Control System (HVAC): Overview Mazda 5 I рестайлинг

Automatic HVAC System 5 illustrations ~270 words

Scheme 1

Scheme 1: HVAC CONTROL SYSTEM LOCATION INDEX [FULL-AUTO AIR CONDITIONER]
Scheme 1: HVAC CONTROL SYSTEM LOCATION INDEX [FULL-AUTO AIR CONDITIONER]

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3: AIR INTAKE ACTUATOR REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]
Scheme 3: AIR INTAKE ACTUATOR REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]
  1. Disconnect the negative battery cable.
  2. Remove the following parts: Side wall (See «SIDE WALL REMOVAL/INSTALLATION».) Shift lever component (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(/mazda/5/i-2007-2010/remont/manual-trans/#manual-transaxle-shift-mechanism).) Selector lever component (ATX) (See «SELECTOR LEVER COMPONENT REMOVAL/INSTALLATION»(/mazda/5/i-2007-2010/remont/automatic-trans/#automatic-transaxle-shift-mechanism).) Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION».) Front scuff plate inner (passenger's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION».) Front side trim (passenger's side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION».) Side panel, (passenger's side) (See «SIDE PANEL REMOVAL/INSTALLATION».) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION».) HF/TEL unit (See «HANDS-FREE TELEPHONE (HF/TEL) UNIT REMOVAL/INSTALLATION».)
  3. Remove the blower case.
  4. Remove in the order indicated in the table.
  5. Install in the reverse order of removal.

Scheme 4

Scheme 4: AIR INTAKE ACTUATOR INSPECTION [FULL-AUTO AIR CONDITIONER]
Scheme 4: AIR INTAKE ACTUATOR INSPECTION [FULL-AUTO AIR CONDITIONER]
  1. Connect battery positive voltage to air intake actuator terminal C (or G), connect terminal G (or E) to ground, and then verify that the air intake actuator operates as shown in the table. If the operation condition is not normal, replace the air intake actuator. TERMINALS REFERENCE CHART Terminal Air intake actuator operation C E G B+ - Ground FRESH-->RECIRCULATE - Ground B+ RECIRCULATE-->FRESH

Scheme 5

Scheme 5: AIR MIX ACTUATOR REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]
Scheme 5: AIR MIX ACTUATOR REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]
  1. Disconnect the negative battery cable.
  2. Remove the following parts: Side wall (See «SIDE WALL REMOVAL/INSTALLATION».) Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION».) Front scuff plate inner (passenger's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION».) Front side trim (passenger's side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION».) Side panel, (passenger's side) (See «SIDE PANEL REMOVAL/INSTALLATION».) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION».)
  3. Remove in the order indicated in the table.
  4. Install in the reverse order of removal.
