SUPPLIER IDENTIFICATION PROCEDURE [AUDIO]
Note. The supplier can vary with the module. When asking the supplier (service center) for repair or replacement, identify the supplier and fill in the Audio Repair Order Form with the following procedures.
Identification Using the Label or Inscribed Lettering
- Disconnect the negative battery cable.
- Remove the following parts: Side wall (See «SIDE WALL REMOVAL/INSTALLATION».) Selector lever knob (ATX) (See «SELECTOR LEVER COMPONENT REMOVAL/INSTALLATION»(/mazda/5/i-2007-2010/remont/automatic-trans/#automatic-transaxle-shift-mechanism).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(/mazda/5/i-2007-2010/remont/manual-trans/#manual-transaxle-shift-mechanism).) Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION».) Center panel module (See «CENTER PANEL MODULE REMOVAL/INSTALLATION».)
- Verify the supplier by referring to the label attached to each unit.
Scheme 44
Scheme 45
Scheme 46
- Switch the ignition to ACC or ON.
- Turn the audio unit power on.
- While pressing the POWER switch, simultaneously press the Preset switch "5" for approx. 3 s or more.
- Identify the supplier code by referring to the information display. SUPPLIER CODE REFERENCE CHART Supplier code Supplier name 01 SANYO Automedia 02 Panasonic 03 Clarion 04 Pioneer NOTE: The supplier code can also be identified from the DTC displays screen.
- Cancel the diagnostic assist function by either turning off the audio unit power or by ignition to the switched off.
