Entertainment System: Removal & Installation Mazda 5 I рестайлинг

GPS ANTENNA FEEDER REMOVAL/INSTALLATION

Note. The GPS antenna feeder is integrated with the vehicle wiring harness.

Scheme 21

1. Disconnect the negative battery cable.
2. Remove the following parts: Front door (See «FRONT DOOR REMOVAL/INSTALLATION»(ref-292960-S10388223372008080600000) .) Sail garnish (See «SAIL GARNISH REMOVAL/INSTALLATION»(ref-292917-S33502298482008080600000) .) Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-292888-S11748287832008080600000) .) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-292888-S14675185142008080600000) .) Side panel (passenger's side) (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-292888-S04204557052008080600000) .) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-292888-S04204557052008080600000) .) Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-292888-S22395177942008080600000) .) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-292888-S03337365032008080600000) .) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-292888-S42810347612008080600000) .) Center panel module (vehicles with audio unit) (See «CENTER PANEL MODULE REMOVAL/INSTALLATION»(ref-292927-S19114208722008080600000) .) Center panel (vehicles without audio unit) (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-292888-S01410883792008080600000) .) Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-292890-S30450519742008080600000) .) (See «CLIMATE CONTROL UNIT REMOVAL [MANUAL AIR CONDITIONER]»(ref-292890-S18303811792008080600000) .) (See «CLIMATE CONTROL UNIT INSTALLATION [MANUAL AIR CONDITIONER]»(ref-292890-S08845262062008080600000) .) Car-navigation unit (Vehicles with car-navigation system) (See «CAR-NAVIGATION UNIT REMOVAL/INSTALLATION»(ref-292927-S36288927672008080600000) .) Selector lever component (See «SELECTOR LEVER COMPONENT REMOVAL/INSTALLATION»(ref-292885-S14884822382008080600000) .) Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-292888-S19738017082008080600000) .) Lower column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-292888-S25932918152008080600000) .) Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-292926-S08983945512008080600000) .) Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-292891-S35675246712008080600000) .) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-292901-S42703079542008080600000) .) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-292888-S16548083342008080600000) .) Rear heater duct (1) (See «REAR HEAT DUCT REMOVAL/INSTALLATION»(ref-292915-S37756334862008080600000) .) Windshield wiper arm and blade (See «WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION»(ref-292916-S04731457852008080600000) .) Cowl grille (See «COWL GRILLE REMOVAL/INSTALLATION»(ref-292917-S06728171802008080600000) .) Center cowl grille (See «CENTER COWL GRILLE REMOVAL/INSTALLATION»(ref-292917-S07168577912008080600000) .) Dashboard (See «DASHBOARD REMOVAL/INSTALLATION»(ref-292888-S03392767112008080600000) .)
3. Secure the new GPS antenna feeder to the vehicle wiring harness along the installation route of the old GPS antenna feeder.

Scheme 22

Scheme 23

1. Verify that there is no continuity between the GPS antenna feeder terminal A and B.
2. Verify that the continuity is as indicated in the table. If not as indicated in the table, replace the GPS antenna feeder.

Scheme 24

1. Disconnect the negative battery cable.
2. Remove the driver-side air bag module. (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-292926-S08983945512008080600000) .)
3. Remove the steering wheel. (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-292891-S35675246712008080600000) .)
4. Remove in the order indicated in the table.
5. Install in the reverse order of removal.

Scheme 25

1. Install the audio control switch so that the audio control switch wiring harness passes behind the steering wheel as shown in the figure.

Scheme 26

Scheme 27

1. Disconnect the negative battery cable.
2. Remove the driver-side air bag module.(See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-292926-S08983945512008080600000) .)
3. Disconnect the audio control switch connector.
4. Verify the resistance and continuity between the audio control switch terminal c and d. If the resistance and continuity are not as indicated in the tables, replace the audio control switch. R: : Resistance. See the table. RESISTANCE SPECIFICATION Switch position Resistance (ohm) VOL- button ON 51-56 VOL+ button ON 140-154 PRESET+ button ON 286-316 PRESET- button ON 533-590 MODE button ON 984-1,089 VOICE/MUTE button ON 1,934-2,139 OFF 4,794-5,300
5. Connect the positive battery to the audio control switch terminal F, the negative battery to the audio control switch terminal E.
6. Verify that LED illuminated. If there is any malfunction replace the audio control switch.

Scheme 28

1. Disconnect the negative battery cable.
2. Remove the following parts: Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-292888-S04204557052008080600000) .) Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-292888-S22395177942008080600000) .) Center panel module (with audio unit) (See «CENTER PANEL MODULE REMOVAL/INSTALLATION»(ref-292927-S19114208722008080600000) .) Center panel (without audio unit) (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-292888-S01410883792008080600000) .) Climate control unit (with car-navigation system) (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-292890-S30450519742008080600000) .) Car-navigation unit (with car-navigation system) (See «CAR-NAVIGATION UNIT REMOVAL/INSTALLATION»(ref-292927-S36288927672008080600000) .) Dashboard center panel (See «DASHBOARD CENTER PANEL REMOVAL/INSTALLATION»(ref-292888-S07737677892008080600000) .)
3. Remove the microphone.
4. Install in the reverse order of removal.

Scheme 29

1. Disconnect the negative battery cable.
2. Remove the following parts: Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-292888-S04204557052008080600000) .) Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-292888-S22395177942008080600000) .) Front scuff plate inner (passenger's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-292888-S11748287832008080600000) .) Front side trim (passenger's side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-292888-S14675185142008080600000) .) Side panel (passenger's side) (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-292888-S04204557052008080600000) .) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-292888-S03337365032008080600000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 30

1. Disconnect the negative battery cable.
2. Remove the side wall. (See «SIDE WALL REMOVAL/INSTALLATION»(ref-292888-S04204557052008080600000) .)
3. Remove the front console. (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-292888-S22395177942008080600000) .)
4. Disconnect the auxiliary jack connector.
5. Squeeze the tabs of auxiliary jack and pull it outward to remove it.
6. Install in the reverse order of removal.

Scheme 31

Scheme 32

1. Connect a commercially-available nonresistant plug to the auxiliary jack.
2. Verify that the continuity between the auxiliary jack terminals is as indicated in the table. If not as indicated in the table, replace the auxiliary jack.

Scheme 33

1. Disconnect the negative battery cable.
2. Remove the following parts: Rear package tray lid (See «REAR PACKAGE TRAY LID REMOVAL/INSTALLATION»(ref-292888-S11741306112008080600000) .) Third-row seat (See «THIRD-ROW SEAT REMOVAL/INSTALLATION»(ref-292922-S10467716332008080600000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-292888-S27858191902008080600000) .) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-292888-S07958763512008080600000) .) Lower anchor of the third-row seat belt (See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-292923-S30538138522008080600000) .) Cargo compartment light (See «CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION»(ref-292924-S28232554992008080600000) .) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-292888-S33319963922008080600000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 34

1. While pressing a tape-wrapped flathead screwdriver against the cap projection, pull the accessory socket outward.

Scheme 35

1. While pressing the tabs, pull the cap outwards.

Scheme 36

1. Connect a tester as shown in the figure and verify that there is continuity. If the continuity cannot be verified, replace the accessory socket.
