheme 74

Scheme 75

Scheme 76

1. Verify that there is no continuity between the front antenna feeder terminals A and B using an ohmmeter.
2. Inspect for continuity between the front antenna feeder terminals using an ohmmeter. If not as specified, replace the instrument panel harness.

Scheme 77

Scheme 78

1. Verify that there is no continuity between antenna feeder terminals A and B using an ohmmeter.
2. Inspect for continuity between the antenna feeder terminals using an ohmmeter. If not as specified, replace the rear harness.

Scheme 79

Scheme 80

1. Disconnect the negative battery cable.
2. Remove the glove compartment.
3. Remove the rear console.
4. Remove in the order indicated.
5. Install in the reverse order of removal. CAUTION: Make certain that the wiring harness and antenna feeder are not caught between the unit and dashboard. If the harness or the antenna feeder is caught between the unit and dashboard, it may cause trouble or malfunctions.

Scheme 81

1. Attach protective tape to the bracket installed to the dashboard. CAUTION: Removing the bolt without attaching protective tape to the bracket may cause injury to your hand. Always attach protective tape to the bracket when removing the bolt.
2. Remove the Bolt.

Scheme 82

1. Pull the center panel module toward you, then disengage clips A from the dashboard, and remove the center panel module.

See also:
• CONSOLE REMOVAL/INSTALLATION
