No.5 Resetting Procedure for the Immobilizer System when Replacing the PCM or Instrument Cluster Conditions

1. When replacing only the PCM: No conditions.
2. When replacing only the instrument cluster: Customer has two or more valid keys after replacement tasks.
3. When replacing the PCM and the instrument cluster: Customer has two or more valid keys after replacement.

Scheme 39

1. Have two or more keys (key 1, key 2) ready for registration.
2. Using key 1, turn the ignition switch to the ON position. NOTE: When replacing only the PCM: The security light illuminates for 3 s and then goes out. When replacing the instrument cluster: Although the security light flashes and DTC 15 is displayed, this does not indicate an improper procedure. Continue to perform the procedure as indicated.
3. Connect the M-MDS to the DLC-2.
4. After the vehicle is identified, select the following items from the initialization screen of the M-MDS. When using the IDS (laptop PC) Select the "Body". Select the "Security". Select the "PATS Functions". When using the PDS (Pocket PC) Select the "Programming". Select the "PATS Functions".
5. Select "Ignition Key Code Erase" from the M-MDS screen menu and perform the procedure according to the M-MDS screen. (When replacing the instrument cluster)
6. Perform security access as indicated on the M-MDS screen. (See «NO.6 SECURITY ACCESS PROCEDURE»(ref-292928-S30019567632008080600000) .)
7. Select "Parameter Reset" from the M-MDS screen menu.
8. Select the replaced part as indicated on the M-MDS screen. When replacing only the PCM: Select "PCM". When replacing only the instrument cluster: Select "IC". NOTE: At this time, do not select any other parts from the M-MDS screen menu.
9. After verifying that the PATS function menu is displayed again on the M-MDS screen, select "Exit" to complete the M-MDS function.
10. After Step 9 , wait 10 s or more and turn the ignition switch to the LOCK position using key 1.
11. Using key 1, turn the ignition switch to the ON position. NOTE: When replacing only the PCM: The security light illuminates for 3 s and then goes out. When replacing only the instrument cluster: Although the security light flashes and DTC 21 is displayed, this does not indicate an improper procedure. Continue to perform the procedure as indicated.
12. Perform the following procedures: When replacing only the PCM: After verifying that the security light goes out, turn the ignition switch to the LOCK position. (Procedure completed) When replacing only the instrument cluster: After verifying that the security light illuminates for 3 s or more, turn the ignition switch to the LOCK position, remove key 1, and then go to the next step.
13. Using key 2, turn the ignition switch to the ON position.
14. Verify that the security light illuminates for approx. 3 s and then goes out.
15. After verifying that the security light goes out, turn the ignition switch to the LOCK position using key 2, and then remove key 2.
16. If an additional key needs to be registered, repeat Steps 13 - 15 in the same manner as key 2. Steps 13 - 15 must be performed within 1 min for each key. If the ignition switch is maintained in the ON position for 1 min or more, key registration according to Steps 13 - 15 will not be possible. If this occurs, refer to " «NO.1 ADDITIONAL KEY REGISTRATION PROCEDURE (USING TWO VALID KEYS)»(ref-292928-S06004930202008080600000) " to register any additional keys.
